- Page 1 COLPOSCOPE MODEL 935 OWNER’S MANUAL PRECISION MICROSCOPES A Division of Seiler Instrument Company...
- Page 2 PRECISION MICROSCOPES A Division of Seiler Instrument Company 3433 Tree Court Industrial Blvd. St. Louis, MO 63122 (314) 968-2282 Toll-Free: (800) 489-2282 Fax: (314) 968-3601 E-mail: micro@seilerinst.com www.seilerinst.com...
- Page 3 Presentation and Use The sections contained in this Manual were especially grouped to serve the owners of the COLPOSCOPE MODEL 935 from Seiler Precision Microscopes. Read this Manual before setting up the equipment, in order to avoid damage from improper usage.
-
Page 4: Colposcope Floor Stand
COLPOSCOPE FLOOR STAND Fig. 10 NOMENCLATURE OF THE NUMBERED PARTS 1) Colposcope Head 2) Head block knob (Caution: Optics will drop when knob is loosened.) 3) Column height adjusting knob 4) Cold Light Generator (1) Metal Halide / (1) Halogen 15V-150W 5) Base with casters A knob located at the stand tube (item 3) fixes the vertical movement of the column. -
Page 5: The Colposcope Head
THE COLPOSCOPE HEAD Composition The Colposcope Head is composed by: • The Binoculars, • One Objective, • An illumination system, and • A floor stand. OPTIC POD COMPONENTS Binocular Head Tension Adjustment Magnification Changer Objective Lens Green Light Filter Fine Focus Knob... - Page 6 CLEANING The Objective, at the bottom of the colposcope body, may be exposed to blood and other bodily fluids. Spots on the objective dim the passage of light. Alcohol or warm water in a mild detergent, applied with a clean cotton swab can be used to remove all smudges.
- Page 7 Focus the observation field Interpupillary distance adjustment: Look through the two eyepieces with both eyes open and adjust the interpupillary distance as explained below in the items “inclined binoculars” and “straight binoculars”, until they are juxtaposed to the two pupils and the vision of the field appears as only one disk, clear and stereoscopic.
-
Page 8: Power Cord
Bulb Change Instructions: 1) TURN OFF POWER TO THE LIGHT SOURCE OR REMOVE THE POWER CORD Thumb Locks 2) Unscrew the two thumb locks on the front of the light source and pull out the light bulb tray. 3) Be Cautious when removing the front light bulb tray. - Page 9 Ceramic Disc 4) Grab the bulb by the ceramic disc and slide out of the bulb holder tray. BE CAREFUL to make sure that the light bulb is not HOT. 5a) For changing the METAL HALIDE bulb: - Remove the bulb from the tray and separate the bulb with the wire from the connector wire.
- Page 10 6) Slide bulb back into bulb tray - Metal Halide bulb tray has a guide for proper seating of the bulb - If bulb is not seated correctly in the bulb tray light output will be affected. 7) Replace front panel and lock down thumb locks 8) Plug in the power cord and/or turn on the power button.
-
Page 11: Optical And Field Magnification Table
The magnification selector has 6 positions: 1, 2, 3, 4, and 5. The 3 position is repeated in the selector. The working position is the one aligned to the red dot mark. MAGNIFICATION TABLE FOR 935. BINOCULAR HEAD FOCAL LENGTH = OBJECTIVE LENSES... - Page 12 PRECISION MICROSCOPES A Division of Seiler Instrument Company If you have any questions regarding Seiler’s products or services, please feel free to contact us. Toll-Free: 800.489.2282 Local: 314.968.2282 Fax: 314.968.3601 E-mail: micro@seilerinst.com www.seilerinst.com • Microscope Division Manager Dane Carlson ext. 365 • dcarlson@seilerinst.com •...
- Page 13 PRECISION MICROSCOPES A Division of Seiler Instrument Company...
