Huntcctv HTP-T2M1000ISWB User Manual

2.0 megapixel speed dome
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HTP-T2M1000ISWB
2.0 Megapixel Speed Dome
User Manual
ver.1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HTP-T2M1000ISWB and is the answer not in the manual?

Questions and answers

Summary of Contents for Huntcctv HTP-T2M1000ISWB

  • Page 1 HTP-T2M1000ISWB 2.0 Megapixel Speed Dome User Manual ver.1.0...

  • Page 2: Safety Precaution

    We appreciate your purchasing HTP-T2M1000ISWB. Before installing the product, please read the following with care  Make sure to turn off the power before installing HTP-T2M1000ISWB.  Do not install under the direct sunlight or in dusty areas.  Make sure to use the product within the temperature and humidity specified in the specification.

  • Page 3: Table Of Contents

    HTP-T2M1000ISWB User Manual Table of Content 1. Introduction ..........................4 About this manual ........................4 Features ........................... 4 Product and Accessories ......................7 Part Names and Functions ....................... 8 System Connections ......................... 9 2. Installation ..........................12 DIP Switch Setup ........................12 Installation Camera with Brackets ...................

  • Page 4: Introduction

    T2M1000ISWB. The Manual includes instructions of installation, operation and configuration of HTP- T2M1000ISWB as well as how to make troubleshooting. Features HTP-T2M1000ISWB is a 2.0M PTZ network-based camera with remote live monitoring, audio monitoring and control via an IP network such as LAN, ADSL/VDSL, and Wireless LAN. Camera •...
  • Page 5 HTP-T2M1000ISWB User Manual Serial Data • RS-485 support • Data pass-through mode : Serial data communication between HTP-T2M1000ISWB and Decoder Sensor and Alarm • Support direct connections of external sensor and alarm devices • Event Alarm notification. • 2 alarm sensor Inputs and 2 alarm Output relays are available •...
  • Page 6 HTP-T2M1000ISWB User Manual PTZ(Pan/Tilt/Zoom) Control • With RS-485 communication, max. 255 of cameras can be controlled at the same time. • Pelco-D or Pelco-P protocol can be selected as a control protocol in the current version of firmware.. Easy Installation and Perfect Outdoor Environment Compatibility •...

  • Page 7: Product And Accessories

    HTP-T2M1000ISWB User Manual Product and Accessories  Main body & Dome Cover  Accessories Main Cable Wrench Driver 2EA of BNC Cross LAN Cable Audio Cable Note: Mount Brackets are optional.  Wall Mount Bracket  Ceiling Mount Bracket [Screws : Torx Secrew M418, Hex Lag #1450] [Screws : Torx Screw M418, Anchor Bolt 3/8"70]...

  • Page 8: Part Names And Functions

    HTP-T2M1000ISWB User Manual Part Names and Functions ① • Dome Cover Do not detach protection vinyl from dome cover before finishing all installation process to protect dome cover from scratches or dust. • DIP Switch Sets up camera ID and protocol.

  • Page 9: System Connections

    Remote Center (PC SW) One HTP-T2M1000ISWB is installed at a site where video images are transmitted. A PC or a decoder is installed at a central location to receive and view the video images on an analog monitor. Audio and serial data are transferred in either direction.
  • Page 10 Multicast Mode If the network supports multicasting, a large number of decoders can be used to receive video effectively from a HTP-T2M1000ISWB using a single streaming of video and audio. However, multicast mode is possible only when network environment supports multicast.
  • Page 11 HTP-T2M1000ISWB User Manual CMS (Central Monitoring System) Remote Center Site Site Remote Center (Decoder) CMS (Central Monitoring System) is a Window-based remote monitoring program in order to monitor or control video, audio, and events in real time from several IP cameras or video servers. Please refer to the CMS User Manual for more in detail.

