License Agreement Published: Dec 2006 Copyright 2005 V One Multimedia Pte Ltd. All rights reserved. No part of this documentation may be reproduced in any form or by any means or used to make any derivative work (such as translation, transformation or adaptation) without permissions from V One Multimedia Pte Ltd. -
Page 3: Table Of Contents
Contents About This Guide Important Instructions Safety Information Handling Cautions Introduction What Is H.264 HDTV Receiver Key Features Before You Start Package Contents Front Panel Illustration Rear Panel Illustration Remote Control Tour Hardware Setup Choosing a Connection Audio System Connections Configuring H.264 HDTV Receiver Powering On Things to remember... -
Page 4: About This Guide
About This Guide This HDTV Receiver Family user guide covers the detail to setup and enjoy the High Definition Digital Terrestrial TV. The User Guide explains each of the available option in detail. Chapter 1, “Introduction”, describes the basic functionalities of hardware, an in depth look at the hardware components available on the unit and the remote control. -
Page 5: Important Instructions
Important Instructions Please read this section carefully in order to ensure your maximum safety while using the device. The cautionary items will help you to prevent yourself completely from exposure to the risk of any electric shock and the safe operations of the device. -
Page 6: Introduction
Chapter Introduction Welcome and thank you for purchasing H.264 HDTV Receiver. Before you proceed to this product, we recommend you read this user manual to get an overview of the product. This chapter provides an introduction to HDTV Receiver and quick steps to configure the product. What Is H.264 HDTV Receiver H.264 HDTV is a future proof state of the art High Definition digital terrestrial receiver. -
Page 7: Before You Start
Before You Start Package Contents H.264 HDTV Receiver One Remote Controller One pair of battery One RCA cables (3) x 2 (1 yellow, 1 red and 1 white). One user manual Product Registration and Warranty card. Install Batteries in the Remote Control Open the battery cover on the back of the Remote Control... -
Page 8: Front Panel Illustration
Digital Receiver Description Front Panel Illustration SZ132X Illustration 1: Power Button When switched on (Down), the device is powered on and when switched off (Up), the device can be turned off 2: Remote Control Receiver Remote Control signals are being received via this receiver. Remote Control must be within 4-6 meter range from this... - Page 9 SZ130X, VA086X Illustration 1: External Infra Red Connect provided IR cable with this jack. This additional RF is helpful to extend the range with cable and where the STB can not be placed on front. 2: Remote Control Receiver Remote Control signals are being received via this receiver. Remote Control must be within 4-6 meter range from this part 3: LED DTV and HD LED provide device status indication for the output resolution selected.
-
Page 10: Rear Panel Illustration
Rear Panel Illustration SZ132X Illustration 1: Antenna Input Connect your aerial input for receiving digital terrestrial transmission 2: 10/100 Mbps Ethernet RJ-45 Ethernet connection for future expandability 3: Digital Video Output Connect DVI or HDMI (model dependent) output from the Digital Receiver to your High Definition... - Page 11 SZ130X , VA086X Illustration 1: Fan Temperature controlling fan 2: Composite Output Connect Composite output to your analog television. 3: RS – 232 For Debuging. Only for engineering use 4: Component Output Connect component output from the Digital Receiver to your High Definition Television/LCD/Plasma/Projector. 5: Left/Right Stereo Audio Outputs Connect Left and Right audio outputs from the rear of the HDTV Receiver to your stereo system 6: RF Loop...
-
Page 12: Remote Control Tour
Remote Control Tour 1. Power (Standby) 2. Alphanumeric 3. Clear 4. Tv Mode 5. Setup 6. PBC 7. Up/Down Left/Right 8. Return 9. Skip Prev 10. Repeat 11. Info 12. Shuffle 13. Angle/Rotate 14. Select 15. Volume (+) 16. Volume (-) 17. - Page 13 1: POWER (Standby) 15: VOLUME (+) Toggle between operations / Standby Mode 2: ALPHANUMERIC INPUT 16: VOLUME (-) Enters TV channel number or Decrease the volume edit channel information 3: CLEAR 17: MUTE Deletes the characters immediately Mute on/off before the cursor 4: TV MODE (Video Output Selection) 18: ENTER Switches the receiver’s output mode...
