Page 1: Instruction Manual
2200W BAGLESS VACUUM CLEANER Instruction Manual MODEL: PL739B Due to ongoing product improvements, specifications and accessories may change without notice. Actual product may differ slightly to that depicted. -
Page 2: Table Of Contents
CONTENTS 02 Welcome 03 Package Contents 03 Technical Specifications 04 Important Safety instructions 06 Assembly and parts 08 Instructions 09 Cleaning and Maintenance AFTER SALES SUPPORT PROLINK ASIA LTD Phone: 0508 776 546 - Mon-Fri 8:30am – 4.30pm Page 1... -
Page 3: Welcome
WELCOME Congratulations on choosing to buy a Sheffield product. All products brought to you by Sheffield are manufactured to the highest standards of performance and safety, and, as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 12 Month warranty. -
Page 4: Package Contents
1 x Warranty Card Confirm all parts before disposing of carton. Safely dispose of all plastic bags and other packaging components. They may be potentially dangerous to children. TECHNICAL SPECIFICATION Model: PL739B Rated voltage: 220-240V~50Hz Power: 2200W Protection class: AFTER SALES SUPPORT PROLINK ASIA LTD Phone: 0508 776 546 - Mon-Fri 8:30am –... -
Page 5: Intended Use
IMPORTANT SAFEGUARDS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE Carefully read this manual before using this appliance. Ensure that you know how the appliance functions and how to operate it. Maintain the appliance in accordance with the instructions to ensure that it functions properly. - Page 6 Use and Environment Do not leave vacuum cleaner when plugged in. Unplug from outlet when not in use and before cleaning. To reduce the risk of electric shock, do not use outdoors or on wet surfaces. If the vacuum cleaner is not working as it should, has been dropped, damaged, left outdoors, or dropped into water, take it to a service centre.
-
Page 7: Assembly And Parts
ASSEMBLY AND PARTS A. Dust container release D. Rewind button B. ON/OFF button E. Exhaust filter C. Floor brush clip ASSEMBLING THE VACUUM CLEANER +Always remove the plug from the power socket before fitting or removing accessories! 1. Fitting the flexible hose Insert the flexible hose into the suction inlet at the front of the appliance. - Page 8 ACCESSORIES Floor brush Adjust the floor brush based on the type of floor. Use the brush position switch to switch to position; (A) Extracted brushes: for hard floors or position (B) Retracted brushes: for rugs and carpets. Crevice tool Use to get into corners and tight areas, such as next to and under the refrigerator and other large appliances and along skirting and architrave.
-
Page 9: Instructions
INSTRUCTIONS Using Your Sheffield Vacuum Cleaner Before using the appliance, unwind a sufficient length of cable and insert the plug into a suitable 220-240V ~ 50Hz power socket. A yellow mark on the power cable shows the ideal cable length. -
Page 10: Cleaning And Maintenance
CLEANING and MAINTENANCE This appliance requires little maintenance. It contains no user-serviceable parts. Any servicing requiring disassembly other than cleaning must be performed by a qualified appliance repair technician. Before Cleaning WARNING: The plug must be removed from the power socket before any maintenance or replacement. - Page 11 Removing and Cleaning the Cyclone Filter Press the dust container release button and lift out the dust container from the Vacuum. Remove the lid and internal components by holding the dust canister body firmly and rotating the lid in the direction of the arrows marked on the lid. (see below) Remove the lower plastic component by holding it firmly and rotating the lid in the direction of the arrows marked on the lid.
-
Page 12: Motor Protection Filter
Re-Assembly (8) Locked (8) Unlocked Cleaning and Replacement of the Motor Protection Filter Remove the dust collection system from the appliance. Remove the motor protection filter. Wash it under running water and allow it to dry completely before refitting to the appliance. Alternatively replace it with a new filter. - Page 13 Precautionary Measures All filters should be checked regularly for signs of damage, preferably after each use. The filters must be replaced immediately if they become damaged. Always disconnect the vacuum from the electrical outlet when checking the filters. This vacuum cleaner is equipped with a plug and a cord, which rolls up automatically. If any of these parts get damaged, it must be repaired by a qualified repairman or electrician.