  • Page 12: Installation

    HTP-T2M1000ISWB User Manual 2. Installation DIP Switch Setup When you control the camera through RS-485, before installation, you should set the DIP switches to configure the camera ID, communication protocol. Camera ID setup  ID numbers of camera are set up with binary numbers..
  • Page 13 HTP-T2M1000ISWB User Manual Communication Protocol Setup  Select the appropriate Protocol with DIP switch combination. Switch State Protocol/Baud rate (Pin 1) (Pin 2) (Pin 3) PELCO-D, 2400 bps PELCO-D, 9600 bps PELCO-P, 4800 bps PELCO-P, 9600 bps Otherwise Reserved ...

  • Page 14: Installation Camera With Brackets

    HTP-T2M1000ISWB User Manual Installation Camera with Brackets Installation using Ceiling Mount Bracket ① Remove the ceiling tile from the ceiling and cut a ② Hook up “Drop Prevention Spring” on main body hole whose diameter is 30~40mm on the ceiling tile...
  • Page 15 HTP-T2M1000ISWB User Manual Installation using Wall Mount Bracket ① Make a hole whose diameter is 30~40mm on ② Hook up “Drop Prevention Spring” on main body to the mounting surface to pass the wire(s) and prevent camera from unexpected drop and pull the cable(s) through the mounting surface.

  • Page 16: Wiring/Cabling & Connecting

    HTP-T2M1000ISWB User Manual Wiring/Cabling & Connecting Port Description  Main Cable Port Pin Number (RJ45) Connector / Wire Color Signal Black RS485 + RS485  Brown DC 12V Orange Ground Yellow OUT COM (Relay Output Common) Green OUT 2 (Relay Output 2)
  • Page 17 HTP-T2M1000ISWB User Manual Connecting Power Carefully check the voltage and current capacity of the rated power. The rated power is indicated in the back of main unit. After confirming the power source, connect power adaptor and connect the 12V DC connector to the system ...
  • Page 18 PC client can send PT commands to the external equipment via the serial port. When a decoder system instead of PC client is connected to HTP-T2M1000ISWB, the serial port and that of the decoder system works in pass-through mode. That is, data from at one port is...

  • Page 19: Check If It Works

    HTP-T2M1000ISWB User Manual  Relay Output Internal AC or DC OUT COM OUT 1 LOAD OUT 2 LOAD Maximum allowable electrical load of relay is shown bellow table. Drive Power DC Power AC Power Max. Load Max DC 24V, 1A Max AC 125V, 0.5A...

  • Page 20: System Operation

    3. System Operation Remote Video Monitoring There are two ways to monitor video when the center system and HTP-T2M1000ISWB are connected. In order for a proper operation, an IP address must be set accordingly. Please refer to True Manager in Chapter 3 or Remote Setting in Chapter 4 for further details.
  • Page 21 Video Selection Select the Video stream to be viewed: Primary or Secondary HTP-T2M1000ISWB is capable of dual streaming; primary streaming and secondary streaming. Video will be displayed according to the resolution set on video configuration. If dual streaming (“Use Dual Encode” Menu in Video page) is not activated, secondary video is not available ...
  • Page 22  Alarm Output Operate the alarm device by pressing the number icon HTP-T2M1000ISWB supports two alarm outputs. A number icon indicates status of the alarm device.  Screen Capture Capture video images and store them as BMP or JPEG files.

  • Page 23: Initialization Of Ip Address

    HTP-T2M1000ISWB User Manual Video Monitoring with Decoder System Once HTP-T2M1000ISWB‟s IP address is set in the remote IP address section of the decoder, the decoder system will connect to HTP-T2M1000ISWB and start receiving the video images. Normally, a monitor connected to the decoder will display video images...

  • Page 24: Remote Configuration

    4. Remote Configuration Using Web Brower Remote setting is available by using web browser. Enter IP address of HTP-T2M1000ISWB and then a live view screen appears as below. Press Setup button located in the upper right area of the monitoring screen to go to the server setup.

