Industriefunkuhren _____________________________________________________________ Technical Manual System 6844 and 6844RC (GPS and Sub-Master) For Housing Versions 1U / 3U / Table / Wall ENGLISH Version: 03.00 - 17.12.2012 _____________________________________________________________ Valid for System 6844(RC) with FIRMWARE Version: 03.xx...
Page 3
Functionality Disregard may impact function of system/device. Information Notes and Information. System 6844(RC) - V03.00 3 / 157 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com...
Page 4
EU directive - especially with regard to protection of health and safety for the operator and the user - and may be released for sale within the common markets. 4 / 157 System 6844(RC) - V03.00 hopf Elektronik GmbH...
1.2.3.6 Function Board Slots ........................22 1.2.3.7 Temperature-controlled Forced Ventilation ................. 22 1.2.4 System Design 6844(RC) in ½ 19 inch Table Top Housing 3U/42HP ......23 1.2.4.1 ½ 19 Inch Table Top Housing 3U/42HP ..................24 1.2.5 System Design 6844(RC) in ½ 19 inch Wall Housing 3U/42HP ........24 1.2.5.1 ½...
Page 6
5.2.13 SYSTEM-Byte ........................58 5.2.13.1 Synchronization Mode (Sync.-Mode) ..................58 5.2.14 Keyword Function for Keypad .................... 59 5.3 SHOW Menu - Display of the System 6844(RC) Base Settings ....... 60 5.3.1 Satellite Values (GPS only) ....................61 6 / 157 System 6844(RC) - V03.00...
Page 7
5.5 INI Menu - System 6844(RC) Extended Settings/Functions ........73 5.5.1 Display the Firmware Version of Board 6844(RC) ............. 73 5.5.2 Display the PCID (Product Config ID) of Board 6844(RC) ..........73 5.5.3 3D / Position-fix GPS Reception a. Synchronization Mode (GPS only) ......74 5.5.4 DCF77 Pulse (1Hz) / DCF77 Antenna Simulation (77.5kHz) ..........
Page 8
ABLE OF ONTENTS 6.2 Data String Transmission Points of Time ..............89 6.3 Data Strings......................90 6.3.1 General Information about Data Output of Board 6844(RC) ..........90 hopf 6.3.2 Standard String (6021) ..................... 91 6.3.2.1 Specified Settings ........................91 6.3.2.2 Structure ............................. 91 6.3.2.3 Status ............................
Page 9
9.1.4 Send LED ......................... 140 9.1.5 Auto-Reset Logic (System-Bus) ..................140 9.1.6 Serial Output of Data Telegrams ..................141 9.1.7 RC-Functionality (6844RC Systems only) ............... 141 System 6844(RC) - V03.00 9 / 157 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com...
Page 10
11 Technical Data ......................147 11.1 Specific Technical Data for 3U / Table-Top / Wall ..........147 11.2 Specific Technical Data for 1U ................148 11.3 General Technical Data 6844(RC) ................. 149 11.3.1 Internal System Accuracy ....................150 11.3.2 Signal Outputs ........................151 12 Appendix ........................
Systems in accordance with changing future requirements. Housing Options hopf Systems 6844 and 6844RC are available to the customer in a variety of housing op- tions to permit their use in almost any application. Maintenance free Complete maintenance free (no additional service costs) and high equipment reliability result in great flexibility and a high degree of availability.
Both Systems are identical in their basic function and are based on the same hardware plat- form. However, System 6844RC also has more features and options. In this description, the notation 6844(RC) means that the statements refer to both Systems.
ESCRIPTION OF YSTEM 1.2.2 System Design 6844(RC) in 19 inch Rack 3U/42HP and 3U/84HP As standard, the System is assembled in a standard ½ 19" rack (3U/42HP). Optionally, the System is also available in a 1/1 19" rack (3U/84HP). The base system consists of the following: ...
Page 16
System front side 3U/84HP: System rear side / plug-in side 3U/84HP: 16 / 157 System 6844(RC) - V03.00 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com...
As standard, the System is assembled in a standard ½ 19" housing (3U/42HP) for control cabinet installation. Optionally, the System is also available in a 1/1 19" rack (3U/84HP) for control cabinet instal- lation. System 6844(RC) - V03.00 17 / 157 hopf Elektronik GmbH...
1.2.2.3 System-Bus 6000 System 6844(RC) contains the System-Bus which is made up of Bus Board with VG ledges, by means of which Control Board 6844(RC) and the Function Boards are connected. The System-Bus is used to: ...
