The trademarks mentioned in the manual are legally registered to their

respective companies.

Notice

The written content provided with this product is the property of Huperlab.

No part of this manual may be reproduced, copied, translated, or transmitted in

any form or by any means without Huperlab's prior written permission.

Specifications and features are subject to change without prior notice.

Product Manual Classification

In order to assist in the use of this product, Huperlab has categorized the user

manual in the following:

For detailed product information and specifications, please carefully read

the "Product User Manual".

For detailed information related to Huperlab's unique features, please go

to "Technology Guide" section on Huperlab's website to read or download

the information you need.

For more product details, please click onto Huperlab's website at

www.huperlab.com

huperVision 1.51 Hybrid DVR Quick Start Guide

- 1 -

Table of Contents

Need help?

Do you have a question about the 4416SL+ and is the answer not in the manual?

Questions and answers

Summary of Contents for HuperLab 4416SL+

Page 1 Specifications and features are subject to change without prior notice. Product Manual Classification In order to assist in the use of this product, Huperlab has categorized the user manual in the following: For detailed product information and specifications, please carefully read the "Product User Manual".
Page 2: Table Of Contents
huperVision 1.51 Hybrid DVR Quick Start Guide huperVision 1.51 Hybrid DVR Quick Start Guide Table of Contents Table of Contents .....................2 Package Contents....................3 System Requirements..................4 Installation......................5 Simple Steps to Start Recording ..............9 Simple Steps to Playback Recordings ............13 How to connect IP Cameras / Video Servers ..........16 How to use Motion Detection .................20 How to use Missing &...
Page 3: Package Contents
huperVision 1.51 Hybrid DVR Quick Start Guide Package Contents Audio Ports Video Ports Connector Product CD& Watchdog Connector Product Model Quick Guide Cable 8 Port 6 Port 4 Port 8 Port 6 Port 4 Port Port 4404SL+ 4408Q-PCIe 4416SL+ (Flex-Channel) 4416SL+-PCIe (Flex-Channel) 4604Q-PCIe...
Page 4: System Requirements
huperVision 1.51 Hybrid DVR Quick Start Guide System Requirements The System requirements depend on the total performance of display and recording frame rates. Please refer to the configuration chart below. Resolution Display Recording Min. CPU Min. RAM 720x480 On-Board VGA E2180 320x240 640x480...
Page 5: Installation
huperVision 1.51 Hybrid DVR Quick Start Guide Installation 1. Insert CDROM You will see the Auto Run start up like following Picture 2. Press [Install huperVision] Button Now start huperVision installation program, The first dialogue box pop-out and please select your installation languages and press [OK] button Please wait until the following dialogue appears.
Page 6 huperVision 1.51 Hybrid DVR Quick Start Guide 3. Now you see the License agreement, Please take a look if you want, or directly select [I accept the terms in the license agreement] then press [Next] button to proceed. 4. The destination folder selection appears. Please directly press [Next] button to use the default folder.
Page 7 huperVision 1.51 Hybrid DVR Quick Start Guide 5. Selection of Capture Card Driver. Please select HMCap2R/HMCap3R to fit all series of huperVision capture cards. If you want to setup a 32CH machine, please select 32ch Version which will use dual VGA output. Meanwhile, select correct Video standard (NTSC/PAL) and press [Next] to proceed.
Page 8 huperVision 1.51 Hybrid DVR Quick Start Guide 7. When you see the Finish window, press [Finish] button, and probably you need a reboot to initial the huperVision site server program. - 8 -...
Page 9: Simple Steps To Start Recording
huperVision 1.51 Hybrid DVR Quick Start Guide Simple Steps to Start Recording Please follow the steps below to start recording. 1. After reboot (Manually), huperVision site server program is launching. You will see a pop-up warning message; this is a notification that you have not specified a recording path to record.
Page 10 huperVision 1.51 Hybrid DVR Quick Start Guide 4. Press [Browser…] button in the Add Storage dialogue box. 5. You can create a new folder in drive E; e.g. E:\DATA (D:\DATA indicates there is a DATA folder under Drive D.) So, you select the Drive E icon and press the button [Make New Folder] And input the new folder name “DATA”, then press [OK].
