Seating system
TECHNICAL MANUAL
EN
Sedeo Lite / Pro

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lite and is the answer not in the manual?

Questions and answers

Related Manuals for Sedeo Lite

Summary of Contents for Sedeo Lite

  • Page 1 Seating system TECHNICAL MANUAL Sedeo Lite / Pro...
  • Page 2 Sedeo Lite/Pro...
  • Page 3 Sedeo Lite/Pro © 2016 Sunrise Medical All rights reserved. The information provided herein may not be reproduced and/or published in any form, by print, photoprint, microfilm or any other means whatsoever (electronically or mechanically) without the prior written authorization of Sunrise Medical.

  • Page 4: Table Of Contents

    32 Sedeo Pro / Lighting on seat frame 33 Sedeo Pro / Abduction support 34 Sedeo Pro / Hemiplegia armrest - Side cushions wegde shaped - Mirror - Armrest bag 35 Sedeo Pro / Positioning belt - Cane holder - Thigh support...

  • Page 5: Sedeo Lite/Pro

    Sedeo Lite/Pro 40 Sedeo Original / Manually elevating legrest (End of Life parts) 41 Sedeo Original / Electrically elevating legrest (End of Life parts) Service instructions ............................75 Maintenance plan / Reimbursement plan Assembling, replacement and adjustment instructions Sedeo Lite 5.2.1...

  • Page 6: Introduction

    1.1 This manual This manual contains the instructions for repairs and general maintenance of the Sedeo seating system (Sedeo Lite/Pro). Mechanics who do repairs on this seating system must be well trained and familiar with the repair methods and the maintenance of the seating system.

  • Page 7: Symbols Used In This Manual

    Sedeo Lite/Pro Introduction | 7 Introduction | 7 1.3 Symbols used in this manual Warning symbol Follow the instructions next to this symbol closely. Not paying careful attention to these instructions could result in physical injury or damage to the seating system or the environment.

  • Page 8: Safety

    8 | Safety Sedeo Lite/Pro Safety 2.1 Personnel qualification Service technicians: Repairs may only be carried out by trained and authorised service technicians. During the execution of their work, they are at all times fully responsible for the fulfilment of locally applicable safety guidelines and standards.

  • Page 9: Used Decals On The Seating System

    Sedeo Lite/Pro Safety | 9 Safety | 9 Decals and instructions on the seating system Decals and instructions on the seating system • The signs, symbols and instructions affixed to the seating system comprise part of the safety facilities. They must never be covered or removed.

  • Page 10: Tools, Parts And Components

    10 | Tools, parts and components Sedeo Lite/Pro Tools, parts and components 3.1 Tools The tools below are needed for various mechanical settings and maintenance: Quantity Description Size (mm) Screwdriver, medium Screwdriver, crosshead Hammer (plastic) Chaser Open ended spanner Ring spanner...

  • Page 11: Spare Parts

    Sedeo Lite/Pro Spare parts | 11 Spare parts 4.1 Use of the parts lists This document is meant as a reference book to be used to order parts for the seating systems that are shown on the front cover. How to order: When ordering parts, please specify: •...

  • Page 12: Sedeo Lite

    12 | Spare parts Sedeo Lite/Pro 4.2 Sedeo Lite Article number Description Description Page Seat frame Seat cushion Backrest frame Backrest cushion Standard legrest Comfort legrest Removable armrest Headrest Joystick bracket Lighting Positioning belt...

  • Page 13: Sedeo Lite / Seat Frame

    Sedeo Lite/Pro Spare parts | 13 1 Sedeo Lite / Seat frame 23a 23b 23c 23d 24a 24b 24c 24d 19a 20a 21a 22a 19b 20b 21b 22b 11 12 Article number Description 1015338 Torx iso14579 cil.head M6x50 (100 pieces)

  • Page 14: Sedeo Lite / Seat Cushion

    14 | Spare parts Sedeo Lite/Pro 2 Sedeo Lite / Seat cushion 1a 1b 1c 1d 2a 2b 2c 2d 3a 3b 3c 3d 4b 4c 4d EV_03A_SedeoLite Article number Description 3104365 Seat cushion 42x39 cm 58602 Seat cushion 45x39 cm...

