Page 1: User Manual
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) DS-8104HMI-M(/XX) Embedded Mobile Net DVR User Manual (V1.20.00) - 1 -... - Page 2 User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) Statement Please kindly note and understand that there may be misprints and technically inaccurate description. The contents of this manual are subject to change without notice from time to time accompanying with the release of new version. The listed products or programs will be improved or renewed whenever necessary.
-
Page 3: Table Of Contents
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) Production Description ....................................6 Overview ......................................6 Key Functions ..................................... 6 Installation help......................................9 Check device and accessories ................................9 Interface Description ..................................9 J1, J2, J3 and Aviation Connector ..............................11 SD and SIM/UIM Installation................................ - Page 4 User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) Backup Recorded Files ..................................29 4.7.1 USB Backup .................................... 29 4.7.2 SD/SDHC Card Backup ................................30 4.7.3 Backup File Playback ................................30 Parameters Setup Guide ....................................32 Basic Setting ..................................... 32 5.1.1 Administrator and Password ..............................
- Page 5 User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) PTZ ........................................45 Exceptions ......................................47 Mobile Setup ....................................48 5.8.1 Boot & Halt Setup .................................. 48 5.8.2 GPS Setup ....................................49 5.8.3 PPP settings ................................... 50 5.8.4 Server Login Setup ................................. 50 Utilities ........................................
-
Page 6: Production Description
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) 1 Production Description Overview Embedded digital net recorder DS-8104HMI-M(/XX), which is an excellent product designed for vehicle surveillance. It supports local recording of SD/SDHC card, driving information recording, voice talk, GPS, wireless, alarm triggering and etc. This mini mobile DVR with lower power consumption is very easy to install. The chassis is made from aluminum and designed according to the requirement of thermal dissipation. - Page 7 User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) · Support video parameters dynamic setting; · Support OSD and LOGO. Feature of local process Video recording · Variety of recording models: Schedule recording, manual recording, alarm recording, etc; · Support SD card storage; ·...
- Page 8 User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) · Audio preview and screen capture at client software; · PPP enabled; Client developing · Network protocol provided for platform system development. · SDK provided for client development. · DEMOs with source code provided. - 8 -...
-
Page 9: Installation Help
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) 2 Installation help 2.1 Check device and accessories Please check carefully according to the list inside once you get it. 2.2 Interface Description DS-8104HMI-M(/XX) front panel is shown as below: (Note: the descriptions are subject to the physical product) Fig 2.1 DS-8104HMI-M front panel Interface Description... - Page 10 User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) Record Recording indicator. The light will turn green when recording. SD card socket; Connect to USB devices, support USB 2.0; Connect to ETHERNET devices; DEBUG Device debug port, connect with special cable in accessories box; SIM/UIM SIM/UIM card socket, the yellow bar is for pushing card out;...
-
Page 11: J1, J2, J3 And Aviation Connector
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) Video&Audio input/output Dc in, KEY and KB port Alarm in/out, RS485 2.3 J1, J2, J3 and Aviation Connector Detail description for interface J1, J2 and J3: Fig 2.3 J1, J2 and J3 interfaces Note: 1. -
Page 12: Sd And Sim/Uim Installation
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) 2.4 SD and SIM/UIM Installation Note: When install SD card or SIM/UIM card, please make sure the operation is under power off, or it will give rise to SD card or SIM/UIM card damage. 2. -
Page 13: Key Ignition Switch Connection
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) 2. SIM/UIM card installation (1) Use a pin to push the yellow bar besides the SIM/UIM slot and eject the card board; (2) Put the card on the board; (3) Insert the card board into the slot. 2.5 KEY Ignition Switch Connection Note: 1. -
Page 14: Connection For Time-Delay Shutdown
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) 2.5.1 Connection for Time-Delay Shutdown Connect DC+ and DC- to power supply (battery) positive and negative poles, connect KEY interface to the vehicle ignition switch for DVR function of vehicle ignition startup and time-delay shutdown. -
Page 15: Connection For Auto Power On-Off
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) Note: Please contact the vehicle battery manufacture for the information on the voltage polarity. 2.5.2 Connection for auto power on-off Connect DC+ and KEY+ to the vehicle batteries positive pole and DC- and KEY- to the vehicle batteries negative pole for the DVR auto on-off function. - Page 16 User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) Alarm Output connection: DS-8104HMI-M(/XX) series mobile DVR is applied closed signal to trigger the alarm output. That means when alarm output is triggered, the Alarm OUT and GND will be connected status, that means user must connect alarm device with power supply.
