MTB-7300
7"Wide TFT LCD Color Rear View System
USER GUIDE

Advertisement

loading
Need help?

Need help?

Do you have a question about the MTB-7300 and is the answer not in the manual?

Questions and answers

Summary of Contents for MTB Cameras MTB-7300

  • Page 1 MTB-7300 7”Wide TFT LCD Color Rear View System WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN To reduce the risk of electric shock do not remove cover(or back) No user serviceable parts inside. Refer servicing to qualified service personnel. The lightning flash with arrowhead symbol,within an equilateral triangle,is intended to alert the user to the presence of uninsulated "dangerous voltage"...
  • Page 2 Contents Checking the main unit and supplied accessories Features / Technical Specifications Checking the main unit and supplied accessories MTB-7300 MONITOR Operations Using MTB-7300 in the Vechile Sun Shield System Wiring MTB-10C Rear View Camera 13~14 Features / Technical Specifications...
  • Page 3 Operations Accessories Menu Control Keys Power Key Power Camera & Input Cable - When POWER OFF (which means STANDBY state), the LED has RED color. - After POWER ON, the LED in RED color is turned off and all LEDs light in GREEN color. - After POWER ON, the LAST CHANNEL saved from its last operation is displayed on the monitor.
  • Page 4 How to set up the functions of the Menu on OSD DIMMER Key FUNCTION - The brightness is adjusted manually at the POWER ON mode, if DIMMER is selected in OSD set-up. FUNCTION Pressing of DIMMER Key in this condition makes the change of brightness responding on every manual operation of the Key.
  • Page 5 CAMERA PICTURE CAMERA PICTURE CA1 SCAN 0 ~ 9 CONTRAST 50 (0-100) NOR/MIR CA2 SCAN 0 ~ 9 BRIGHT 50 (0-100) NOR/MIR CA3 SCAN 0 ~ 9 COLOR 50 (0-100) NOR/MIR TINT 50 (0-100) CA1 TRIG 0 ~ 9 CA2 TRIG 0 ~ 9 0 ~ 9 CA3 TRIG...
  • Page 6 CAMERA CAMERA CAMERA CAM MODUS CAM1 N/M NORMAL/MIRROR CA 1 NORMAL/SHUTTER NOR/MIR CAM2 N/M NORMAL/MIRROR CA 3 ON/OFF NOR/MIR CAM3 N/M NORMAL/MIRROR NOR/MIR CAM1 DIST ON/OFF CAM2 DIST ON/OFF CAM / MODUS CAM3 DIST ON/OFF - Display CAM / MODUS set-up Screen by pressing the MENU Key 9 times and locate the cursor at CAM / MODUS by SCAN and/or CA.SEL Keys.
  • Page 7 Using MTB-10C in the Vehicle System Wiring For using MTB-10C on the dashboard ○ After connecting power to the unit through the Cigarette adaptor, press [Power button] on the main unit or on the Remote Control to power on. ○ Set up MTB- 10C with Stand Bracket Kit and fix the Stand Bracket Kit on the dashboard of the car.
  • Page 8 MTB-10C Rear View Camera Specifications Waterproof Aluminium Diecasted Low Illumination Color CCD Camera. Mirror & Normal Image Views IMAGE SENSOR 1/3" Sony Super HAD Color CCD (Compatible with Sharp CCD) EFFECTIVE PIXELS PAL : 320,000 Pixels RESOLUTION 380 TV Lines SYNCHRONIZING SYSTEM Internal VIDEO OUTPUT...
