Summary of Contents for Bertazzoni M45CAFX
- Page 1 Instructions for Use and Installation Coffee Machine M45CAFX...
-
Page 2: Table Of Contents
CONTENTS CLEANING ......17 Cleaning the coffee maker .......17 INTRODUCTION ......7 Cleaning the waste coffee container ..17 Cleaning the drip tray .......17 Symbols used in these instructions ..7 Cleaning the water tank ......17 Letters in brackets ........7 Cleaning the spouts .........17 Troubleshooting and repairs ......7 Cleaning the pre-ground coffee funnel ..17 SAFETY ........7... -
Page 3: Introduction
INTRODUCTION • farm houses; • by clients in hotels, motels and other resi- Symbols used in these dential type environments; instructions • bed and breakfast type environments. Important warnings are identified by these sym- Danger! This is an electrical appliance, bols. -
Page 4: Designated Use
accessories required to make the coffee (the A2. Service door measure for example) in the special holder. Do A3. Coffee guide not rest large objects which could obstruct mo- A4. Waste coffee container vement or unstable objects on the appliance. A5. -
Page 5: Preliminary Checks
icon to exit the selected mode rectives, an omnipolar switch with a minimum contact distance of 3 mm must be installed. B7-B8. icons to scroll forwards or Do not use multiple sockets or extensions. backwards through the menu and display the various modes Important! Safety cutout devices must be included in the mains power supply in compliance... -
Page 6: Built-In Installation
BUILT-IN INSTALLATION Verify the minimum measurements required for correct installation of the appliance. The coffee maker must be installed in a column and the column must be firmly fixed to the wall with commercially available brackets. Important: • Important: all installation or maintenance operations must be performed with the ap- pliance disconnected from the mains electri- city supply. - Page 7 x 16 Position the rails on the sides of the cabinet as Position the appliance on the rails, making sure shown in the figure. Fix with the screws, then the pins are correctly inserted in the housings, extract them completely. If the coffee maker is then fix it with the screws supplied.
-
Page 8: Using The Appliance For The First Time
USING THE APPLIANCE first time, you need to make 4-5 cups of coffee and 4-5 cappuccinos before the appliance gives FOR THE FIRST TIME satisfactory results. • Coffee has been used to factory test the ap- N.B.! Each time you turn the coffee maker pliance and it is therefore completely normal on by the ON/OFF switch (A23), it performs a for there to be traces of coffee in the mill. -
Page 9: Replacing The Filter
pliance begins delivering hot water and the follows: message "PLEASE WAIT... " is displayed. 1. Press the icon (B2) to enter the menu; When delivery stops, the appliance automa- 2. Press the icons (B7) and (B8) until tically displays the basic modes set again. "INSTALL FILTER"... - Page 10 normal taste. You can also choose coffee pressing the previously selected icon within 3 se- with an extra-mild, mild, strong or extra- conds after delivery has finished. strong taste. There is also a pre-ground cof- NOTE 6: When the appliance displays "FILL fee option.
-
Page 11: Changing The Quantity Of Coffee In The Cup
the cappuccino maker for about 30 seconds. ADJUSTING THE COFFEE When delivery stops, the basic modes are di- MILL splayed again. The coffee mill is preset in the factory and should N.B.: The coffee maker may request the not require adjusting. However, if after making operation to be repeated a number of times until the first few coffees you find that delivery is either the air is completely elminated from the hydrau-... -
Page 12: Delivering Hot Water
espresso coffee machines into the funnel. MAKING CAPPUCCINO NOTE 5: If more than one measure of pre-ground (USING THE STEAM coffee is used and the funnel clogs, push the cof- fee down with a knife (fig. 21) then remove and FUNCTION) clean the brewing unit and machine as described in the "Cleaning the brewing unit"... -
Page 13: Cleaning
then holding the cappuccino maker lever firmly the waste coffee container must always be em- in one hand, unscrew the cappuccino maker it- ptied. self with the other, turning it anticlockwise and removing it downwards (fig. 24). Cleaning the drip tray •... -
Page 14: Cleaning The Inside Of The Coffee Maker
Cleaning the inside of the coffee N.B.! If the brewing unit is difficult to in- maker sert, you must first adapt it to the right dimen- 1. Check regularly (about once a week) that the sions by pressing it forcefully from the bottom inside of the appliance is not dirty. -
Page 15: Setting The Language
• Buzzer Changing the length of time the • Contrast appliance remains on The appliance is set by default to go off automa- Setting the language tically 30 minutes after the last coffee has been To change the language on the display, proceed made. -
Page 16: Changing Coffee Temperature
activate the auto-start function until "AUTO of red squares on the test strip (for example, START" is displayed. if there are 3 red squares on the test strip, • Press the icon (B9) to confirm. select the message "WATER HARDNESS 3" . symbol appears on the display. -
Page 17: Resetting Default Values (Reset)
then add water up to the MAX level marked fault values; on the water tank. Position a container with a capacity of about 2 litres under the hot water Statistics spout. This displays statistics relating to the machine. • Press the icon (B9). -
Page 18: Water Filter
• Press the icon (B6) once to exit the fun- ELECTRICAL CONNECTION ction or twice to exit the menu. (UK ONLY) Water filter A) If your appliance comes fitted with a plug, it will incorporate a 13 Amp fuse. If it does not fit your For instructions on the water softener filter, see the socket, the plug should be cut off from the mains section "INSTALLING THE FILTER". -
Page 19: Electrical Connection
ELECTRICAL CONNECTION (AUSTRALIA ONLY) This appliance is designed to operate on a power supply voltage of 220-240V, single phase and is fitted with a 10A, 3 pin plug. Before making the connection, make sure that: 1) The electrical system is able to withstand the load of the appliance (see data label). -
Page 20: Displayed Messages
DISPLAYED MESSAGES DISPLAYED MESSAGE POSSIBLE CAUSE REMEDY FILL TANK • The water tank is empty or • Fill the tank with water positioned incorrectly. and/or insert it correctly, pushing it as far as it will GROUND TOO FINE ADJUST • The grinding is too fine •... - Page 21 DISPLAYED MESSAGE POSSIBLE CAUSE REMEDY • The "pre-ground coffee" • Extract the appliance and ADD PRE-GROUND COFFEE function has been selec- place pre-ground coffee in ted without placing any the funnel. pre-ground coffee in the funnel. • The funnel (A21) is bloc- •...
-
Page 22: Troubleshooting
TROUBLESHOOTING Below is a list of some of the possible malfunctions. If the problem cannot be resolved as described, contact Customer Services. PROBLEM POSSIBLE CAUSE REMEDY The coffee is not hot • The cups were not pre- • Warm the cups by rinsing heated. - Page 23 If the appliance requires a service. • If you need spare parts. BERTAZZONI GROUP ACN 069 686 326 650 Bridge Road, Richmond, Victoria 3121 Service & Spare Parts: 1300 748 308 Bertazzoni After Sales Service - P.O. Box 543 SOMERTON VIC 3061 Email: service@bertazzoni.com.au"service@bertazzoni.com.au...