-
Page 17: Operation Guide
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) 3 Operation Guide 3.1 Wire Control Name Description POWER Reserved Reserved Numeric Input number, upper and lower case, symbol, and Keys Chinese character. 1. Enter the edit state, and then delete the EDIT character in the front of the cursor;... - Page 18 User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) Direction Up [], Down [], Left [], Right []: Keys 1. In menu mode, moving the activity frame by press [] & [], and selecting the data items by press [] & []; 2.
-
Page 19: Menu Description
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) 3.2 Menu Description 3.2.1 Menu items Item Option Item Option Item Option Unit Name Select Camera Device ID Name & Position Require Password Brightness, Contrast, Hue, If SD full Overwrite /Stop Recording Screen Saver Saturation Stream Type, Resolution, Bit Rate Type, Max Bit Rate,... -
Page 20: Menu Operations
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) Copy to Camera Save Parameters Restore Parameters Boot & Halt Upgrade Add & Del User SD Card User Password & Verify Mobile Utilities Stop Alarm Out Default & Set Right Reboot IVMS Power Off View Log... - Page 21 User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) Fig 3.3 Fig 3.4 There is a rectangular box in the main menu interface, which is referred to as “Activity Frame”, you can move it from one icon to another by pressing [ ] or [ ] on the IR control.
-
Page 22: Input Method
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) iv. Press [ENTER] or [ESC] to exit edit. d) Button: Execute a special function or enter into next sub-menu. For example, press “Policy” button to enter into sub-menu. Press [Confirm] to save parameters and return to parent menu. -
Page 23: Basic Operation Guide
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) 4 Basic Operation Guide Note: The user must have the appropriate rights for basic operations described in this chapter. The following Fig.4.1.are login prompt boxes: In this box, you can use [ ] and [ ] to select one username, then press [ ]to move to password. After entering the password, please press [ENTER] to exit the password box and press confirm to enter the menu. -
Page 24: Preview
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) 4.2 Preview The preview interface will show up after the device started up. The date, time, channel name and GPS info (Enable GPS function) can be seen in the preview interface, if you want to reset them, please refer to the section 5.2.3 OSD Setup. - Page 25 User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) their user rights. Modify password for the users created by admin: For example, a user named “user” (The method of adding and deleting user please refer to section 5.1.2),please modify the password as follow: Step 1: Enter the main menu and select “User”...
-
Page 26: Ptz Control
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) 4.4 PTZ Control Note: The user must have the “PTZ Control” right. Under the main menu mode, press the “PTZ” to enter the PTZ control interface. PTZ control keys description: Direction control keys:[ ],[ ],[ ],[ ];... -
Page 27: Playback
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) Exit manual record: Press[ESC] key to exit manual record and enter preview mode. Press[MENU]key to enter main menu. Press[Play]key to enter into playback menu. Press[PTZ]key to enter PTZ control mode. 4.6 Playback Note: The user must have “Playback”... - Page 28 User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) In the playback interface, you can set search channels, record type, time section, and select “Search” button. DVR will search and list the matched files. (Fig.4.6) If the matched files are more than8, you can use “Page No.” to select page. In the file list box, use [ ], [ ]keys to move the scroll bar to the file, press [ENTER]key to playback the file.
-
Page 29: Backup Recorded Files
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) 4.7 Backup Recorded Files 4.7.1 USB Backup Note: The user must have “Playback” right. Please connect with backup devices first, such as USB flash, USB HDD and SATA device. Please enter the layback interface to apply the backup operation. (Fig.4.9) There are two methods of backup: 1. -
Page 30: Sd/Sdhc Card Backup
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) camera is selected, press [EDIT]to switch “×”and”√” ). Secondly, select “Rec. Type” and set “Date” and “Period”. Lastly, move the “Active Frame” to “Start Backup”, and press [ENTER]to start backup. If there is no file in the selected period, after pressing [ENTER] will back to playback interface. Note: 1. - Page 31 User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) - 31 -...
