  • Page 1 - 1 - 2 ″ 0 ″ , 46″ User’s Manual includes setup, service and troubleshooting information Available in solid wood Ash, Beech, Sapele...
  • Page 2 - 2 - All rights reserved. ™ iameco Copyright © 2007, computers. ™ ™ MicroPro iameco and the logo are registered Multimedia Computer Systems Ltd trademarks of and its related entities. All other trademarks are the property of their respective owners.
  • Page 3 The waste mountain of electronic goods is growing rapidly. In 1997 a ™ standard computer had a lifespan of 7 years now it is as little as 2 years. iameco computers believe in a cleaner greener approach to the whole eco design of computers resulting in a much longer lifespan averaging between 5 and 7 years.

  • Page 4: Getting Started

    Note: Please keep the box and packing materials in a safe place for re-use. It can be used when transporting your LCD-TFT-TV monitor in the future or return the packaging to iameco for recycling and re-use. Warning: Your AC cord comes equipped with a three-wire grounding plug. This plug will fit a standard AC outlet.
  • Page 5 . The main benefit of energy efficiency is lower power bills. Wall-Mounting iameco LCD-TFT TVs are wall-mounting compatible which allows you to save on space by not needing a cabinet etc to stand the screen onto. With a simple and strong two-piece...
  • Page 6 - 6 - Certified TCO-99 The TCO-99 certification guarantees the customer an excellent ergonomic and visual environment.
  • Page 7 - 7 - Specifications of 32″, 40″, 46″ monitors Features/Model XV1-32 XV1-40 XV1-46 Display Aspect ratio 16:90 16:90 16:90 Resolution 1366x768 1366x768 1366x768 Brightness 500(cd/m 500(cd/m 500(cd/m Contrast Ratio 1200:1 1200:1 1200:1 Maximum Rate 100 MHz 100 MHz 100 MHz...
  • Page 8 - 8 - Connecting your iameco™ monitor Follow these steps to set up your monitor. Step 1: Plug the AC power cable into the power adapter and the other end into a 3-pin socket. Step 2: Connect the signal cable to the 15-pin, D-Type sub connector on the back of the monitor and to the VGA port in the computer.

  • Page 9: Rear Control Buttons

    Otherwise you may damage the connections. See "Connecting your iameco monitor" on page 7 of the manual for further information regarding cable connections or visit the iameco website. Remote control...
  • Page 10 - 10 - Key name Operation 7. Right Key • Increases speaker/headphone sound volume when no OSD activated. • Executes function by OSD help commands when main OSD activated • Increases values of user menu when main OSD activated 8. Info •...

  • Page 11: Basic Operation

    - 11 - Mounting your iameco • Drill the holes. (Refer to the distance between the holes according to the model.) • Install the plug, part A and the screws. • Install the parts A. • Install the screws A on the rear of the LCD-TV.

  • Page 12: Preset Timing Modes

    AC 100-240V ~2.0 - 1.0A 50/60Hz Output DC 12V 4A Note: Use only the iameco™ provided AC adapter approved for use with this monitor. Use of another AC adapter may damage your monitor and invalidate your warranty. 15pin VGA Connector...

  • Page 13: Power Saver

    OFF when it is not needed, or when leaving it unattended for long ™ periods. Always use your PC in S3 mode, which is set up in BIOS. All iameco XPCs are factory set to S3 mode to conserve energy.
  • Page 14 - 14 - On Screen Display (OSD) control adjustment for the monitor Turning LCD-TFT-TV On And Off Press Power button on the remote control. The PDP/LCD will turn on and you will be ready to use its features. You can also use the Power key on the front panel Select Source Press Source button on the remote control.
  • Page 15 - 15 - Custom Press MENU/ENTER button to display the main OSD menu. Select the picture main menu. Press MENU/ENTER to enter the sub menu. Select Custom and press MENU/ENTER button to enter the sub menu. Then the custom sub mode appears. You will see the picture setting bars.
  • Page 16 - 16 - Auto Store 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the Channel main menu with CH+/CH- button on the remote control. Press MENU/ENTER to enter the sub menu. Select with button press Auto Store VOL+/VOL- MENU/ENTER button.
  • Page 17 - 17 - Manual Store > Channel 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the Channel main menu with CH+/CH- button on the remote control. 3. Select the Manual Store menu with CH+/CH- button on the remote control.
  • Page 18 - 18 - To sort the program in the list If you want to sort a program, press MENU/ENTER button. Then you can select a field with VOL+/VOL- button. Press MENU/ENTER button on the field to sort. Adjust the field with CH+/CH- button. To return, press BACK button ANALOG TV CHANNEL >...
  • Page 19 - 19 - ANALOG TV SOUND > Volume 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the Sound main menu with CH+/CH- button on the remote control. 3. Press MENU/ENTER to enter the sub menu. 4. Select Volume and press MENU/ENTER button to enter the sub menu.
  • Page 20 - 20 - ANALOG TV SOUND > Sound Mode 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the Sound main menu with CH+/CH- button on the remote control. 3. Press MENU/ENTER to enter the sub menu. 4.
  • Page 21 - 21 - SETUP > On Time Channel Set the channel when LCD-TFT-TV power turns on automatically. Available only when the Time is set and On Time is ON. 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the TIME main menu with CH+/CH- button on the remote control.
  • Page 22 - 22 - SETUP > Blue Screen 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the Setup main menu with CH+/CH- button on the remote control. 3. Press MENU/ENTER to enter the sub menu. 4. Select Blue Screen and press MENU/ENTER button to enter the sub menu.
  • Page 23 - 23 - PIP (Picture in Picture) > Swap Using swap function, you can exchange two programs or sources at the same time. 1. Press MENU/ENTER button to display the main OSD menu. 2. Select the PIP main menu with CH+/CH- button on the remote control.
  • Page 24 - 24 - Picture (PC) > Colour Tone If you select Custom in the Colour Tone popup window on PC, you can select sub modes like as Red, Green, and Blue. 1. Press MENU/ENTER button to display the main OSD menu. 2.