-
Page 14: Hardware Setup
Chapter Hardware Setup Choosing a Connection The following chapter shows examples of connections commonly used to connect the HDTV Receiver with the TV/HDTV and other components. There are a number of ways to connect the player to an AV system depending on the type of TV and other AV equipment in your existing system. - Page 15 Connection to a TV (Composite Video) Using video/audio cables, connect the VIDEO (yellow)/AUDIO (Red-FR & White-FL) OUT terminals on the rear of the player to the VIDEO IN terminals of your TV Turn on the HDTV Receiver and TV Press the TV Mode button on your remote control until the video signal from the player appears on the TV screen Connection to a TV (S-Video)
- Page 16 Consult your TV User’s Manual to find out if your TV supports Progressive Scan. Depending on your TV, the connection method may differ from the illustration used here. Using component video cables, connect the COMPONENT VIDEO OUT terminals on the rear of the receiver to the COMPONENT IN terminals of your TV Using the AUDIO (Red-FR &...
-
Page 17: Audio System Connections
Audio System Connections HDTV Receiver can either be connected with a two-channel analog stereo or Digital Audio Out on Optical and Coaxial. Connection to an Audio System (2 Channel Amplifier) Using the audio cables, connect the AUDIO (Red-FR & White-FL) OUT terminals on the rear of the receiver to the AUDIO IN terminals of the Amplifier... - Page 18 Connection to an Audio System (Multi-channel) for Dolby Digital/MPEG-2/DTS If using an optical cable, connect the DIGITAL AUDIO OUT (OPTICAL) terminal on the rear of the receiver to the DIGITAL AUDIO IN terminal of the Amplifier. If using Coaxial cable, connect the DIGITAL AUDIO OUT (COAXIAL) terminal on the rear of the receiver to the DIGITAL AUDIO IN...
-
Page 19: Configuring H.264 Hdtv Receiver
Chapter Configuring H.264 HDTV Receiver This chapter provides you quick setup instructions to enjoy viewing HDTV. In this chapter we assume that you have already done the Hardware Setup for connecting your Antenna and AV to the HDTV receiver, as explained in Chapter 2. -
Page 20: Auto Scan
Auto Scan If your receiver is connected to an aerial and television, you can automatically search channels without additional information. This is the easiest way for scanning all channels. Otherwise use the Setup button to perform following: Press the Setup button on the remote control to invoke the HDTV Receiver’s setup options. Navigate to the channel tab using the Up/Down keys on your remote control and press Enter. - Page 21 Receiver will start scanning for available channels. Please wait for the Receiver to finish the channel scan. This process will take a couple of minutes to complete. Once all channels are scanned, please press Return followed by Setup to complete the process and start watching available TV channels. At any time if you want to stop channel scanning, press Stop button on your remote control After channel scan is finished, the results will automatically be saved.
-
Page 22: Manual Scanning
Manual Scanning If your receiver is connected to the antenna and television, you can also scan all channels by manually entering the parameters. Press the Setup button on the remote control to invoke HDTV Receiver’s setup options. Using the Remote Control’s direction buttons for Up/Down, navigate to the Channel tab and press Enter. Select Search Channel option and click OK. -
Page 23: System Options
Chapter System Options This chapter includes important information about setting system parameters before we start using the HDTV Receiver. These parameters will affect the audio/video performance of the receiver and requires understanding about some AV knowledge. TV System Setup TV system setup options relate to the display device and its capabilities. HDTV Receiver supports Composite/S- Video, Component, DVI or HDMI (model dependent). -
Page 24: Setting Aspect Ratio
Once you’ve chosen the appropriate video output option, you can now return to the main menu by pressing Return on Remote to make other changes. Upon quitting the Setup, HDTV Receiver will automatically save all the changes. During this time, an OSD message will appear on screen. After you set this option, you don’t need to press the TV Setup on the remote control to bring the image on your display device. -
Page 25: Setting Picture Quality
Setting Picture Quality HDTV Receiver allows you to modify the video controls of your receiver to change Brightness, Contrast, Color and Tint values to adjust them manually according to your display requirements. Press the Setup button on the remote control to invoke HDTV Receiver’s Setup Options. Using Remote Control navigation keys select Picture Tab on the left hand side as shown above. -
Page 26: Lock Password
Lock Password Lock password is used to prevent the loss of preferred options from resetting the device. Only users who know the password will be able to reset the device in case of any problem. Press Setup, navigate to Lock tab and press Enter on your remote control. -
Page 27: Customer Support
Online Chat Support SnaZio* serves its valued international customers through online chat support, the fastest and effective way of getting help. Our Engineers are online to provide you the technical support. Chatting with a support department is just a click away. - Page 28 International : 54 Kallang Bahru #02-04 Singapore 339336 Tel : 6391-3088 Fax : 6391-3033 All identified brands and product names are trademarks or registered trademarks of their respective owners. Printed in Singapore P/N : 78-001-9101 1st Edition...
