Summary of Contents for Hobby Wireless HORYZONHD V4

Page 1 14 Megapixel High Definition Split-Type DVR Instruction...
Page 2: Table Of Contents
Catalog N o t i c e …………………………………………………………… 1 Start Guide 1 Accessory Diagram…………………………………………3 2 F u n c t i o n D i a g r a m ……………………………………… 5 3 Micro SD Insert and Plug in………………………………9 4 Power ON/OFF……………………………………………10 5 Date / Time Setting ………………………………………11 Operation Guide 1 Function Setting Menu……………………………………12...
Page 3 3 Photo…………………………………………………………22 4 Playback……………………………………………………23 ■ Playback Operation…………………………………23 ■ Playback Manual……………………………………24 ■ Playback Setting Manual…………………………25 5 Indicator Light……………………………………………25 Other Special Function 1 Connect to the Computer………………………………26 2 Connect to Aircraft Remote Controller Receiver……27 Basic Specification…………………………………………28...
Page 4: Notice
Notice > Warning ● Keep from moisture to avoid fire hazard, electric shock and damage. ● Only use the recommended accessory. ● Do not disassemble, there is no maintainable parts inside the machaine.
Page 5 > Attention ● Certain frequency electromagnetic field may affect the image and sound. ● If transfer data failed by static or electromagnetic, disconnect and restart, re-link the cable (USB etc.). ● Do not install the device in the confined container to avoid any fire hazard and damage.
Page 6: Start Guide
Start Guide > Accessory Diagram USB Cable...
Page 7 PHOTO_PPM_IN MOVIE_PPM_IN AUDIO_OUT DC_IN / VIDEO_OUT 6P Multi-function Cable 6PDC Cable...
Page 8: U N C T I O N D I A G R A M
> Function Diagram Record Button Microphone Photo Button LED Indicator Playback Button Manual Button...
Page 9 6P Multi-function Port USB Cable Port Micro SD Port HDMI Port Camera Port LCD Scree Socket...
Page 10 LCD Screen LCD Screen Plug Volume- Volume+ LCD Screen ON/OFF Speaker...
Page 11 Screen CameraCable...
Page 12: Micro Sd Insert And Plug In
> Micro SD Insert and Plug in Insert the Micro SD Follow the arrow direction, insert the Micro SD Card, keep the gold contact facing down, push into the card with 'click' sound.
Page 13: Power On/Off
Take Out the MicroSD ● When record and playback, do not take out the Micro SD Card. ● Press the Micro SD inward with 'click' sound, then take out the card. > Power ON/OFF The device is auto start up when power on, auto save when power off.
Page 14: Date/Time Setting
> Date/Time Setting ● First use, keep the device on-state for 24 hours. It could make full charge of built-in battery which is used for time and power off retention ● During the first-use, set the date and time to guarantee the documents on the right date and time.
Page 15: Operation Guide
Operation Guide > Function Setting Menu Press "M" to Menu, choose "record /photo /setting " by "M", then press "OK " to sub-menu setting inter-surface . Press " " to choose sub-menu, then press "OK " to lower sub-menu. Press " "...
Page 16 6 7 8 9 ① Photo Quality : S.Fine, Fine, Normal ② Photo Size : 14M,16M ③ Video Quality : S.Fine, Fine, Normal ④ Video Size : 1920*1080 30p 16:9;1280*720 60p 16:9; 1280*720 30p 16:9; 848*480 60p 16:9;848*480 30p 16:9;...
Page 17 ⑤ Mode : Video/Photo, Thumbnail, Playback ⑥ Battery Volume ⑦ Sd Card Volume / Micro SD ⑧ Self Time : Off, 3sec, 5sec ,10sec ⑨ Rec Lapse : Normal record, rec lapse off, rec lapse 1sec, rec lapse 5sec, rec lapse 30sec...
Page 18: Record Menu Setting
1. Record Menu Setting Item 1 0 8 0 P 3 0 P / 7 2 0 P 6 0 P / 7 2 0 P 3 0 P / 4 8 0 P Video Size 60P/480P 30P Auto-Record ON / OFF Video Quality High / Middle / Low Video Section 5 min /10 min /15 min /OFF Watermark...