YSTEM 1.2.3 System Design 6844(RC) in 19 inch Rack 1U/84HP (Slim Line) The system can be individually configured for various applications due to its partly modular design and can be easily upgraded or converted to suit changes in the application condi- tions.
1.2.3.5 System-Bus 6000 The System-Bus, consisting of the Bus Board with VG ledges, via which the Control Board 6844(RC) and the Function Boards are connected, can be found in the System 6844(RC). The System-Bus serves to provide: Distribution of the time information.
ESCRIPTION OF YSTEM 1.2.3.6 Function Board Slots Up to two Function Boards can be implemented in the System 6844(RC) 1U Slim Line. As a basic principle, the slot can be freely selected for each 'Function Board' / 'System-Bus Function Board'.
YSTEM 1.2.4 System Design 6844(RC) in ½ 19 inch Table Top Housing 3U/42HP In essence, the System consists of the same components as the 3U System, except that the arrangement is in accordance with the differing requirements of the housing option.
1.2.4.1 ½ 19 Inch Table Top Housing 3U/42HP 1.2.5 System Design 6844(RC) in ½ 19 inch Wall Housing 3U/42HP In essence, the System consists of the same components as the 3U System, except that the arrangement is in accordance with the differing requirements of the housing option.
1.2.5.1 ½ 19 Inch Wall Housing 3U/42HP 1.2.5.2 Slot for a Function Board In System 6844(RC), due to the mechanics of the housing, only one Function Board can be installed in the wall-mounting housing as standard. System 6844(RC) - V03.00...
Sub-Master (Slave) Systems are Systems 6844 (RC) that are synchronized by other Sys- tems such as a Master System 6844 (RC). Depending on the synchronisation mode an addi- tional hardware is required to connect the synchronisation signal to System 6844 (RC).
2.1.3 Synchronisation via Serial Interface with High-Accurate PPS In this synchronisation mode System 6844 (RC) gets, in addition to the serial data string for the time synchronisation, a PPS (Pulse per second) generated by the Master System. The time information is adopted form the serial data string in the synchronisation mode "Syn- chronisation via serial interface".
Set time offset +1h Daylight saving time Changeover point of time + current time status (daylight saving time or standard time) are taken from the synchronization signal System 6844(RC) - V03.00 29 / 157 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com...
Installation of the 19 Inch 3U Rack The System is assembled in a standard 3U/42HP or 3U/84HP 19" housing for control cabi- net installation (for dimensions see Chapter 1.2.2 System Design 6844(RC) in 19 inch Rack 3U/42HP and 3U/84HP) The following steps are to be carried out: ...
Mounting the Wall Housing 3.1.4 Earthing The System 6844(RC) is usually earthed via the PE cable of the power supply. An additional earth cable (up to 16mm ) for surge protection purposes can be connected by means of the earth screw located on the System housing.
6844(RC). The corresponding performance data can be taken from the equipment nameplate. The Sys- tem 6844(RC) is currently fitted with a power supply unit with a power consumption of max. 40VA. If the internal fuse (device protection) trips it is highly probable that the equipment is faulty.
6844(RC). The corresponding performance data can be taken from the equipment nameplate. The Sys- tem 6844(RC) is currently fitted with a power supply unit with a power consumption of max. 40VA. If the internal fuse (device protection) trips it is highly probable that the equipment is faulty.
The necessary steps to connect the Function Boards should be consulted in the respective technical specifications of the Function Boards present in the system. 34 / 157 System 6844(RC) - V03.00 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com...
3.2.2 Earthing The System 6844(RC) 1U Slim Line is usually earthed via the PE cable of the power supply. An additional earth cable for surge protection purposes can be connected by means of the earth screw located on the rear side of the System housing.
6844(RC) 1U Slim Line The corresponding performance data can be taken from the equipment nameplate. The Sys- tem 6844(RC) 1U Slim Line is currently fitted with a power supply unit with a power con- sumption of max. 40VA. If the internal fuse (device protection) trips it is highly probable that the equipment is faulty.
6844(RC) 1U Slim Line. The corresponding performance data can be taken from the equipment nameplate. The Sys- tem 6844(RC) 1U Slim Line is currently fitted with a power supply unit with a power con- sumption of max. 40VA. If the internal fuse (device protection) trips it is highly probable that the equipment is faulty.
The GPS antenna equipment coaxial cable is connected to the BNC connector marked "An- tenna" on the control board 6844(RC) of the System. More detailed specifications for the in- stallation of the antenna equipment, such as cable lengths and types, can be found in the manual "Antenna Equipment GPS".
