Summary of Contents for Wuchuan PH802
- Page 1 PH802 Advanced Configuration Manual Advanced Configuration Manual IP PHONE PH802 Version: VOIP PHONE V1.7.193.199 Wuchuan Network Tech Co., Ltd www.5111soft.com...
-
Page 2: Table Of Contents
PH802 Advanced Configuration Manual Content 1. Preface............................3 2. Installation ...........................3 3. WEB config..........................3 3.1 current state ..........................4 3.2 Network...........................4 3.3 voip ............................6 3.3.1 SIP config.........................7 3.3.2 IAX2 config ........................9 3.4 Advanced config ........................10 3.4.1 DHCP service.........................10 3.4.2 NAT ..........................11 3.4.3 Net Service ........................12... -
Page 3: Preface
SIP and IAX2, fully compatible with SIP industry standard and can interoperate with many other SIP compliant devices and software in the market. In order to make full use of our IP phone PH802 and getting the best return, please read the user manual carefully before using it and keep the manual for reference. -
Page 4: Current State
PH802 Advanced Configuration Manual http://xxx.xxx.xxx.xxx：xxxx/, for example, http://192.168.1.18:8080. Or user cannot find the phone web page.) Two default users for verification are admin（user name and password are both admin） and guest (User name and password are both guest). 3.1 current state... - Page 5 PH802 Advanced Configuration Manual and getting the dynamic IP address after submission. PPPOE: If choose the PPPOE service, fill in the account and password of the PPPOE service provider, the system will get the public IP address after submission. Note: If the user logs on by WAN IP and modify the WAN IP, must log on the new IP address after submission.
- Page 6 PH802 Advanced Configuration Manual Configure subnet mask Configure default gateway Configure "dns domain" suffix; if user input "domain" and it can't be parsed, the phone will parse after adding this domain Main DNS server IP address The second DNS server IP address. When main DNS server IP address isn’t available, the phoen will change to use the second DNS server IP address...
-
Page 7: Voip
PH802 Advanced Configuration Manual automatically modify the adjustment and save the configuration according to IP and subnet mask team DHCP Lease Table, user need to restart the IP Phone to make DHCP server configuration go into effect LAN port DHCP server Enable NAT. - Page 8 PH802 Advanced Configuration Manual configurations, then the port configuration needs to be configured to be numbers, here the configuration account can be arbitrary character string）. Configure password of SIP register account. Configure proxy server IP address（usually SIP will provide user with service of proxy server and register server which have the same configuration,...
-
Page 9: Iax2 Config
PH802 Advanced Configuration Manual 3.3.2 IAX2 config IAX2 server address, can be domain name IAX2 server port Username authentication. Password authentication. Register phone number IAX2 local port in device. If IAX2 supports voice mail, the voice mail is in the form of letters, it can’t input letters, so replace the numbers with the name of voice mail。... -
Page 10: Advanced Config
PH802 Advanced Configuration Manual option, user picks up the handset and dial number, it will be communicated by IAX2 protocol. The default of phone is SIP protocol, this configuration is aimed at the caller party, the receiver party wouldn’t be affected. If user configures this item, it won’t be used SIP, but IAX. If user wants to give a call by SIP simultaneously, then can configure the function of prefix substitution in the item of Dial peer and achieve the SIP call. -
Page 11: Nat
PH802 Advanced Configuration Manual the end IP of add the lease table. The quantity from the beginning to the end depends on the enable IP quantity which connect to the devices in the LAN port. The DHCP gain the address which connect with any device in the LAN port must be in the range from the Start IP to the End IP.（The size of the lease table can not beyond the address... -
Page 12: Net Service
PH802 Advanced Configuration Manual Configure the LAN IP address which NAT mapped Configure the LAN port which NAT mapped Configure the WAN port which NAT mapped the phone After configuration, click and add it to the mapped table, click and delete it from the mapped table. -
Page 13: Fireware Defence
PH802 Advanced Configuration Manual Configuration Explanation: Configure web browse port, the default is 80 port, if you want to enhance system safety, you'd better change it into non-80 standard port， modify it and save the setting, by the method of logging in http://xxx.xxx.xxx.xxx：xxxx/... - Page 14 PH802 Advanced Configuration Manual Configuration example: Configure and filter the imcp package which connected with the device in the LAN port and sent from WAN net phase. The WAN port IP of phone is 192.168.10.77，LAN IP is 192.168.1.86. Configure Explanation:...
-
Page 15: Qos
Configure Diffserv value. Note: you need to set your IP PHONE work in bridge mode to make VLAN function work and make sure your PC and PH802 in the same VLAN, otherwise your PC will have no access to PH802. -
Page 16: Sip Advanced Config
PH802 Advanced Configuration Manual 3.4.6 SIP advanced config Set SIP STUN, private and backup server, user password and so on SIP STUN is the function that realizes NAT support for SIP, IP phone is a SIP STUN client, so need to configure the STUN server IP and Port (default is 3478). After enable SIP Stun, we can use common SIP server to realize the IP phone NAT function. -
Page 17: Digital Map
PH802 Advanced Configuration Manual Enable or disable presence subscribe package, this is special function for IP PBX, the phone status display must enable subscribe. Configure auto Detect Server Enable IP phone support register with authentication, so no need for the device to reply the server and the server can reply register confirm info. -
Page 18: Call Service
PH802 Advanced Configuration Manual seconds, just after 5 seconds when receive a call, the user doesn’t dial the numbers, the phone will think the user has dial out the numbers. The received number will be sending out as the called number;... - Page 19 PH802 Advanced Configuration Manual Configure hot-line number. If configure the hot-line number, this hotline number will be dialed automatically while off-hook, and user can't dial any other number. Call forward（single option, default off） Off: switch off the forward function. Busy: The calls to this phone will be forwarded when the phone is busy.