  • Page 15: Sedeo Lite / Backrest Frame

    Sedeo Lite/Pro Spare parts | 15 3 Sedeo Lite / Backrest frame EV_05C_SedeoLite Article number Description 1015341 Torx Countersunk socket head screw M6x35 din7991T (100 pieces) 1-6b 1012961 Comfort Backrest mounting set 1-2b,4,5 1014903 Mounting bracket set comfort Backrest for Backrest frame SW 45 cm...

  • Page 16: Sedeo Lite / Backrest Cushion

    16 | Spare parts Sedeo Lite/Pro 4 Sedeo Lite / Backrest cushion 1b 1c 1d 3a 3b 3c 3d 5a 5b 5c 5d EV_04A_SedeoLite Article number Description 1a,2 1012950 Backrest sling SW 42 cm 1b,2 1012951 Backrest sling SW 45 cm...

  • Page 17: Sedeo Lite / Standard Legrest

    Sedeo Lite/Pro Spare parts | 17 5 Sedeo Lite / Standard legrest 2a 2b 8a 9a 10a 11a 8b 9b 10b 11b EV_06B_SedeoLite Article number Description 1012934 Standard legrest upper part assy 2a-5 1012932 Legrest socket, right 2b-5 1012931 Legrest socket, left...

  • Page 18: Sedeo Lite / Manually Elevating Legrest

    18 | Spare parts Sedeo Lite/Pro 6 Sedeo Lite / Manually elevating legrest 1a 1b 2a 3a 4a 5a 2b 3b 4b 5b EV_07A_SedeoLite Article number Description 3353521 Manually elevating legrest upper part right 3353522 Manually elevating legrest upper part left...

  • Page 19: Sedeo Lite / Removable Armrest

    Armrest pad 30 cm, left 3,10 1010911 Side plate PA 3,9,10 1016191 Side plate PA set incl mounting bracket Sedeo Lite 1012939 Armrest upper part 1015340 Torx countersunk socket head screw M6x20 Iso10642 Precote 85 (100 pieces) 1012938 Armrest middle part...

  • Page 20: Sedeo Lite / Headrest

    Torx socket head screw M6x12 iso10642 (100 pieces) 1010954 Headrest metal parts 1012949 Headrest metal part reciever Lock nut M6 D985/8/VZ 1015341 Torx countersunk socket head screw M6x35 din7991T (100 pieces) 1a,2-8 1016182 Headrest small with metal parts and reciever Sedeo Lite...

  • Page 21: Sedeo Lite / Joystick Bracket

    Sedeo Lite/Pro Spare parts | 21 9 Sedeo Lite / Joystick bracket Article number Description 1010949 Remote interface bracket 1010881 Clamp nut (10 pieces) 2-4, 7, 8 1010950 Remote Armrest bracket 1015330 Torx socket head screw M6x8 din7984T Precote 85 (100 pieces)

  • Page 22: Sedeo Lite / Lighting

    22 | Spare parts Sedeo Lite/Pro 10 Sedeo Lite / Lighting Article number Description 6002661 Front light module standard 6000038 Front light module StVZO 1012957 Front light module incl mounting bracket, left = right 1-13 1014907 Lighting set Shark 1-13...

  • Page 23: Sedeo Lite / Positioning Belt

    Sedeo Lite/Pro Spare parts | 23 11 Sedeo Lite / Positioning belt 1a 1b Article number Description 1a,2 1010991 Positioning belt short 1b,2 1010992 Positioning belt long Distance bush 13,5 x 8,5 x 5 mm...

  • Page 24: Sedeo Pro

    Sedeo Pro / Lighting on seat frame Sedeo Pro / Abduction support Sedeo Pro / Hemiplegia armrest - Side cushions wegde shaped - Mirror - Armrest bag Sedeo Pro / Positioning belt - Cane holder - Thigh support Sedeo Pro / Worktops manual wheelchair...