-
Page 32: Parameters Setup Guide
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) 5 Parameters Setup Guide Note: only the users have “Parameters Setup” right can set the parameters. You must reboot the DVR to make the new parameters take into effective, when the following parameters are modified and saved. -
Page 33: Add And Delete User
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) Step 3: Use [ ],[ ]key to move “Active Frame” to password edit box, input the new password. Move “Active Frame” to “Verify password” edit box, input the verify password. Then choose the “Confirm” button, the password will be saved and taken into effective. Note: When the “Active Frame”... -
Page 34: Unit Name And Device Id
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) “Remote Rights”: Remote rights define the rights of operating by IE or Client Server. PTZ control: Remote control PTZ; Record: Remote manual start/stop recording; Parameters setup: Remote setup the DVR parameters; ... -
Page 35: Local Preview Setup
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) Unit name is the name of DVR; it can be modified according to the requirement of monitoring. For example, it can be named as the car license number to facilitate the search of backup files. -
Page 36: Video Parameters Setup
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) In “Display” menu, you can setup DVR system date and time.(Fig.5.6) In “Image Setup” menu (Fig.5.7), you can setup time display position in the image. Move “Active Frame” to “Position” button on the right side of “OSD” and enter setup image, you can use[ ],[ ],[ ],[ ]keys to move the OSD position. -
Page 37: Preview Properties
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) NTSC). Firstly, move the yellow pane to your hope position and press[EDIT]key, the yellow pane will be turned into red, then you can use[ ]to expand downward ,[ ]to shrink upward,[ ]to expand rightward,[ ]to shrink leftward. After you make sure the red mask area, press[EDIT]key to save the mask area. The area will be blacked in the preview image.(Fig.5.9) Press[ESC]key to cancel the mask area. -
Page 38: Alarm Setup
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) Switch time: That is image preview switch time. You can use [ ] or [ ]keys to select switch time. There are many options, including “5 Seconds”, “10 Seconds”,”20 Seconds”, “30 Seconds”, “1 Minutes”, “5 Minutes”... - Page 39 User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) External alarm input setup: Select one alarm input from 1,2,3,4, and then choose an alarm type from “Normal Open” and “Normal Close” according to the sensor type. External alarm input setup includes alarm in handling and alarm in schedule. Alarm in handling includes record camera, PTZ linkage, trigger alarm out, etc. Fig.5.13 Fig.5.12 You can select channels to record for each alarm input.(”“...
-
Page 40: Motion Detection Alarm
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) In “Handle Method”, you can also setup “Audible warning”, “Upload to Center” and “Trigger Alarm Out”. The alarm in schedule is in “Alarm In Handling” menu. Note: The schedule is settled by day, you can copy this to the other days. The alarm in parameters can be copied to other alarm in channels in “Alarms”... - Page 41 User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) You can use [PTZ] key to set the whole screen as motion area, and multi motion areas can be defined. Press [A]key to clear all motion areas. The minimum area is one panel. After you setup the areas, press [ENTER] key to return “Image Setup”...
-
Page 42: Video Loss Alarm
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) 5.3.3 Video Loss Alarm When the video cable or camera has something wrong, the video image is lost. If you enable video loss alarm, in such case, DVR will make alarm. In “Image Setup”... -
Page 43: Recording Parameters Description
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) Before the recording parameters you need to decide whether “Overwrite” or “Stop Recording” when SD is full. If you select “Overwrite”, when SD in DVR are full, DVR will overwrite the earliest recorded files and continue recording. If you select “Stop recording”, when SD is full, DVR will handle it as “SD Full” exception, please refer to chapter 5.17 for exception menu. -
Page 44: Network Parameters
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) All Day, Rec. Type: If you need to record 24 hours, you can enable “All Day” option and select a record type. Period: If you do not need record all day or you need to record different types in different period, there are 4 time periods for one day, and each time period can select start time, stop time and different record type. -
Page 45: Ptz
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) Gateway: when the mobile DVR connects to server through a wireless router or communicates in different network segments, you need to setup the gateway Multicast IP: it is one D-class IP address, among 224.0.0.0 to 239.255.255.255. We suggest using 239.252.0.0 to 239.255.255.255. If you do not use multicast function, you do not need to set. - Page 46 User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) Fig.5.21 Fig.5.22 The parameters of adding cruise point are: Cruise No: 1 to 16; Preset: 1 to 128, please ensure the preset point has already been defined. Dwell Time: the dwell time on the preset point; ...
-
Page 47: Exceptions
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) Fig.5.23 Fig.5.24 5.7 Exceptions The exceptions can be handled include: SD card full, SD card error, illegal access, IP address conflict, network failure , NTSC/PAL differ and speed limit, etc. The parameters can be set in “Exceptions” menu. -
Page 48: Mobile Setup
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) You can select more than one handle methods. For example, if you choose exception type as “SD card Error”, you can select “Audible Warning” and “Upload to Center”. When the SD card has an error, the DVR will warning and the center host PC will receive a warning message. -
Page 49: Gps Setup
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) If you have directly connected the positive pole of DVR KEY to vehicle battery (Please refer to section 2.3.3), you can also select auto work function. The auto work time can be set in “Boot & Halt” menu. The device will auto power on/off according to the setup time. ... -
Page 50: Ppp Settings
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) 5.8.3 PPP settings For DS-8104HMI-M, there are 3 options of wireless modem, including WCDMA, EVDO(cdma2000), TS-SCDMA. In this menu, user can set the parameters of the build-in module for the wireless network transmission. The menu is shown in Fig 5.29: The default option is None, the module type can be distinguished by the device name: Device Name Module Type... - Page 51 User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) The WVS login interface is shown in Fig.5.30: Used For: there are 4 options for the network environments: CDMA/EDGE/GPRS, 3G, WLAN, LAN. Server IP: input the WVS server static WAN IP. Port: should be as same as the client port of server, the default is 5660.