  • Page 25: Troubleshooting

    You can find more troubleshooting information in our support website at www.iameco.com/support. If you experience a problem with your monitor, there is usually a simple and quick solution. If you encounter a problem, try to make a note of what you did before the problem occurred.
  • Page 26 - 26 - The image on the screen is shaking 1. Check the monitor configuration to see if it is in interlace mode. (Interlace mode: Vertical frequency 43Hz, 87Hz (i), etc.) It occurs if the signal from the video card exceeds the maximum resolution and frequency of the monitor.
  • Page 27 See the video card manual to see if the plug and play (VESA DDC) function can be supported. Find the updated monitor driver from our site and install the monitor driver according to the driver installation instructions. ™ Note: If a problem repeatedly occurs, contact an authorized iameco service centre.

  • Page 28: Tips And Safety Precautions

    ™ service representative. iameco Note: There are Dangerous High Voltages inside, even when the power is OFF. The only way to turn off power completely is to disconnect the power cord. Make sure at least one end of the power cord is within easy reach so that you can unplug the monitor when you need to.
  • Page 29 If an unauthorised person opens your monitor, you risk damaging your equipment, and such damage is ™ not covered by the limited warranty on your monitor. All spare parts are available from iameco and can only be nstalled by official service centres. Visit www.iameco.com for updated information.

  • Page 30: Disposal Information

    In the European Union (EU) ™ If the product is used for business purposes and you want to discard it please contact your iameco dealer who will inform you about the take-back of the product. You might be charged for the costs arising from the take-back and recycling.

  • Page 31: Return Policy

    10 days of shipment. How to return your purchase All returns queries are dealt with by e-mail. Contact returns@iameco.com for further instructions. You will be e-mailed a Return Merchandise Authorisation (RMA) number with some details to fill out before receiving the RMA number.

  • Page 32: Warranty Information

    ™ product or replace a product with a rebuilt, reconditioned or new product. Upon request from iameco , the ™ consumer must provide information to reasonably prove the date of purchase. iameco reserves the right to charge customer in case of warranty conditions that are not fulfilled.

  • Page 33: Limitation Of Liability

    ™ including any lost profits or savings or special incidental, or consequential damages. iameco is not liable for any claim made by a third party or made by you for a third party.

  • Page 34: Regulatory Notices

    Further information on the eco-label can be found at http://europa.eu/int/ecolabel Restriction of Hazardous Substances (RoHS) iameco products are safe from hazardous substances (Cd, Pb, Hg Cr+6, PBDE and PBB) and can be disposed of in an environmentally safe manner. Moreover, we at iameco are continuing our efforts to develop products that do not require internationally banned toxic chemicals.
  • Page 35 ISO certifications ISO 9001:2000 iameco has been assessed and is in compliance with the provisions of the Quality System to IS.EN.ISO 9001:2000 in respect of the scope of operations such as build and sale of environmentally friendly computers. Service and repair of computers, peripherals and network solutions and is hereby included in the European Quality Assessment (EQA) directory of certified organisations.

  • Page 36: Useful Terms

    - 36 - Useful terms Dot pitch The image on a monitor is composed of red, green and blue dots. The closer the dots the higher the resolution is. The distance between two dots of the same colour is called the Dot Pitch. The unit is mm. Vertical frequency The screen must be redrawn several times per second in order to create and disp lay an image for the...
  • Page 37 Standard Limited Warranty. You can either e-mail it to info@iameco.com or fax it to +353 (0) 1 4943885. Returns Material Authorisation (RMA) request form Title Contact first name...
  • Page 38 - 38 - iameco registered dealers in Ireland ™ roPro Computer Cultivate Sustainable Living Centre 98 Nutgrove Avenu 15-19 Essex St, Rathfarnham, West Temple Bar, Dublin 14, Dublin 8, Ireland. Ireland. : +353 (0) 1 4930514 Tel: +353 (0) 1 6745773...
