  • Page 1 XL-PB224C XL-PB224C2 Coaxial Integrated Access System User's manual V1.2...

  • Page 2: Safety Notice

    Statement All rights reserved By the written permission of the Company and no unit or individual will be allowed to extract the contents of this book to copy some or all of any form is not able to disseminate As the product version upgrades or other reasons for the content of this manual will be updated from time to time unless otherwise agreed by the parties to use this manual only as a guide.

  • Page 3: Table Of Contents

    Contents 1 Welcome to coax XL-PB Integrated Access System ....1 1.1 Recognizing XL-PB .............. 1 1.1.1 XL-PB224C Terminal Products........2 1.1.2 Ports................3 1.2 Connect power and network ..........4 1.2.1 Connect Network............4 1.2.2 Connect the power............5 2 Attachment ..................6 2.1 Specification ................

  • Page 4: Welcome To Coax Xl-Pb Integrated Access System

    1 Welcome to coax XL-PB Integrated Access System 1.1 Recognizing XL-PB Today's cable networks in households, by telephone twisted pair, power lines and the most common CATV coaxial cable. Also among the coaxial cable which, with its large bandwidth, shielding is good, the high rate of households, business is rich in resources and become an ideal medium for broadband Internet access.

  • Page 5: Xl-Pb224C Terminal Products

    *: The actual load with a concrete model version shall prevail 1.1.1 XL-PB224C Terminal Products Appearance...

  • Page 6: Ports

    Indicator Item Meaning Desctription POWER Power Indicator Light Always have electricity, you can start using the XL-PB. Syetem System Indicator The system to start successfully. Data Data Indicator Successfully connected to the network. Flicker:There are data transmission Ethernet network LAN port connected to the network. Flicker: There are Interface data transmission.

  • Page 7: Connect Power And Network

    Ethernet Network Port 10/100M Adaptive connected computer CABLE TV / data Metric F-parent head to connect to the integrated access Internet. network interface ON/OFF Power Switch Power Switch ------- XL-PB224C terminal equipment connected diagram as shown above, insert power supply before you carefully read the manual on the "safe Notes.

  • Page 8: Connect The Power

    1. Broadband data model Cable WAN will XL-PB224C the appropriate client households connected to the coaxial cable (make sure the region has opened coaxial have broadband Internet access services), and then XL-PB224C Ethernet line interface RJ45 Ethernet cable to connect to your personal the computer's LAN port, so that the completion of network hardware link.

  • Page 9: Attachment

    2. The power adapter exchange received a power outlet plugs, XL-PB224C to boot. 3. Boot after the POWER indicator light, about 10 seconds after the System indicator will begin to flicker, the system began to self-test, and then after about 10 seconds, such as monitoring systems are completed and normal, System indicator will Always.

  • Page 10: Environmental Characteristics

    12V/DC 1A Power supply and power consumption 2.1.2 Environmental Characteristics -10—55°C Temperature 10%--90% Working humidity 2.1.3 Application Characteristics VLAN (IEEE802.1Q) to ensure security and to reduce regional Security broadcasting QoS (802.1p) priority to provide multimedia applications and bandwidth management IGMP snooping through the realization of 802.3 multicast and IP Multicast multicast, multicast group of end-use of a common tone map in order to optimize data throughput.

  • Page 11: Frequency Question Answer

    RF TV Signal output interface DC Power Interface 2.2 Frequency Question Answer Solution Trouble phenomenon POWER light does not 1, check the power connector is correct. shine 2, check the power adapter match Ethernet Light does not 1,Check the validity of the cable connections, check whether the PC shine card's indicator light lit.
