WELCOME
Thank you for purchasing
Exhibit Video Player
The EVL is one of a range of products we offer specific to the heritage
marketplace. We are confident that we have other products you will find
useful and look forward to dealing with you again soon.
T: +44 (0) 1639 767007
W:
www.blackboxav.co.uk
WHAT IS THE EVL
Exhibition Video Player Looping is a compact, stand-alone, digital media player.
It can be used to display and distribute media communication, videos and
images over a LCD/ plasma screen that is connected to the device via VGA input.
The EVL supports a wide range of digital media files which can be stored on a
USB drive, CF or SD card. A remote is also supplied for easy player control.
SPECIFICATIONS
Dimensions (LxWxH)
Power
Composite Output Resolution (pixels)
VGA Output Resolution (pixels)
Component (Y.PB.PR) (pixels)
Photo Format Support
Audio Format Support
USB Specs
Memory Card Support
VESA Standard
Power Source Compatibility
Looping.
130 x 117 x 25 mm
External AC Adapter (included)
(12v, 1.0 amp)
720x576
640x480 or 1280x720
640x480 or 1280x720
JPEG, BMP
MP3, WMA, AC3, AAC, OGG
High Speed USB 2.0 Host .up to 4gb
SDHC /CF Card, Size: 1GB to 32GB
100mm x 75mm
Worldwide(110v to 240v input)
FEATURES
Media Format Compatibility
Media Storage and Playback Source
Playback Modes
On-Screen Display Languages
Image Slideshow Playback
PRE-SETUP INSTRUCTIONS
Connecting your EVL is a simple and straight forward process. You will need the
following:
1.
The EVL Base Unit
2.
12V AC Power Adapter (included)
3.
VGA Cable
4.
VGA Compatible Monitor or TV
3
5.
SDHC Card, High-speed CF Card or USB2.0 Drive
6.
If you are using audio you will need a phono connection from the player
an amplifier and speakers.
Image: JPEG, BMP
Audio: MP3, WMA, AAC, OGG
Video: MPEG-1, MPEG-2, AVI
High Speed Compact Flash (CF) Card
High Speed Secure Digital (SD) Card
USB 2.0 Drive (Thumb Drive/Flash Drive)
Audio Playback
Video with Music or
Picture with Background Music
English
Chinese
Japanese
Picture Rotation
Portrait-Vertical or Landscape-Horizontal
Slideshow Transitions
14 Different Transition Effects
Slide Intervals: 1 to 60 seconds
Page 1
Manual V1 10/12