Function Boards Connection / Input- and Output Modules The necessary steps to connect the Function Boards should be consulted in the respective technical specifications of the Function Boards present in the system. System 6844(RC) - V03.00 39 / 157 hopf Elektronik GmbH Nottebohmstr.
AC power supply 1U: Put the mains power switch into position " I " (on). The System 6844(RC) 1U Slim Line runs and the firmware version and programming date are shown on the display (see Chapter 4.3 Display after System Start/Reset (Firmware)).
The following start frame appears on the 2x16 digit LCD-Display for approx. 3 seconds after switch-on or reset: e.g. Control Board 6844 firmware S Y S T E M 6 8 4 4 Firmware programming date V 0 1 . 0 0 3 1 / M A Y / 1 0 respectively ...
This flashing occurs on the standard display only and not on the menu im- ages. 42 / 157 System 6844(RC) - V03.00 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com...
Completes and accepts the input at the end of an input frame. When no input is made, pressing ENT switches through to the next frame. The other buttons have no specific function. System 6844(RC) - V03.00 43 / 157 hopf Elektronik GmbH Nottebohmstr.
The base initialization of the equipment is carried out first. This enables the equipment to synchronize with the Sync.-Source. To initialize the System 6844(RC) GPS the menu items presented below are to be parame- terized accordingly (see Chapter 5.2 SET Menu - Basic Settings System 6844(RC)). In do- ing so attention should be paid to System and location specific requirements such as time base, synchronization source and synchronization parameters.
The parameters of all NTP LAN Boards available in the System and the Master Clock Board(s) (Menu 3 - S.CLK) are not stored on Control Board 6844(RC) but on the respective Function Board in each case. 5.2.2 Input Time / Date The local time is set with this input function.
(changeover points of time must be set for this purpose). 48 / 157 System 6844(RC) - V03.00 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com...
If the DST changeover is not to be activated all values have to be entered as 0. The System 6844(RC) then only operates with the standard time (winter time) set via the time offset. S E T C H A N G E _ O V E R...
The desired value is entered via the keyboard. The input is accepted by pressing the ENT key. The associated SHOW menu can display whether the SyncOFF timer is active and the current value of the timer. System 6844(RC) - V03.00 51 / 157 hopf Elektronik GmbH...
LEDs and error relays will be faulty. Set value for 1U Systems = 0000 0001 Programming takes place by entering a byte. The input is selected with the following selec- tion frame: System 6844(RC) - V03.00 55 / 157 hopf Elektronik GmbH...
Synchronization via DCF77 pulse free, currently GPS free, currently GPS free, currently GPS For further information see Chapter 2 System 6844(RC) Synchronization. The Sync.-Mode is not changed or reset by releasing a FACTORY DEFAULT. 58 / 157 System 6844(RC) - V03.00...
5.2.14 Keyword Function for Keypad The System can be protected by a key-word against unauthorized changes via the keypad to the settings. Warning: In the case of Systems 6844, if the keyword is lost this can hopf only be reset at the factory.
BR key. SHOW Menu - Display of the System 6844(RC) Base Settings The SHOW function is called up to check the values entered or the values updated via the GPS receiver.
(tracked) in order to synchronize the GPS System 6844(RC) with UTC and to calculate the position. Under optimum conditions approx. 9-14 satellites are in the visibility range of the antenna, of which 12 can be received in parallel.
B Y T E > 0 0 0 0 0 0 0 0 62 / 157 System 6844(RC) - V03.00 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com...
Page 63
Sync.-Protocol. This error bit is separately operated for each Sync.-Mode. All used Sync.-Protocols of the respective Sync.-Mode may cause the setting of a failure bit. System 6844(RC) - V03.00 63 / 157 hopf Elektronik GmbH Nottebohmstr.
Further information and an explanation of the parameters can be found in the description of the LAN Board. The LAN Board parameters are cyclically updated (approximately every 10 seconds) in Control Board 6844(RC), as these can also be changed via the WebGUI of the respective Board. 5.3.8.1 Display Frames for LAN Board 1 Parameters The configuration of the LAN Board coded as Board 1 is displayed on this display frame.
5.5.2 Display the PCID (Product Config ID) of Board 6844(RC) This function is used to display the PCID (Product Config ID) of Board 6844(RC). The PCID is displayed in 3 successive display frames. P R O D U C T C O N F I G...
