Telegesis
EAP-E
EAP-E and EAP-E-PA Ethernet Access Point
©2008 Telegesis (UK) Ltd
TG-EAPE-PM-006-102
PRODUCT MANUAL
Telegesis
TG-EAPE-PM-006-102
Product Manual
EAP-E Product Manual (Rev 1.02)
1
1.02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EAP-E and is the answer not in the manual?

Questions and answers

Summary of Contents for Telegsis EAP-E

  • Page 1 Telegesis TG-EAPE-PM-006-102 EAP-E Product Manual 1.02 TG-EAPE-PM-006-102 EAP-E and EAP-E-PA Ethernet Access Point PRODUCT MANUAL Telegesis ©2008 Telegesis (UK) Ltd EAP-E Product Manual (Rev 1.02)

  • Page 2: Table Of Contents

    FIRMWARE CHANGES AND UPGRADES ............11 Device Reset and manually Entering the Bootloader ..........11 SCHEMATICS ......................12 ORDERING INFORMATION .................. 14 TRADEMARKS ...................... 15 DISCLAIMER......................15 CONTACT INFORMATION ..................15 REFERENCES ....................... 15 ©2008 Telegesis (UK) Ltd EAP-E Product Manual (Rev 1.02)

  • Page 3: Introduction

    ZigBee® networks. Using the Ember bootloader custom firmware and firmware upgrades can be downloaded via Ethernet or over the air. The SIF interface also allows the EAP-E to be used as a platform for firmware development and debugging.

  • Page 4: Absolute Maximum Ratings

    For radio features please refer to the ETRX2 and ETRX2-PA product manuals. Dimensions: 114mm x 74mm x 25mm Weight: 95g Thermal shutdown may occur when exceeding the operating conditions. The unit will become operational again after allowing it to cool down. ©2008 Telegesis (UK) Ltd EAP-E Product Manual (Rev 1.02)

  • Page 5: Device Installation And Operation

    5. To test the communication with the EAP-E select the unit from the main window list and click Tools->Ping. Once the IP address of the EAP-E is known it is possible to open a telnet session connecting to the built-in ETRX2. By default the port connecting to the ETRX2 is port number 10001 as shown in Figure 3.
  • Page 6 ZigBee® network via the internet is the remote IP address and the port number. Figure 3: A Telnet Session to the EAP-E In order to change the configuration data, such as the port number simply open a telnet connection to port number 9999, which is the configuration port and follow the setup menu.

  • Page 7: Creating Virtual Com Ports

    The DeviceInstaller is used to change the configuration of the EAP-E on the Ethernet side. In most cases there is no need to alter any of the Ethernet settings and so the DeviceInstaller can usually be ignored.
  • Page 8 Product Manual 1.02 ETRX2CF or the EAP-E in the same way, you can map the EAP-E to a virtual COM port in the same way as you can do with the USB and CF devices. For this purpose Lantronix® provides a COM port redirector (CPR) software for use with their products.
  • Page 9 Figure 5. The Lantronix® CPR After this process any application can access the embedded ETRX2 as though it was connected to the local machine’s COM port as shown in Figure 6. ©2008 Telegesis (UK) Ltd EAP-E Product Manual (Rev 1.02)
  • Page 10 Telegesis TG-EAPE-PM-006-102 EAP-E Product Manual 1.02 Figure 6: Telegesis Terminal accessing a EAP-E using CPR ©2008 Telegesis (UK) Ltd EAP-E Product Manual (Rev 1.02)

  • Page 11: Firmware Changes And Upgrades

    Finally with the advent of EmberZNet3.x it is now possible to download the Ember EZSP (Ember ZigBee® Serial Protocol) as described in section 6 of the EM260 manual to the EAP-E. In case require...

  • Page 12: Schematics

    1.02 6 Schematics The schematic of the EAP-E is shown on the next page for reference. LED1 and the beeper are future options, which are not fitted. The serial port including the handshaking lines as well as the reset and A/D2 lines can be accessed via labelled pads.
  • Page 13 Telegesis TG-EAPE-PM-006-102 EAP-E Product Manual 1.02 ©2008 Telegesis (UK) Ltd EAP-E Product Manual (Rev 1.02)

  • Page 14: Ordering Information

    Where customers wish to program custom firmware they can simply overwrite the existing firmware • Please contact Telegesis if you require additional AT style commands or specific integration assistance. Table 3. Ordering Information ©2008 Telegesis (UK) Ltd EAP-E Product Manual (Rev 1.02)

  • Page 15: Trademarks

    Telegesis (UK) Limited Marlow Business Centre 84 Station Road Marlow Bucks. SL7 1NX Tel: +44 (0)1628 894347 Fax: +44 (0)1628 894333 11 References Telegesis - www.telegesis.com Ember - www.ember.com Lantronix - www.lantronix.com ©2008 Telegesis (UK) Ltd EAP-E Product Manual (Rev 1.02)
