Summary of Contents for Samcen SCS-6100MA
-
Page 1: User Manual
Conference System User Manual SAMCEN SAMCEN Professional Audio Conference System Fully Digital Congress System User Manual Please read the instruction carefully before using. - Page 2 SCS-6170C/D, SCS-6190C/D, SCS-350MA, SCS-350TA, SCS-360RA etc. It is only an instruction for operators, not for any maintenance usage. This manual is copyright SAMCEN Corporation (China). All rights reserved. No part of this publication may be copied or reproduced without the prior written consent of SAMCEN Corporation (China).
- Page 3 Conference System User Manual SAMCEN Safety Operation Guide In order to ensure the credibility use of the product and the user’s safety, please comply with the following items during installation and maintenance: The system must be earthed properly. Please do not use two blades plugs and ensure the alternating power supply ranged from 100v to 240v and from 50Hz to 60Hz.
-
Page 4: Table Of Contents
Features of SCS ..........................2 1.3. Product list............................3 2. SCS Control Units........................4 2.1. Introduction............................. 4 2.2. SCS-6100MA SCS control host ...................... 4 2.3. SCS-6100E expand main host ...................... 11 2.4. Products introduction ........................13 2.5. SCS-6090C/D discussion system unit ..................14 2.6. - Page 5 Conference System User Manual SAMCEN 7. Conference Management Software ..................28 7.1. Please read before setup ....................... 28 7.2. Installation ............................. 28 7.3. Basis setup............................28 7.4. Preparation (Just for voting system) ................... 34 7.5. Start meeting (just for voting system) ..................34 7.6.
-
Page 6: Samcen Conference System Introduction
IR language distribution, telephone conference, voting and video tracking. SAMCEN is always dedicated to integrated system solutions. Therefore, the SCS is not only a Hi-tech electronically system, but also a powerful conference control solution while cooperating with the central control system seamlessly. -
Page 7: Product List
Conference System User Manual SAMCEN 1.3. Product list Audio Conference System Product Models SCS Control Units SCS-6100MA Control host SCS-6100E Expanded host SCS Fully Discussion System Units SCS-6090C Chairman unit with LCD display SCS-6090D Delegate unit with LCD display SCS-6070C... -
Page 8: Scs Control Units
② LCD screen: to indicate the working state. After energized, the first indication welcome message, such as "Welcome SAMCEN Digital System" Then the LCD display system that is the mode of work, such as : Mode Set: Fifo Mode, Talker Num: 3. It means that the system in the first-in first-out meeting mode, allowing three individuals to speak at the same time. - Page 9 Conference System User Manual SAMCEN back to the screen mode interface. “UP”, “DOWN”, “LEFT” and “RIGHT”, to switch from term to term uses the “up/down” button, and uses ④ these four buttons to move the camera in setting preset. ⑤ "ENTER", enter / confirm button. setting and switching the modes with the selection button together,...
- Page 10 Conference System User Manual SAMCEN A. Work Mode/Conference Mode * Limit mode: you can set the number of talkers for 1-6 in this mode, but 12 talkers can be allowed to speak at the same time through the PC operation. When the talker numbers reach the number what is set before, it can not increase the unit open.
- Page 11 Conference System User Manual SAMCEN G. Unit control: designated to speak directly through the open or closed the corresponding unit 2.2.2. Rear Panel ① Serial communication port： With 9-pin connectors to connected the computer. ② LINE IN: can be connected the CD player etc. as the background music for the venue.
- Page 12 Conference System User Manual SAMCEN Controller connected to H igh Speed Dome used RS485 protocol，resulting in long-distance signal transmission, without interference. Controller use standard 1U design, steady and solidity. It can be installed in the 19-inch standard rack. Without computer, through the controller to achieve the following functions：...
- Page 13 Conference System User Manual SAMCEN Voting model: agree, against, abstain. 2. Election mode: elect 1/3 or elect 1/5 3. Score mode: 0’, 25’, 50’, 75’,100’. To establish a process prior to the meeting, including agenda, and to the meeting who signed, seating, and so on.
- Page 14 Conference System User Manual SAMCEN 5 Multifunctional keys: 1) Key1(Candidate 1/Yes/Response/check voice control and sensitivity) In the idle state, press key1 will check the voice control status (disable/enable) and sensitivity; In voting (elect 1/3 or 1/5) mode, voting indicating light will blink (red and green), press this key to vote candidate 1;...