  • Page 25: System Configuration

    HTP-T2M1000ISWB User Manual System Configuration 25/54 2.0 Megapixel Speed Dome Manual...
  • Page 26  Firmware version Display the current firmware version  Board ID Display the Network board ID of HTP-T2M1000ISWB recognized by system  Upgrade Upgrade firmware Press Browse button to select a firmware file from PC. Press Firmware Upgrade button to start to upgrade.
  • Page 27 HTP-T2M1000ISWB User Manual Time  Start Time Latest the camera‟s booting date and time  Current Time Current date & time Enter a new date and time and press Set Current Time button to update date & time  Time Format Change the time format.
  • Page 28 Factory Reset  Current IP Address of HTP-T2M1000ISWB is changed to default IP Address, 192.168.10.100. System log and user registrations are also cleared. The other setting value will be remained. Note that Password will not be changed by the factory reset for the security purpose. Please contact the manufacturer when you forget your password.

  • Page 29: Video Configuration

    HTP-T2M1000ISWB User Manual Video Configuration 29/54 2.0 Megapixel Speed Dome Manual...
  • Page 30 HTP-T2M1000ISWB User Manual Encode  Enable Preview 1. Select ON to enable to display video on the monitor that is connected to the composite or HD-SDI video port. 2. Select the Output format accordingly in the end of the Video page.
  • Page 31 HTP-T2M1000ISWB User Manual  Quality Select Video quality. 7 levels of quality are available. Quality mode (VBR encoding) adjusts the bit rate according to the image complexity, using higher bandwidth for increased activity in the video and lower bandwidth for decreased activity. It is preferred when the activity change in the video is significant or the network capacity is insufficient to allot certain bit rate continually.
  • Page 32 HTP-T2M1000ISWB User Manual Dual Encode  Use Dual Encode 1. Select Off button on the Enable Preview to enable to use Dual Encode 2. Select ON to enable to use Dual Encoding The secondary video can be viewed on Live View window by selecting Secondary on Video selection ...
  • Page 33 HTP-T2M1000ISWB User Manual  Sensitivity Sensitivity is the condition to trigger an event of motion detection. The value determines the sensitivity of the motion detection within a block: the smaller, the more sensitive. It is selectable from 0 to 10.

  • Page 34: Audio Configuration

    Select the Bit rate between 64kbps and 128kbps when AAC is selected The sampling rate is fixed to 32KHz when AAC is selected. Note that when HTP-T2M1000ISWB is connected to a decoder, the decoder‟s audio algorithm should be set identically to transmit audio properly.

  • Page 35: Network Configuration

    HTP-T2M1000ISWB User Manual Network Configuration 35/54 2.0 Megapixel Speed Dome Manual...
  • Page 36  Base Port Enter the Base Port number. Network base port is use for communication between systems. In order for HTP-T2M1000ISWB and remote systems (decoder or CMS, NVR software) to be connected, the port number must be identically set. 36/54...
  • Page 37 HTP-T2M1000ISWB User Manual  HTTP Port Enter HTTP port used for web-based connection  RTSP Port Enter RTSP port used for RTSP-based connection. The default RTSP port is 554 RTSP (Real Time Streaming Protocol) is a standard for connected client(s) to control streaming data...
  • Page 38 SNMP  HTP-T2M1000ISWB can be used as an SNMP agent. It is compatible to both SNMPv1 and SNMPvec. Settings for using SNMP (Simple Network Management Protocol) are as following SNMP Listen Port: The port is for connecting external devices when system operates as a SNMP client.
  • Page 39 Bitrate control  When there are more than one client connected to HTP-T2M1000ISWB, due to bandwidth difference among the clients some of them do not have enough bandwidth to receive encoded stream completely. In this case, it is possible to select the way to stream video to clients as following.

