Summary of Contents for Hosola Bright series

  • Page 1 Hosola New Energy Co., Ltd. Add: NO.328 Xinghu Road,Suzhou Industrial Park,China,215123 Tel:+86 512 6281 5763 Fax:+86 512 6281 5763-1888 E-mail:info@hosola.com All rights reserved by Hosola...
  • Page 2: Copyright Declaration

    Copyright Declaration The copyright of this manual belongs to Hosola New Energy Co., Ltd. Any corporation or individual should not plagiarize, partially copy or fully copy it (including software, etc.). And no reproduced or distributed of it in any form or by any means. All rights reserved.
  • Page 3: Table Of Contents

    Contents 1NOTES ON THIS MANUAL………………………………………………………………………5 1.1SCOPE OF VALIDITY…………………………………………………………………………5 1.2TARGET GROUP………………………………………………………………………………5 1.3 SYMBOLS USED………………………………………………………………………………5 2SAFETY……………………………………………………………………………………………5 2.1APPROPRIATE USAGE………………………………………………………………………5 2.2 IMPORTANT SAFETY INSTRUCTIONS……………………………………………………6 2.3EXPLANATION OF SYMBOLS ………………………………………………………………7 3 INTRODUCTION…………………………………………………………………………………8 3.1 BASIC FEATURES……………………………………………………………………………8 3.2 ELECTRICAL BLOCK DIAGRAM……………………………………………………………9 3.3 DIMENSION AND WEIGHT…………………………………………………………………10 4 SPECIFICATIONS………………………………………………………………………………11 4 .1 SPECIFICATIONS …………………………………………………………11 (4200TL/ 5000TL) 5 FUNCTION………………………………………………………………………………………13...
  • Page 4: Scope Of Validity

    Caution indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. Note: Note provides tips that are valuable for the optimal operation of your product. 2 Safety 2.1 Appropriate Usage The Hosola Series is a PV inverter which converts the DC current of a PV generator...
  • Page 5: Important Safety Instructions

    Hosola inverter. Note: Grounding the PV generator 1. Before using the Hosola inverter, read all instructions and cautionary markings on the Comply with the local requirements for grounding the PV modules and the PV Hosola inverter, and all appropriate sections of this guide.
  • Page 6: Introduction

    3. To avoid a risk of fire and electric shock, make sure that existing wiring is in good ● IP65 protection level; ● Efficiency up to 97.1%; condition and that wire is not undersized. Do not operate the Hosola inverter with ● THD<3%; damaged or substandard wiring.
  • Page 7: Dimension And Weight

    3.3.2 Terminals of PV inverter Table 1 Weight Model Hosola Bright 4200TL Hosola Bright 5000TL Weight 18.9Kg 18.9Kg 4 Specifications 4 .1Specifications Figure 4 Terminal of PV inverters(4200TL/5000TL) (4200TL/5000TL) 3.3 Dimension and Weight 4.2.1 DC Input 3.3.1 Dimension Model Hosola Bright 4200TL Hosola Bright 5000TL Max.
  • Page 8 4.2.2 AC Output MPPT efficiency Overvoltage Protection Model Hosola Bright 4200TL Hosola Bright 5000TL DC isolation Impedance Monitoring On-grid Connection Single phase Ground Fault Protection Rated Output Power 4200W 5000W Grid Monitoring Max. Output Power 4200W 5000W Ground Fault Current...
  • Page 9: Function

    The user can get into the setting mode by press “Function” key for 6 seconds if DC is    high temperature inside the inverter. Please let users know that Hosola will not   exist. The detail information please refers to operation method in chapter 7.
  • Page 10: Preparation

    B is allowed on the supply side of this product. 3. The installation place should be away from humid or corrosive substance. 4. The Hosola inverters can be used outdoor. 6.2 Preparation 5. Users can check the firmware version via LCD function as shown below.
  • Page 11 or less than 27mm, the expansion tubes wouldn’t be installed and tightened. Figure 8 Bracket&Inverter Installation Figure 7 Installation of Expansion Pipe 3.Use the bracket to install the inverter onto the narrow vertical panel (or wall). Put 2.Clean all dust outside/inside the hole and measure pitch-row before installation. It upper-part holes of the inverter onto the bracket.
  • Page 12: Connections Of The Pv Power Syste

    6.4 Connections of the PV power system Warning: (1)PV String Hosola Bright series inverters (4200TL/5000TL) can be connected in series When there is something wrong with module arrays, modules can be connected with PV grid-tied inverter only after eliminating these problems.
  • Page 13 Impedance of Hosola inverter AC connecting dot should be less than 2Ω. To ensure reliable anti-islanding function , PV cable should be used to ensure wire loss <1% than normal power. Moreover, length between AC side and grid connecting dot should be less than 150m.
  • Page 14: Run The Inverter

    Complete AC connector parts to the inverter’s installation process. ( Figure 16) Normal: Inverter begins to operate normally with green light on. Meanwhile, feedback energy to grid, LCD displays present output power. Inverters will work in MPPT mode when PV voltage range is 300 ~500V, inverter will stop feedbacks power to grid when PV power is not enough Note:...
  • Page 15: Lcd Function

    7.2 LCD Function Initial State The function key is used to set the LCD. It can alternate among different parameters. LCD will light on It display AC voltage. Normal State Vac=xx.xV Pac=xxxx.xW Pac=xxxx.xW It display AC current. It display the total Energy Iac=xx.xA Etotal=xx.xkwh Use Function Key to...
  • Page 16: Lcd Information

    Fault UFR AC Under frequency rating 7.3 LCD Information Table 5 LCD Information No Utility No utility No Utility PV Over Voltage PV over voltage PV voltage ≥625V Operating State Information Display Description Working Condition Fault Information Power Off No display DC input voltage<80V, Consistent Fault Consistent fault...
  • Page 17: Communication And Monitoring

    This section contains information and procedures for solving possible problems with the monitoring equipment via RS232. Hosola inverters, and provides you with trouble shooting tips to identify and solve most 8.2 Communication problem that can occur with the Hosola inverters.
  • Page 18 Table 8 Troubleshooting list 1 Disconnect the PV (+), PV (-) with DC input, then reconnect them Consistent Fault Faults Diagnosis and Solutions 2 Please seek for help from us if it can not go back to normal state 1 Waiting for one minute, grid will go back to normal working state 2 Making sure that grid voltage and frequency complies Grid Faults with standards...
  • Page 19: Decommissioning

    “What proof of purchase is required?” following requirements: What will Hosola do? Hosola will, at its option, repair or replace the defective product • Suitable for loads of at least 25 kg free of charge, provided that you notify Hosola of the product defect within the Warranty •...
  • Page 20 Hosola product specifications including high input voltage from lightning strikes; 3. Ship the unit prepaid to the address provided by your Hosola customer service represen- c) the product if repairs have been done to it other than by Hosola or its authorized service tative.
  • Page 21 If the warranty period for your Hosola PV inverter has expired, if the unit was damaged by misuse or incorrect installation, if other conditions of the warranty have not been met, or if Serial Number _________________________________ no dated proof of purchase is available, your unit may be serviced or replaced for a flat fee.