-
Page 15: Scs-6100E Expand Main Host
Conference System User Manual SAMCEN “no”, ”abstain”, light ring off, you have voted, effective. Before the end of the vote, you can modify the vote. Result of the voting will displays on LCD. Voting (electing) If used in the election, the five keys representing five candidates. “Candidate 1” “Candidate 2” “Candidate 3”... -
Page 16: Technical Parameter
It can be located anywhere in the chain. ROUTE A is the interface to the SCS-6100MA control host. B is the expanded interface to another SCS-6100E expanded control host. When in a multilevel expansion, A is the interface to the front level, and B is the interface to the next level. -
Page 17: Products Introduction
Conference System User Manual SAMCEN 2.3.5. System Diagram 2.4. Products introduction Model Description Outline MIC button Voting buttons Channel selection SCS-6090C Chairman unit Desktop √ × × √ SCS-6090D Delegate unit Desktop √ × × √ SCS-6070C Chairman unit Embedded √... -
Page 18: Scs-6090C/D Discussion System Unit
Conference System User Manual SAMCEN 2.5. SCS-6090C/D discussion system unit 2.5.1. Function direction： 1. Microphone words head. 2. Unit-bright ring. It turns red when the unit is ON. 3. Activity part：Used to adjust the direction and height of the microphone, so to speak speaker to facilitate. -
Page 19: Scs-6050C/D Discussion System Unit
Conference System User Manual SAMCEN 12. Microphone rods can be taken down during the recess, easy to maintain 13. Humanization design. There is different length MIC rods to choose, it is suitable for different height attendances 2.6. SCS-6050C/D discussion system unit 2.6.1. -
Page 20: Scs-6040C/D Discussion System Unit
Conference System User Manual SAMCEN 2.7. SCS-6040C/D discussion system unit 2.7.1. Function direction： Chairman unit Delegate unit 1. Microphone words head. 2. Unit-bright ring: It illuminates when the unit is ON. 3. Activity part：Used to adjust the direction and height of the microphone, so to speak speaker to facilitate. -
Page 21: Scs-6001C/D Discussion Unit
Conference System User Manual SAMCEN 2.8. SCS-6001C/D discussion unit 2.8.1. Function Directions Chairman unit Delegate unit 1、 Microphone words head. 2、 Unit-bright ring: It illuminates when the unit is ON. 3、 Activity part：Used to adjust the direction and height of the microphone, so to speak speaker to facilitate. -
Page 22: Scs-6190C/D Voting System Unit
2、 5 keys for voting and electing 3、 With the function of sign in 4、 Working with Samcen software for various kinds of voting 5、 First choice for large-scale & important conferences, such as International Conferences, Summits, Standing Committee 6、... -
Page 23: Scs-6170C/D Voting System Unit
Conference System User Manual SAMCEN 2.10. SCS-6170C/D voting system unit 2.10.1. Function direction： Chairman voting unit Delegate voting unit 1、 Microphone words head. 2、 Unit-bright ring. It illuminates when the unit is ON. 3、 Activity part：Used to adjust the direction and height of the microphone, so to speak speaker to facilitate. -
Page 24: Scs-6150C/D Voting System Unit
Conference System User Manual SAMCEN 2.11. SCS-6150C/D voting system unit 2.11.1. Function direction： Chairman voting unit Delegate voting unit 1、 Microphone words head. 2、 Unit-bright ring. It illuminates when the unit is ON. 3、 Activity part：Used to adjust the direction and height of the microphone, so to speak speaker to facilitate. - Page 25 Conference System User Manual SAMCEN 3.1.2. Physical View SCS-320PAFront View Rear Panel 1. Microphone words head 2. Microphone red indicator to show mic state 3. Microphone LCD, can display input and output channel 4. MIC. 3.5mm input jack to connect the microphone.
-
Page 26: Scs Ir Language Distribution System
Conference System User Manual SAMCEN 3.1.3. Connection Diagram 4. SCS IR Language Distribution System 4.1. Introduction SCS-350MA IR language distribution system transmitter host SCS-350TA IR language distribution system radiator unit SCS-360RA IR language distribution system receiver unit 4.2. SCS-350MA IR Language Distribution System Transmitter 4.2.1. -
Page 27: Scs-350Ta-15 Ir Radiator
Conference System User Manual SAMCEN 5. Equipped with 12 input audio connectors, it is able to input external audio signals. 6. Equipped with 12 output audio connectors, it is able to output audio signals to different audio devices like amplifier and audio recorder. -
Page 28: Technical Data
Conference System User Manual SAMCEN 4.4.2. Features 1. Cooperate with SCS-E3A headphone. 2. Adopt the special anti-noisy technique to reduce the noisy while switching, 8-32 selectable channel. 3. Adjustable volume. 4. The quantity of the receiver unit is not limited in the covered area of IR radiation 5. -
Page 29: Scs Video Auto-Tracking System
Conference System User Manual SAMCEN > 80dB Am restraint > 45dB Maximum sound pressure level 110dB Frequency response 608 kHz Dimension 108L x 62W x 28H (mm) Weight 0.4KG Color Black SCS Video Auto-tracking System 5.1. SCS690HD High Definition Camera 5.1.1. -
Page 30: Accessories
Conference System User Manual SAMCEN Preset 128 preset, title can be edited Auto-flip Tilt down 90°, with auto-flip 180° Display zone 8 programmable zones with titles Sync model Internal Decoder Built-in Video output Female BNC Remote controlling RS485 Baud rate (RS485) 2400／4800／9600/19200 bps... -
Page 31: Scs-E3A Earphone With Microphone
Conference System User Manual SAMCEN 6.2.2. Technical Data Model SCS-E2 Interface 3.5mm stereo connector Frequency response 80Hz – 2KHz Sensitivity 90dB > 80dB Distortion < 0.1dB Impedance 32 Ω Dynamic range > 85 dB Output power 100mW 6.3. SCS-E3A Earphone with Microphone 6.3.1. -
Page 32: Conference Management Software
Please copy the file “Setup.exe” to PC, then double-click that file, according to the prompt to install 7.2.1. Login in After installation, double-click “Fully Digital Congress System” to login, enter the user name and password （default user is samcen，password is samcen） ，then click “OK”. 7.3. Basis setup 7.3.1. - Page 33 Conference System User Manual SAMCEN 7.3.2. Screen Management: set the second screen The Sreen size, ForeColor, BackColor, Font Size and TextAlign can be set in this. 7.3.3. Venue Designer According to the actual layout of the venue, describes the venue seating arrangement situation to form an intuitive and imagination controlled interface.