Page 11 huperVision 1.51 Hybrid DVR Quick Start Guide 6. The result will be shown when you back to the Add Storage dialogue box. Please press [OK] button to save the decision. Note. Please keep the all 16 cameras be checked even if you don’t have that much cameras.
Page 12 huperVision 1.51 Hybrid DVR Quick Start Guide 7. After Create the folder and press the [OK] button of the Preference page. Congratulations! You are start recording videos. 8. The R LED turns green at upper right side, indicates that available channels is recording now.
Page 13: Simple Steps To Playback Recordings
huperVision 1.51 Hybrid DVR Quick Start Guide Simple Steps to Playback Recordings 1. Launch the huperVision Record Player program by clicking the icon 2. You will see the following full screen program to cover the current huperVision Live view. Don’t worry, the Live View and recording task is still working at the background.
Page 14 huperVision 1.51 Hybrid DVR Quick Start Guide 4. After you select the channel you want to playback, it shows a list of time mark for today’s recording. Please select a Time mark to load the Video records. 5. All the video available channels will show the first Image in the Video split area, after the video load progress bar running to the end.
Page 15 huperVision 1.51 Hybrid DVR Quick Start Guide Press the [User’s Manual] on the Installation CDROM auto run program. You will be able to open the Document. Before you load this document, please ensure your system have already Acrobat Reader program installed. The Acrobat Reader program is included in the Installation CDROM E:\English\Doc\aar.exe - 15 -...
Page 16: How To Connect Ip Cameras / Video Servers
huperVision 1.51 Hybrid DVR Quick Start Guide How to connect IP Cameras / Video Servers In huperVision V1.5, huperVision start to support IP cameras as Video source for recording and intelligent analyze. Let’s see How to connect IP cameras step by step. 1.
Page 17 huperVision 1.51 Hybrid DVR Quick Start Guide 5. The IP camera setting page pup-up now, please click [Search] button. 6. It will take a while to search all the supported-searchable IP cameras in the range of local network. Let’s wait for the progress bard running to the end. 7.
Page 18 huperVision 1.51 Hybrid DVR Quick Start Guide 8. After input necessary information, please click the [OK] button to save the settings. 9. Press another [OK] button to finish this connection setting. - 18 -...
Page 19 huperVision 1.51 Hybrid DVR Quick Start Guide 10. Back to the Camera page, click the down button to assign the IP camera for IP1 connection. Note. A Star Sign is marked leading the IP camera list to indicate this IP camera has already been assigned in huperVision system.
Page 20: How To Use Motion Detection
huperVision 1.51 Hybrid DVR Quick Start Guide How to use Motion Detection Motion Detection is the basic detection of huperVision, It works like a motion sensor but with more powerful parameters to control the precision of detection result. 1. Click the [Hammer] button and select [Preference…] to open the Preference window.
Page 21 huperVision 1.51 Hybrid DVR Quick Start Guide 4. You can find the Motion Detection feature in the list of “Detect Events by:” 5. Check the Motion Detection feature and press [OK] button to take effect. 6. Or, you can press the [Apply To…] Button to select which other cameras you want to enable Motion Detection.
Page 22 huperVision 1.51 Hybrid DVR Quick Start Guide 7. BTW, you can also press the [Settings…] Button to bring up the detailed Motion Detection settings, like Adjustment of Sensitivity and Noise Tolerance, Ignore Smaller or Larger objects and mask out some area which you don’t want to detect motion.
Page 23: How To Use Missing & Left Object Detection
huperVision 1.51 Hybrid DVR Quick Start Guide How to use Missing & Left Object Detection Missing & Left Object Detection is the other way against Motion Detection. Motion Detection detects movement in a Video, but Missing & Left Object Detection monitor all the moving object in the video and only alarm when the moving object stops moving in the video for a while(Left Object).
Page 24 huperVision 1.51 Hybrid DVR Quick Start Guide 4. You can find the Missing & Left Object Detection feature in the list of “Detect Events by…” 5. Check the Missing & Left Object Detection feature and press [OK] to take effect. 6.
Page 25 huperVision 1.51 Hybrid DVR Quick Start Guide 8. After input the Detection time, please press (OK button) to take effect. 9. If you want to do some Mask to avoid some area been detected, please refer to the “How to do Masks in Detection Features” session in this Quick Start Guide.
Page 26: How To Use Secure Zone Detection
