media-tech MT6254 Instruction Manual

90W/120W UNIVERSAL
POWER ADAPTOR
Power Delivery for Most of Mobile Computers
NOTE: Before connecting this power adaptor
to Your computer, check the power require-
ments for specifi c computer.
Before using
Thank You for buying this universal power adap-
tor. Please read this manual carefully because a
mistake could cause Your computer damage.
MEDIA-TECH
Prepare to use
1. Find on the notebook SN label value of DC
voltage
2. Using switch in the power adaptor set cor-
rect DC voltage corresponding to DC value on
notebook's SN label.
NOTE: If Your computer should be powered
with non-absolute value of voltage (ex.:
16,5V), please set the LOWER value in power
adaptor: 16V.
Instructions Manual
3. Assembly correct DC adapter head, compat-
ible with power socket in Your notebook, on
DC plug.
4. Connect power cord to AC100~240V 50/60Hz
Power source. The power adaptor will emit-
ting a heat what is normal during work.
Using USB +5V power output
From the USB +5V port can be charged any de-
vice powered with this voltage thru the own USB
interface such as: cellular phone, media player,
PDA, etc.
NOTE: Before connecting this power adaptor
to Your computer, check the power require-
ments for specifi c computer. Setting wrong
value of voltage will damage Your computer.
Media-Tech is not responsible for computers
damages caused by wrong voltage setting.
MT6254/MT6255
EN