  • Page 25: Sedeo Pro / Seat Frame

    Sedeo Lite/Pro Spare parts | 25 12 Sedeo Pro / Seat frame 58 57 Article number Description Qty Article no Description 1015338 Torx iso14579 cil.head M6x50 (100 pieces) 1010873 Legrest clamp, set 1010880 Armrest holder 4-11,13,15a,16a,17-36,38,39, 1016184 Seat frame complete with backrest with gasspring...
  • Page 26 26 | Spare parts Sedeo Lite/Pro Continued from 12 Sedeo Pro / Seat frame Article number Description 1015133 Clamp nut profile for backrest frame (10 pieces) 26,29 1010895 Cover Backrest frame (set, left = right) 1015331 Torx socket head screw M6x10 iso14579 Precote 85 (100 pieces)

  • Page 27: Sedeo Pro / Push Bar

    Push handle, left 1010894 Wing screw M6x25 (10 pieces) 1010893 Push handle locking clip 1010892 Push grip (set of 2) 1015340 Torx countersunk socket head screw M6x20 iso10642 Precote 85 (100 pieces) 9004109 Foam for push bar, angle adjustable, Sedeo Pro...

  • Page 28: Sedeo Pro / Seat Cushion

    28 | Spare parts Sedeo Lite/Pro 14 Sedeo Pro / Seat cushion 9004482B Article number Description 1010953 Seat cushion mounting set 1015346 Torx socket head screw M5x16 T30 (100 pieces) 1012267 Interface board Sedeo original 1011726 Seat cushion padded 42x50 Stretch Rubber...
  • Page 29 Sedeo Lite/Pro Spare parts | 29 Continued from 14 Sedeo Pro / Seat cushion Article number Description 1-5,7,8 1011666 Seat cushion padded 50x50 Comfort 1-5,7,8 1011667 Seat cushion padded 50x54 Comfort 1-5,7,8 1011668 Seat cushion padded 50x58 Comfort 1-5,7,8 1011669...
  • Page 30 30 | Spare parts Sedeo Lite/Pro Continued from 14 Sedeo Pro / Seat cushion Article number Description 1-5,7,8 1011677 Seat cushion memory foam 46x54 Comfort 1-5,7,8 1011678 Seat cushion memory foam 46x58 Comfort 1-5,7,8 1011679 Seat cushion memory foam 50x50 Comfort...
  • Page 31 Sedeo Lite/Pro Spare parts | 31 Continued from 14 Sedeo Pro / Seat cushion Article number Description 1-5,7,8 1011687 Seat cushion support 42x58 Comfort 1-5,7,8 1011688 Seat cushion support 46x50 Comfort 1-5,7,8 1011689 Seat cushion support 46x54 Comfort 1-5,7,8 1011690...
  • Page 32 32 | Spare parts Sedeo Lite/Pro Continued from 14 Sedeo Pro / Seat cushion Article number Description 9005007 Cover seat cushion support TR with memory foam 42x50 Stretch Rubber 9005008 Cover seat cushion support TR with memory foam 42x54 Stretch Rubber...
  • Page 33 Sedeo Lite/Pro Spare parts | 33 Continued from 14 Sedeo Pro / Seat cushion Article number Description 9008336 Form seat 54x58 Stretch rubber 9008138 Cover form seat 42x50 Stretch rubber 9008139 Cover form seat 42x54 Stretch rubber 9008140 Cover form seat 42x58 Stretch rubber...
  • Page 34 34 | Spare parts Sedeo Lite/Pro Continued from 14 Sedeo Pro / Seat cushion Article number Description 9004942 Cover seat cushion balance 54x50 Comfort 9004943 Cover seat cushion balance 54x54 Comfort 9004944 Cover seat cushion balance 54x58 Comfort 9005563 Top cover seat cushion balance 42x50 Comfort...
  • Page 35 Sedeo Lite/Pro Spare parts | 35 Continued from 14 Sedeo Pro / Seat cushion Article number Description 9008437 Cover seat cushion fluid 50x54 Comfort 9008438 Cover seat cushion fluid 50x58 Comfort 9008439 Cover seat cushion fluid 54x50 Comfort 9008440 Cover seat cushion fluid 54x54 Comfort...
  • Page 36 36 | Spare parts Sedeo Lite/Pro Continued from 14 Sedeo Pro / Seat cushion Article number Description 9008374 Seat cushion pan 7,5 cm, 46x58 Sellaskin 9008375 Seat cushion pan 7,5 cm, 50x50 Sellaskin 9008376 Seat cushion pan 7,5 cm, 50x54 Sellaskin...
  • Page 37 Sedeo Lite/Pro Spare parts | 37 Continued from 14 Sedeo Pro / Seat cushion Article number Description 1015093 Sellaskin Sedeo Pro (per meter) 1015091 Comfort fabric (per meter) 00004.0291 Black Stretch Rubber (per meter)