huperVision 1.51 Hybrid DVR Quick Start Guide How to use Secure Zone Detection Secure Zone Detection is the Advanced Object Based version of Motion Detection. Motion detection use an algorithm to analyze the changes / difference area in a video, it has some limitation of precision when multiple objects existed on the video.
Page 27 huperVision 1.51 Hybrid DVR Quick Start Guide 4. You can find the Secure Zone Detection feature in the list of “Detect Events by:” 5. Check the Secure Zone Detection and press the [Settings…] button to get in the settings page. 6.
Page 28 huperVision 1.51 Hybrid DVR Quick Start Guide 7. Now you can use your mouse to drag an area or multiple areas in the Video. 8. Check this item to show the detection area in Live Video, No matter you check it or not, the Secure Zone detection still works unless you disable this feature in camera page.
Page 29 huperVision 1.51 Hybrid DVR Quick Start Guide 11. If you want to remove all the area in the video, you can press this button to remove them all. Check this function to enable ignore smaller object, you can either adjust the value against object’s width and height counted by pixel, or you can click the hand icon to drag the size directly on video by mouse.
Page 30: How To Use Flow Counting Feature
huperVision 1.51 Hybrid DVR Quick Start Guide How to use Flow Counting feature Flow Counting is designed to count moving object cross user defined line, 2 lines can be applied on 1 video / camera. Since this detection should really detect object touch the line, so, at least 7 FPS video should be used to fit most situation, otherwise, frame interval might cause object jump over the counting line and not be counted.
Page 31 huperVision 1.51 Hybrid DVR Quick Start Guide 4. After extend this Criteria settings, you can use mouse to drag detection lines on the video area. 5. For example we draw 2 lines on the video area for flow count detection. Click to select the line on video and click this button to toggle detect direction, you can either detect single direction or both in/out...
Page 32 huperVision 1.51 Hybrid DVR Quick Start Guide 10. As the result of Flow Counting feature, you can see the 2 detection lines with count numbers on the Live video. 11. You can refer to the “How to Ignore Smaller/Larger Objects in detections”...
Page 33: How To Use Virtual Fence Detection
huperVision 1.51 Hybrid DVR Quick Start Guide How to use Virtual Fence Detection Virtual Fence Detection is the detection to alarm when objects cross a forbidden line. Maximum 5 lines can be defined in this detection. 1. Like the other detection settings, you can enable and call up the Virtual Fence Detection setting pages.
Page 34 huperVision 1.51 Hybrid DVR Quick Start Guide 5. After extend this Criteria settings, you can use mouse to drag detection lines on the video area. 6. For example we draw 2 lines on the video area for Virtual Fence detection. Click the line on video to select it and click this button to toggle detect direction, you can either detect single direction or both directions.
Page 35: How To Ignore Smaller / Larger Object Size In Detection
huperVision 1.51 Hybrid DVR Quick Start Guide How to Ignore Smaller / Larger Object Size in detection Ignore Smaller Object and Ignore Larger Object function exists in most huperVision’s detection settings. Ignore smaller object like mice, cockroaches or smaller animals if you want to detect and alarm human or vehicles.
Page 36: How To Do Masks In Detection Features
huperVision 1.51 Hybrid DVR Quick Start Guide How to do Masks in Detection Features Mask feature exist in some detection e.g. “Motion Detection” and “Missing & Left Object detection”. You can either set a full Video detection or mask out some unwanted area to prevent false alarms.
Page 37 huperVision 1.51 Hybrid DVR Quick Start Guide Let’s try to do Add Mask and Subtract Mask example here. 1. Check the “Add Mask” Mode. 2. Check the Rectangle Shape 3. Drag a Rectangle shape by Mouse to block out the Flashing screen from Motion Detection.
Page 38 huperVision 1.51 Hybrid DVR Quick Start Guide The other way to do Mask: Full Screen mask When you need to block out most of the area and only detect several regions on video, you can use this button to block out the entire video, and the system will also switch to “Subtract Mask”...
Page 39 huperVision 1.51 Hybrid DVR Quick Start Guide 5. Dig a circular shape in the mask for detection. 6. Check the Free hand sketching 7. Use free hand sketching to wipe out Mask areas. 8. Now you know how to do masks. And hope the mask can help you to a precise detection area.