- Page 34 Conference System User Manual SAMCEN Move the mouse to “Preset”, tick the empty box in front of “Preset Setting”. Then move the mouse to “Default” to restore the default settings, a message will pops “Are you sure to delete all the preset position”, click the left button “确定”, you will hear a “Di”...
- Page 35 Conference System User Manual SAMCEN ② Select the “Protecol Type”: click the down arrow in the selected box, select the right protocol of the camera which you select on Step 2, then click “OK” behind that selected box, you will hear a “Di” sound after a few seconds.
- Page 36 Conference System User Manual SAMCEN front of “Configure Camera”, select “Protecol-D” in the “Protecol Type” selected box, then click “OK” behind that selected box, you will hear a “Di” sound after a few seconds. Finally, select “9600” in the “Deme Bpe”...
- Page 37 Conference System User Manual SAMCEN ※ Public preset: Screen displaying state when video track start and all microphones are turn off ⑤ For example, Camera 1 tracks: microphone 1, microphone 3, Pubic Camera 2 tracks: microphone 2, microphone 4 Setting step: Microphone 1: Click the down arrow in the selected box of “Mic No.”...
-
Page 38: Preparation (Just For Voting System)
Conference System User Manual SAMCEN Preparation (Just for voting system) 7.4. 7.4.1. Proposal List: fill out the meeting title and content, choose vote mode, calculation method and registered way. Vote mode: vote on the nomination of candidate, we can choose “Yes” “No” “Abstain” by microphones. - Page 39 Conference System User Manual SAMCEN 7.5.2. Controllor State: choose the talk mode, talking number & chairman number. Mute time mean speaking time for microphone at a time. It will close by itself at the predetermined time. Limit Mode: 1-12 speakers can be allowed to speak at the same time. When it reaches the set number of speakers, the speaker can not increase.
-
Page 40: Report
Conference System User Manual SAMCEN Click on Registered list, you can check delegate’s vote. Elect 3-1/5-1 mode: click on “Start Elect 3-1”, the microphone LCD will display “Voting Begin…… 1，2，3”, in the mode, key1 means candidate1, key2 means candidate2, key3 means candidate3, then you can choose the number of whose you want to. -
Page 41: Basic Discussion Conference & Video Auto Tracking
Conference System User Manual SAMCEN Due to the modularized structure of SAMCEN SCS, engineers just need to expand the SCS modules to strengthen the functions according to the user’s request and the scale of the conference. It is easy and cost-saving for both users and engineering designers. -
Page 42: Discussion & Voting Conference & Video Auto Tracking
PC. Addresser’s voice will be transferred to the build-in loudspeaker of each contribution unit. Need to input some background music and output the audio to amplifier and recorder. 8.2.2. System Configuration SCS-6100MA SCS control host SCS-6190C SCS chairman unit... -
Page 43: Discussion + Voting + Interpretation Conference
Except the original language, this international conference needs to interpret up to 31 foreign languages. Many auditors will attend this conference and select their own languages to hear. SCS should cooperate with central control system to control and manage the whole conference. 8.3.2. System Configuration SCS-6100MA SCS control host SCS-6150C SCS chairman unit... - Page 44 Conference System User Manual SAMCEN SAMCEN Fully Digital Congress System Samcen Industrial Co., Ltd. Address: Units 705,Lingyun Building Dingxin Hi-Tech Park,Honglang North-2 Rd, Bao'an District,Shenzhen,China P.C.: 518101 Tel: (+86)-755-2309 3086 Fax: (+86)-755-2649 6450 Email: info@samcen.com Website: http://www.samcen.com...