Page 19: Photo Menu Setting
Microphone ON / OFF Microphone 30P/ 70P/ 100P Volume 2. Photo Menu Setting Items Photo Size 14.4M(4384*3288 4:3)/16M(4608*3456 4:3) Delay Photo OFF/ 3/ 10/ 20/ 30/ 60 sec Self-Timer OFF/ 3/ 5/ 10 sec Watermark/ OFF/ Time/ Date/ Time and Date postmark...
Page 20: System Setting Menu
3. System Setting Menu Items Simplified Chinese/ English/ Language Setting Japanese/ Portuguese/Germany 2008/01/01 00：00 (Year/Month/Day/ Date/ Time Setting Hour/Minute) Auto Screen Off 30sec/ 1/ 3/ 5 min Auto Power-Off OFF/ 3/ 5/ 10 min Standard / Image Rotation File No. Reset / Continuous...
Page 21 Notification Tone ON / OFF Indicating Light ON / OFF Formatting 30P/ 70P/ 100P Default Setting USB Port Mobile HDD/ Camera/ Power supply Version Information...
Page 22: Record
> Record 1. Record : ● Press " " to start the record, " ● " on the top of screen and the moving time shown. ● The auto-save of video file is in accordance with the setting time of video segmentation in the record menu;...
Page 23 2. Auto Record : ● When the device power on and start, it will access to the recording mode automatically. ● Under the recording mode, the setting of recording menu is the same with the setting before start. 3. Time Lapse Record: ●...
Page 24 4. Record Loop : ● In the loop record, the record icon “ ” of standby image will response to the setting time lapse record. ● In the loop record, there is no need to replace the memory card for long time record, the recording is between normal record and auto record mode.
Page 25: Photo
> Photo 1. Normal Photo Mode : Press once to take one picture. During taking photo, the photo icon changes with the photo modes. 2. Delay Photo : Setting the camera aperture and adjusting the delayed time, the photo icon changes with the setting.
Page 26: Playback
> Playback 1. Playback Operation Under the preview mode, press "OK " to preview thumbnail inter-surface. ● Playback Preview : Quit the Playback Mode: Long Press M Access to Playback Menu: Press M File Select: Press " " Play: Press "OK" ●...
Page 27: Playback Manual
● Playback Menu Confirm: press "OK " Up: Press " " Down: Press " " Quit: Press "M" 2. Playback Menu Play Menu Single/ Full/ Single Cycle/ Full Cycle PowerPoint ON / OFF PowerPoint Mode Fade-Out / Floating The Current File Delete / All the File File Delete Delete...
Page 28: Playback Setting Manual
3. Playback Setting Menu: ● Same with the main menu setting items. > The Indicator ● Under the normal working, the indicator long light. ● When recording/taking photo, the indicator turn long light to flash, after accomplished, it is back to long light.
Page 29: Other Special Function
Other Special Function > Connect to the Computer ● Before connecting to the computer, set the power supply/mobile HDD/camera. ● If selecting the power supply mode, the device is charged through USB cable with computer. ● After selecting mobile HDD mode, computer could visit the memory card through USB cable and operate.
Page 30: Connect To Aircraft Remote Controller Receiver
> Connect to Aircraft Remote Controller Receiver ● Connect to the aircraft remote controller receiver by the dedicated tail circuit. The connection could take photo or make record to the device in the air. ● The test of the function on FUTABA system is passed.
Page 31: Basic Specification
Basic Specification Item Content Image Sensor 1/2.3 COMS 14 megapixels Lens F+2.8 FOV：150° up and down: Camera 90° Exposure Control Automatic White Balance Automatic Format: JPEG pixel 14.4M (4384*3288 Photo 4:3) / 16M (4608*3456 4:3)
Page 32 Format H.264 compressed format size 16：9 1920*1080 30 frame/second,6： 9 1280*720 60 frame / second，16： Image 9 1280*720 30 frame / second 16： 9，848*480 60 frame / second，16：9 848*480 30 frame / second. Storage Max Micro SD Card: 32GB 2.0″ TFT LCD Pixel：960*240 Multi-function USB port ( compatible with mini USB Plug ) , mini HDMI port, Multi-Function Port...