  • Page 40: Serial Configuration

    HTP-T2M1000ISWB User Manual Serial Configuration 40/54 2.0 Megapixel Speed Dome Manual...
  • Page 41 PTZ Type & ID: PTZ Type & ID are displayed automatically once the camera reboots after DIP switch setup. The default PTZ Type and ID is Pelco-D and 2400bps. Sensor Type  There is two sensor input ports on HTP-T2M1000ISWB.The sensor port can be configured to the following. Function Operation Not used...

  • Page 42: Event Configuration

    HTP-T2M1000ISWB User Manual Event Configuration 42/54 2.0 Megapixel Speed Dome Manual...
  • Page 43 The HTP-T2M1000ISWB has two sensor ports and two alarm ports. When a decoder instead of a PC client is connected to a HTP-T2M1000ISWB, one system becomes a Local system and the other a Remote system (Generally a system which is being used by the user is called as Local system).
  • Page 44 HTP-T2M1000ISWB User Manual E-mail Notification  Specify the information to send event information, when E-mail is selected as an event action. Server Address: Enter an address of mail(SMTP) server Port: Specify a port for SMTP operation (Port 25 is the default port in SMTP operation. If a different port is configured in the SMTP server, this port needs to be changed accordingly).

  • Page 45: Ptz Configuration

    HTP-T2M1000ISWB User Manual PTZ Configuration 45/54 2.0 Megapixel Speed Dome Manual...
  • Page 46 HTP-T2M1000ISWB User Manual  Control PTZ using the PTZ controller Preset  Max. 128 positions can be stored as Preset position. 1. Move the position to be set 2. Select one of the entries of Preset from the list 3. Press Set button 4.
  • Page 47 HTP-T2M1000ISWB User Manual Swing  By using Swing function, you can make camera to move between 2 Preset positions repeatedly. When swing function runs, camera moves from the preset assigned as the 1st point to the preset assigned as the 2nd point in CW(Clockwise) direction. Then camera moves from the preset assigned as the 2nd point to the preset assigned as the 1st point in CCW(Counterclockwise) direction.
  • Page 48 HTP-T2M1000ISWB User Manual Ex) Group-1 Swing-1 Preset-1 Pattern-1 Repeat 2 Speed 3 Repeat100 Live View Page Select List-1 and Press Group to operate the Group-1 48/54 2.0 Megapixel Speed Dome Manual...

  • Page 49: Record Configuration

    HTP-T2M1000ISWB User Manual Record Configuration  In case of HTP-T2M1000ISWB, Recording configurations on the Record page is not available. 49/54 2.0 Megapixel Speed Dome Manual...

  • Page 50: User Configuration

    HTP-T2M1000ISWB User Manual User Configuration User List  User can be registered and privilege level of a user can be specified. User configuration is allowed only to admin user. Max 16 users can be registered and each user can have one of four privileges.
  • Page 51 HTP-T2M1000ISWB User Manual  Delete User Select the User to be deleted and press Delete button.  Change Password .Press Modify password button. The following window will appear. Enter the current password and then set a new password.  Modify Privilege Level Press Modify Privilege button to change User level.

  • Page 52: Camera Configuration

    HTP-T2M1000ISWB User Manual Camera Configuration 52/54 2.0 Megapixel Speed Dome Manual...
  • Page 53 HTP-T2M1000ISWB User Manual Day & Night  The camera delivers color images during the day. As light diminishes below a certain level, the camera can automatically switch to night mode (Black & White mode) to maintain good image quality. ...
  • Page 54 HTP-T2M1000ISWB User Manual  Digital Zoom Determine to use Digital zoom (12x) supported by the camera zoon lens. x10 Optical zoom and x12 Digital zoom lens (f=5.1 ~ 5.1mm) is built-in HTP-T2M1000ISWB.  Aperture Level Set Aperture Level from 0 to 15 Aperture control is a function which adjusts the enhancement of the edges of objects in the picture.
