MultiMax 6DS User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User's Manual
Rev 003
Seite 1 von 24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6DS and is the answer not in the manual?

Questions and answers

Summary of Contents for MultiMax 6DS

  • Page 1 User’s Manual Rev 003 Seite 1 von 24...

  • Page 2: Fcc Notice

    FCC Notice The MultiMax 6ds have been tested and found to comply with the limits for Class A digital devices, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 3 Welcome Congratulations on your purchase of the new MultiMax 6ds! The MultiMax 6ds is the ultimate label and decal production unit, combining high image durability and precision contour cutting into one device. The MultiMax 6ds uses thermal transfer technology. This is a dry transfer printing process that uses heat and pressure to create a durable bond with the resin-based inks and the media.
  • Page 4 1 Setup 1.1 Unpacking the MultiMax 6ds NOTE: Save the shipping box and any other packaging items in case the printer needs to be moved. Do not transport the printer without first completely repacking it in its original packaging. CAUTION: For safety reasons, no fewer than two people should be involved in unpacking the printer.
  • Page 5 From this point on, two people ARE REQUIRED for safety reasons. Lift the MultiMax 6ds from each side, just high enough so the foam blocks can be pulled out from underneath the MultiMax 6ds. FIG 1-3 UNPACKING...
  • Page 6 Position the ramps so the printer can be rolled down from the pallet. Be sure the wheels of the printer are aligned with the ramp legs. FIG 1-4 UNPACKING MULTIMAX 6DS FINAL STAGE 4 Open the front cover and loosen the printer carriage, then remove the foam underneath the carriage, which is protecting the printhead.
  • Page 7 While printing, the printhead cleans itself automatically and at regular intervals. Front Wheels: The front wheels of the MultiMax 6ds are equipped with locking brakes. Secure the brakes, once the MultiMax 6ds is permanently installed, by pressing the locking wheel brake down with your foot.
  • Page 8 USB port: This interface is based on the standards specified in Universal Serial Bus Specifications Revision 1.1. It allows for high-speed bi-directional serial communication between the host computer and the MultiMax 6ds. Cable clamp: These two cable clamps provide a neat path for the communication cables.

  • Page 9: Ideal Operating Environment

    The printer should be located away from windows and doors, preferably within a clean interior room of a building. Check for the following conditions when installing the MultiMax 6ds: Surface must be level without vibration Operating temperature should be stable, between 15 - 27 degrees Celsius (60 to 80 degrees Fahrenheit).

  • Page 10: Connecting The Printer To The Mains

    1.4 Connecting the Printer to the Mains 1.4.1 Grounding (“Earthing”) CAUTION: An insulated ground conductor must be installed as part of the branch circuit that supplies power to the wall outlet to which the printer is connected. The ground conductor must have the same size, insulation material and thickness as the grounded and ungrounded branch circuit supply conductors, but the insulating seat should be green or green with yellow striping.
  • Page 11 When there is no media loaded, the MultiMax 6ds will prompt the user for a media load procedure. When media is loaded, the MultiMax 6ds will measure the media width and check the...
  • Page 12 7. Remove the CD from the CD-ROM drive. 8. Restart the computer. NOTE: When the MultiMax 6ds is connected to a computer for the first time using the USB cable, the computer will detect the printer and ask for the USB driver. The driver is included on the CD containing this user’s manual.

  • Page 13: Media Handling

    1.6 Media Handling 1.6.1 Loading media The MultiMax 6ds is designed to work with rolls of media, not sheets. It is advised to use cotton gloves while loading the media, otherwise the surface of the media becomes contaminated by oil from fingers, and the beginning of the printout will be unusable.
  • Page 14 If the media is to far from the origin, then the MultiMax 6ds will “Park” the media on the starting point (origin). If it is not loaded straight, it will align it automatically (unless OptiTrac is set to ‘white background).

  • Page 15: Loading Ribbon Cassettes

    1.7 Loading ribbon cassettes 1.7.1 Loading and removing the cassettes The MultiMax 6ds can take up to 5 cassettes. The cassettes can be loaded or removed from the cassette station at any time, even during printing. If the printer is missing a color, then it will give a message on the LCD just before it needs the color.

  • Page 16: Knife Installation

    Knife Installation SAFETY WARNING: The MultiMax 6ds uses razor-sharp vinyl cutting knives. The knife blades may cause serious personal injuries if handled without proper caution. Use extreme care when operating the cutter; and when installing, removing or handling the cutter’s knife blade! 1.8.1 Removing the drag knife...

  • Page 17: Installing The Drag Knife

    1.8.2 Installing the drag knife Remove the aluminum plunger from the plastic knife holder (5) by turning the knurled adjustment knob (3) counterclockwise until the plunger comes out of the holder. Insert the conical, non-cutting end of the knife into the opening in the narrow end of the holder;...
  • Page 18 2.8 Preparing the MultiMax 6ds for long print-outs The MultiMax 6ds has a fixed position at the rear for the rollerguiding of the flange. It is possible that some types of vinyls are not wound up even (e.g. the core sticking out).

  • Page 19: Maintenance And Cleaning

    They are virtually friction-free and require no lubrication. They will, however, collect dust and lint, which may affect the performance of the MultiMax 6ds. Keep the MultiMax 6ds as clean as possible by keeping the front cover always closed. When necessary, clean the unit with a soft cloth dampened with isopropyl alcohol or mild detergent.
  • Page 20 To clean the sensor area, proceed as follows: 1. The front sensor is located on the MultiMax 6ds left side, right next to the pinch roller. The rear sensor is located on the same line as the front sensor but on the rear plate.
  • Page 21 5.1.3 Cleaning the cleaning pad Located on the left side of the MultiMax 6ds is a printhead cleaning pad. The printer cleans the head periodically on this pad. It is possible that after a while some dust will accumulate on this pad. Therefore it is advised to clean this pad from time to time.
  • Page 22 Do not clean the printhead above the printing surface. To clean the printhead, proceed as follows: 1. Power off the MultiMax 6ds. Open up the rear cover and take out the cassette. 2. Use a lint free cloth, or gauze, moistened with isopropyl alcohol.
  • Page 23 Cut a piece of vinyl, the size of the printing surface (1 x 0.14m) and stick it onto the printing surface. Power on the MultiMax 6ds and load the media. Print out a rectangle full width and height, consisting out of two colors app 20% coverage.
  • Page 24 5.2 OPERATING VOLTAGE CAUTION: Before changing the fuse, make sure that the cutter is completely disconnected from its power source. CAUTION: For continued protection against risk of fire, replace only with the same type and rating of fuse: T4.0A, 250V SCHURTER SPT OR EQUIVALENT. The power entry module detects the line voltage and switches automatically between 110V and 230V.