-
Page 20: Mmi Filter
PH802 Advanced Configuration Manual Select this item，use the definition of voice hint. can play the voice message, always use with the “Enable Voice Record” together. Black List: Configure add/delete blacklist. If user doesn’t want to answer a certain number, please add this number to the list, and then this number will be unable to get through the phone. -
Page 21: Dsp
PH802 Advanced Configuration Manual Add and Delete the IP net phase; configure the start IP address and the end IP address, then submit it and go into effect. Can set a big net phase or divided several net phase and add, select the detected net phase from the start IP address in the up down menu, then click “delete”... -
Page 22: Memory Key
PH802 Advanced Configuration Manual UDP Tunnel option: VPN IP: display the virtual IP address the PH802 get. If assigned IP address means the device dial success. Configure the VPN server address Configure the VPN server port L2TP option: Configure VPN L2TP server address... -
Page 23: Dial Peer
PH802 Advanced Configuration Manual Total 10 Memory key, each key can set a number which can display presence status. This function need to be used together with Asterisk IP PBX. 3.5 Dial Peer Configure explanation: ◆when configure it in 0.0.0.0, the corresponding numbers use the SIP1（VOIP-SIP）... - Page 24 PH802 Advanced Configuration Manual When you finished configure, the phone will automatically replace 0 with 0086, when you dial 075525118801#,the phone will automatic call 0086-755-25118801 (3) Number auto delete: the device register two separate sip server accounts, if user want to sip2 to call, you can configure like the following step: （...
- Page 25 PH802 Advanced Configuration Manual (5) Call pickup function Call pickup function is kind of like pickup function of PBX, which means when A calls B, B rings but no answer. Then C can input pointed prefix+ B’s number to pick up the call and talk with A.
-
Page 26: Config Management
PH802 Advanced Configuration Manual Notice； To realize the above function 5, 6, 7, callee’s phone should have the same function, though. And need a server supporting transmitting information with any change. 3.6 Config Management 3.6.1 Save config Click Config Manage—>Save Config Save to save the current configure When the user changes the setting, he must click save configure, otherwise the phone will remain the same. -
Page 27: Back-Up Config
PH802 Advanced Configuration Manual 3.6.3 Back-up config Right click this option and choose “save as” to export this file. All IP phone’s configuration can be relized via changing config files, which can bring convenience when need to revise bulk of IP phone’s configuration. -
Page 28: Auto Provisioning
PH802 Advanced Configuration Manual Configure Explanation: Configure upload or download FTP/ TFTP server IP address. Set username of the upload or download FTP server. If user select TFTP mode, no need to input username and password. Set upload or download of FTP server password. - Page 29 PH802 Advanced Configuration Manual Complete the blank and reboot the device. If the FTP server have newer config file, the device will download it automatically and register, if not, the device will register directly. Automatically update via FTP A, Config the FTP server according to the above instruction B, Change the config file.
-
Page 30: System Management
PH802 Advanced Configuration Manual C, Put the modified config file and the needed upgrade version in the same FTP server directory. after reboot the device, it will import the config.txt and detect AUTOUPDATE CONFIG MODULE, finally download the new Image we have changed. -
Page 31: Phone Book
PH802 Advanced Configuration Manual 3.8.2 Phone Book Click “add” and input the phone number. This function is to add user’s phone number. 3.8.3 Syslog Config Config explanation: Config syslog server IP address. Config syslog server port. config MGR level config SIP level... -
Page 32: Time Set
PH802 Advanced Configuration Manual reboot etc), this debug is O level. 1 level-alert, the info indicate the system have fatal problem 2 level-critical the info indicates the system have critical problem (e.g.: insufficient system resource, upgrade file error etc) 3 level-error, the info indicate the mistake will influence the system 4 level-warning, the info indicate the system is work normally, but it may contain potential risk. -
Page 33: Appendix
PH802 Advanced Configuration Manual Click System Manage—>Reboot to confirm phone reboot. 3.9 Appendix PH802 firmware recovery Preparation ◆ The phone’s WAN port connect with the computer in the same LAN ◆ Shut down the firmwall of the computer and make sure the FTP port is open and the client server can download normally. - Page 34 PH802 Advanced Configuration Manual ◆ Input the FTP server address, if the FTP server install in the local computer, input the computer’s ip address is ok. ◆ Input the filename of the firmware, the file must put the FTP server’s directory, the user need have right to download.
- Page 35 PH802 Advanced Configuration Manual ◆ Press ”Enter” to begin upgrade If it displays update fail. Please check the setting or the update file carefully. ◆ Exit Wuchuan Network Tech Co., Ltd www.5111soft.com...
- Page 36 PH802 Advanced Configuration Manual Note: Before upgrade, please shut down the firewall of your computer, otherwise it will cause the update file. Please don’t close the post mode windows directly, exit safely with input 4 according to the tip. ※If you still have questions, please browse our website to get the contact info of our professional technical support.
