- Page 1 SVT-3100 ACCESS CONTROL CARD READER (SVT19100) User Manual Please read this user manual prior to installing the system, and keep it well for future use.
- Page 2 SVT-3100 ACCESS CONTROL CARD READER - SPECIFICATIONS 100 mm 110 mm Description Mode indicator Infrared receptor Case screw Antenna Technical Parameters Ambient temperature -20 Applicable card type ID/IC card Relative humidity Capacity: maximum 1000 card Standby Current 90mA Sensing distance Operating Voltage DC 14.5V...
- Page 3 INSTALLATION (without the rain guard) Install into the wall Screw hole 50mm Screws (fix with button case) INSTALLATION (with the rain guard) Screw anchors Wall hole Rain cover Screws Screws (fix with rain cover)
- Page 4 WIRING CONNECTION Connect to main Purple Unlock button board module White P3(4+2) Connect to main board module J1 Connect to main board module Lock P8(4+2) Connect to access control Power supply keypad Black DC 14.5V Note: If it is used as stand alone system, disregard the wiring in dashed box.
- Page 5 OPERATION SVT-3100 ACCESS CONTROL CARD READER requires the SVT Remote control for programming. Enter the setting mode Press * and #, then enter XXXX (4-digits admin code) and #. A Di sound indicates entering to the setting mode successfully. Press * to return to standby mode. (No operation in 20 seconds will return automatically).
- Page 6 Add user card In the setting mode: Press 1. Di sound indicates it is in the adding user card mode. Enter the last 6-digits of a new card number. If Di sound is heard, it indicates the adding is successful. Or swipe the new card instead of adding the card numbers.
- Page 7 Set building number and machine number In the setting mode: Press 3, a Di sound is heard. Enter 6 digits (4-digits building number and 2-digits machine number), press # with a Di sound. It indicates the setting is successful. Press * to return to standby mode. No operation in 30 seconds will return automatically.
- Page 8 The design and specifications of this user manual can be changed without any notification to the user. All copyright and interpretation rights are reserved to SVT Innovations Inc.