This Chapter describes the configuration of the DCF77 pulse(s) and DCF77 antenna simula- tion (77.5 kHz). In System 6844(RC), one DCF77 pulse (1 Hz) is available as standard (DCF77.SYS). This DCF77 pulse is available to other Function Boards on the internal System-Bus; however, the same DCF77 pulse is also used to produce DCF77 antenna simulation (77.5 kHz) of Control Board 6844(RC)
(pulse / simulation) is always transmitted as soon as a valid time is availa- ble in the System. 5.5.4.2 Signal DCF77.ADD (Option) In System 6844(RC), there is an option to enable a second DCF77 pulse. The following menu items only appear when signal DCF77.ADD is enabled. 5.5.4.2.1 Display and Set DCF77.ADD Configuration In this display frame, both the current settings for signal DCF77.ADD are displayed and the...
27 bits for the input of control information 17 bits for the binary value of the current day seconds 100 bit frames can be transmitted in one second. Unused bit frames are filled with a logical zero. System 6844(RC) - V03.00 77 / 157 hopf Elektronik GmbH...
French Standards Association. It is based on IRIG Standard 200-89. IRIG-B Standard 200-89 is included in part as a sub-section of AFNOR NFS 87-500. 78 / 157 System 6844(RC) - V03.00 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com...
System. 5.5.5.4 IRIG-B.(2) Configuration/TimeOFF (Option) In System 6844(RC), there is an option to enable a second digital IRIG-B output. The following menu items only appear when the IRIG-B.(2) signal is ena- bled.
5.5.7 Trigger Reset / Default In System 6844(RC), a reset or default can be triggered in a differentiated way, in the Sys- tem or in individual components. R E S E T / D E F A U L T...
The interfaces / parameters dialog appears on the display with the following message: Input frame: 82 / 157 System 6844(RC) - V03.00 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com...
Page 83
The ENT key must be activated after the final entry. By doing so a plausibility check of the complete data entry is undertaken. If the data entry is valid the new settings are transferred. System 6844(RC) - V03.00 83 / 157...
The meanings of the individual bit positions (switches) are described in the following chap- ters. 84 / 157 System 6844(RC) - V03.00 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com...
STRING / PULSES). Bits B6-B4 are not currently assigned and must be set to off. 86 / 157 System 6844(RC) - V03.00 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com...
Optional functions, dependent on the software / hardware configuration. A 2Hz disturbing signal is always transmitted if a pulse is selected that is not available in the System, or not assigned System 6844(RC) - V03.00 87 / 157 hopf Elektronik GmbH...
This Chapter describes the data strings supported by this System. 6.3.1 General Information about Data Output of Board 6844(RC) When "last control character at second change" is set there is a transmission gap of up to 970msec., depending on the baud rate. This should be taken into consideration when pro- gramming the time-out on the reception side.
9600 baud, 8 bit, 1 stop bit, no parity This setting guarantees the best control of the time basis in the slave systems. Blocked: System 6844(RC) - V03.00 95 / 157 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com...
no announcement of a changeover The difference time to UTC is +2.30 h System 6844(RC) - V03.00 97 / 157 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com...
It is 12:34:56 o'clock radio operation day of the year System 6844(RC) - V03.00 103 / 157 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com...
Prepared slot for a LAN Management Board with a separate remote RS232 interface for connection to a PC (option) - (not for 1U) 126 / 157 System 6844(RC) - V03.00 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com...
1, 2, 3, 4, 5, 6 , 10, 12, 15, 20, 30 seconds The pulse length can be selected in the range 1 - 65,500 msec. The pulse duration should not exceed the cycle time, otherwise the output is switched through permanently. System 6844(RC) - V03.00 129 / 157 hopf Elektronik GmbH Nottebohmstr.
Page 131
Every 5th day of the month at 09:00 in the zero second pulse length approx. 100msec Due to a pulse duration longer than 1000msec (1sec) there is an overlap of the pulse output. System 6844(RC) - V03.00 131 / 157 hopf Elektronik GmbH Nottebohmstr.
Due to a pulse duration longer than 1000msec (1sec) there is an overlap of the pulse output (e.g. minute pulse) 132 / 157 System 6844(RC) - V03.00 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com...
Subsequent installation of the LAN Management Module is not possible in the field. The DCF77 antenna simulation (77.5kHz) via BNC connector, female is not applicable with implemented LAN Management Module. System 6844(RC) - V03.00 133 / 157 hopf Elektronik GmbH...
(the board must be configured prior to installation) Boards which are configured via the System 6844(RC) menu (and DIP switches or jumpers), (the base configuration of the board must be set prior to installation; the other settings are then carried out via the System 6844(RC) menu).
- Suitable for retrofit 7121 Relay Board for Pulse Output - Suitable for retrofit To expand 6844(RC) Systems with Function Boards for System-Bus, a slot with Bus-Bridge Boards must be available for each Board. System 6844(RC) - V03.00 135 / 157...