-
Page 52: Utilities
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) 6 Utilities The “Utilities” menu is used for day-to-day management and maintenance of DVR. Including “SavePara” ,”RestorePara” ,”Upgrade”, ”SD Card”, “Stop Alarm Out”, “Reboot” ,”Power Off” ,”View Log” and “System Info”. The “Utilities” menu is shown in Fig.6.1. 6.1 Save Parameters Save current parameters to device FLASH, this change will take effective after reboot. -
Page 53: Upgrade
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) 6.3 Upgrade You can use this function to upgrade the firmware. Please confirm the language is matched. Press “Upgrade” icon, in the pop-up dialog, you can select either “FTP” or “USB” upgrade mode. (Fig.6.4) If you select “FTP”... -
Page 54: Clear Alarm Out
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) 6.5 Clear Alarm Out Clear the alarm output manually. 6.6 Reboot Reboot DVR 6.7 Power Off Not available for mobile DVR. 6.8 View Log After enter into the “LOG” menu, you can check the log(Fig.6.7) Press[ ]key on the front panel to view all the log, this will list the earliest 2000 record log. -
Page 55: System Information
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) get Status, Net Alert On, Net Alert Off, Net Reboot, BiComStart(Start Voice Talk), BiCom Stop(Stop Voice Talk), Net Upgrade, Net File Play, Net Time Play, Net PTZ and so on. For alarm major type, the minor type includes: External Alarm In, External Alarm Out, Motion Detect Start, Motion Detect Stop, View Tamper Start, View Tamper Stop and so on. -
Page 56: Appendix A Sd Capacity Calculation
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) Appendix A SD Capacity Calculation Calculate total capacity needed by each DVR according to video recording (video recording type and video file storage time). Step 1: According to Formula (1) to calculate storage capacity that is the capacity of each channel needed for every hour, unit Mbyte. - Page 57 User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) ×a% In the formula: a% － Alarm occurrence rate For example: According to the above formula, if the bit rate type is FIXED, for different bit rate, the file size of ONE channel in ONE hour is: Bit Rate(Max Bit Rate(Max Bit Rate(Max...
-
Page 58: Appendix B Ethernet Connect Cable Made Method
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) Appendix B ETHERNET Connect Cable Made Method Material and tool: One twist cable (8 pin, the length can be defined as to the actual demand, but must be within 100m), 2 standard RJ45 head, one tool for RJ45. Suggestion: have a network cable test tool to test each cable made. -
Page 59: Appendix C Specifications
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) Appendix C Specifications Model DS-8104HMI-M(/XX) Operating System Embedded RTOS Video Compression Standard H.264 Preview Resolution PAL:704×576(4CIF);NTSC:704×480(4CIF) Playback Resolution 4CIF(6fps)/DCIF(12fps)/2CIF(15fps)/CIF(fps)/QCIF(fps) Video Input 1/4-ch (1.0Vp-p,75Ω),PAL/NTSC adaptive Video Output 1-ch (1.0Vp-p,75Ω),PAL/NTSC optional Frame Rate PAL:1/16—25fps;NTSC:1/16—30fps Bit Rate 32Kbps～2Mbps(Self definition)8Mbps MAX... - Page 60 User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) Operating Temperature -10℃～+55℃ Humidity 10％～95％ Dimensions 155mm×45mm×105mm Weight About 1Kg Device Control Special wire control for mobile DVR - 60 -...
-
Page 61: Appendix D Faq
User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) Appendix D FAQ Q: why a new machine has “di-di-di-di” voice warning after boot? A: Reason1: there is no SD in DVR Reason2: the SD is not initialized Reason3: SD is broken If do not need the SD, please go to the exception settings menu, disable the voice warning of “SD error”... - Page 62 User Manual of DS-8104HMI-M(/XX) Series Mobile Net DVR (V1.20.00) 255.) If it still does not work after repeating many times. Please check the reasons: 1. Check the battery’s positive and negative polarity 2. Check the battery’s power 3. Make sure the remote controller is not tampered. 4.