Switch the equipment back on Set Function Board to the desired configuration via the System 6844(RC) menu if necessary Software settings must always be set after replacing a function board by using the menu in order that the new function board takes over the parame- ters.
Make all connections to the Function Board. Switch the equipment back on. Configure the Function Board via the System 6844(RC) menu as necessary. Removing Function Boards The following steps are required in order to remove a Function Board from the System: ...
ROUBLESHOOTING System Indicators / Fault Analysis / Troubleshooting The System 6844(RC) provides a variety of indicators for presenting the System status and for problem analysis. This status information can also be used for monitoring the clock sys- tem by means of a supervisory management system.
A fall-off signals the loss of synchronization. The action of the relay can be influ- enced by the "SyncOFF Timer" setting (see Chapter 5.3.6 SyncOFF Timer - Delayed Change of Sync. Status). System 6844(RC) - V03.00 139 / 157 hopf Elektronik GmbH Nottebohmstr.
a Function Board is in an undefined condition (program malfunction) then this is recognized by the Control Board 6844(RC) and the System triggers a system- wide hardware-reset. Bus-Bridge Boards installed in the factory are integrated into the auto-reset circuit and can be replaced by suitable Function Boards without system-internal modifications.
The status of the clock system can be ascertained in a connected System by means of this status (see Chapter 6.3 Data Strings). Systems 6844 without remote interface enables the recording of these data telegrams (e.g. via "hyper terminal“) a long-term analysis of the reception status.
Verification of the System byte referring to correct selection of the Sync.-Source (Sync.-Mode) 142 / 157 System 6844(RC) - V03.00 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com...
Page 143
Antenna faulty The GPS receiver of Control Board 6844(RC) is faulty A building change has had an effect on the antenna equipment (e.g. shad- ing of the antenna caused by subsequent building installation, or the laying...
Time has drifted because the System has been running in quartz mode for a long period Local time to UTC time offset differs from the time offset configured in the System 6844(RC) Fault on Control Board 6844(RC) UTC Time Description ...
Providing a detailed description of the error and the information listed above avoids the need for additional clarification and leads to faster processing by our Support team. System 6844(RC) - V03.00 145 / 157 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com...
AINTENANCE Maintenance / Care The System 6844(RC) is generally maintenance-free. The following points should be noted if it is necessary to clean the System 6844(RC): 10.1 General Guidelines for Cleaning The following must not be used to clean the System 6844(RC): ...
ECHNICAL Technical Data 11.1 Specific Technical Data for 3U / Table-Top / Wall Technical Data - System 6844(RC) 3U / Table-Top / Wall Housing construction: Sheet steel / aluminium, closed 3U and Table-Top with ventilation openings for convec- tion on top and bottom...
ECHNICAL 11.2 Specific Technical Data for 1U Technical Data - System 6844(RC) 1U Housing construction: Sheet steel / aluminium, closed Housing measurement: Chapter 1.2.3.1 19 Inch Rack 1U/84HP Housing protection class: IP20 Protection class: I, with PE connection. Additional earth screw for cables up to 16mm Cooling: Active cooling by fans, temperature-controlled.
> 74% Function display LED green LED green LED green (Power LED) 11.3 General Technical Data 6844(RC) General Data 6844 Operation: o Via keypad and LCD-Display (illuminated) 6844RC (Option) Manangement Console via serial interface with COM0 or separated optional remote interface ...
Via BNC connector, female Antenna connection: For active antennas, U = 5V DC Antenna power fed via Board 6844(RC) BNC connector Backup Clock Maintenance free buffering at least 3 days / typ. 7 days / max. 10 days Time offset (accuracy) <...
Activation resp. deactivation of the LAN MNG board for 6844RC Configuration of the LAN board 7270 / 7271 / 7272 Configuration of the slave line board 7406 Configuration of the frequency board 7530 System 6844(RC) - V03.00 153 / 157 hopf Elektronik GmbH...
200ms. One hour before changeover from CEST to CET, or vice-versa, the 16 second mark has a duration of 200ms. DCF77: D = Deutscher (German), C = Long-wave transmitter, F = Frankfurt, 77 = frequency System 6844(RC) - V03.00 155 / 157 hopf Elektronik GmbH...
Page 156
Start bit of the coded time information P1, P2, P3 Test bits 156 / 157 System 6844(RC) - V03.00 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com...
The 100 and 200msec. long reductions are represented by logical signal levels. In this digital form the signal can then also be transmitted via a fiber optic cable, for example. System 6844(RC) - V03.00 157 / 157 hopf Elektronik GmbH Nottebohmstr.