  • Page 38: Sedeo Pro / Backrest

    38 | Spare parts Sedeo Lite/Pro 15 Sedeo Pro / Backrest 9004483C Article number Description 1,4,5,8 1010888 Backrest mounting plate, set 2,3,6,7 1010889 Backrest mounting, set 1015344 Torx countersunk head screw M5x25 T30 (100 pieces) 1010881 Clamp nut (10 pieces)
  • Page 39 Sedeo Lite/Pro Spare parts | 39 Continued from 15 Sedeo Pro / Backrest Article number Description 2,3,6,7,9,11,12 1012145 Backrest padded 50 x 56 Comfort 2,3,6,7,9,11,12 1012146 Backrest padded 54 x 50 Comfort 2,3,6,7,9,11,12 1012147 Backrest padded 54 x 56 Comfort...
  • Page 40 40 | Spare parts Sedeo Lite/Pro Continued from 15 Sedeo Pro / Backrest Article number Description 9005386 Top cover backrest webbed 50 x 56 Comfort 9005387 Top cover backrest webbed 54 x 50 Comfort 9005388 Top cover backrest webbed 54 x 56 Comfort...
  • Page 41 Sedeo Lite/Pro Spare parts | 41 Continued from 15 Sedeo Pro / Backrest Article number Description 9005482 Cover backrest with adjustable straps passive 50 x 56 Stretch Rubber 9005483 Cover backrest with adjustable straps passive 54 x 50 Stretch Rubber...
  • Page 42 42 | Spare parts Sedeo Lite/Pro Continued from 15 Sedeo Pro / Backrest Article number Description 11-12 9005346 Cover backrest with adjustable straps active 50 x 56 Comfort 11-12 9005347 Cover backrest with adjustable straps active 54 x 50 Comfort...

  • Page 43: Sedeo Pro / Backrest Flexible

    Sedeo Lite/Pro Spare parts | 43 16 Sedeo Pro / Backrest flexible Article number Description 1,3,4 1010986 Angle adjustable backrest mounting, set 1015344 Torx countersunk head screw M5x25 T30 (100 pieces) 1015330 Torx socket head screw M6x8 din7984T Precote 85 (100 pieces) 1017704 Headrest mounting bracket for flexible backrest >2014...
  • Page 44 44 | Spare parts Sedeo Lite/Pro Continued from 16 Sedeo Pro / Backrest flexible Article no Description 9005353 Cover backrest flexible with adjustable straps passive 50 x 50 Comfort 9005354 Cover backrest flexible with adjustable straps passive 50 x 56 Comfort...
  • Page 45 Sedeo Lite/Pro Spare parts | 45 Continued from 16 Sedeo Pro / Backrest flexible Article number Description 9005363 Cover backrest flexible with adjustable straps active 54 x 50 Comfort 9005364 Cover backrest flexible with adjustable straps active 54 x 56 Comfort...
  • Page 46 46 | Spare parts Sedeo Lite/Pro Continued from 16 Sedeo Pro / Backrest flexible Article number Description 9008098 Cover extra deep backrest flexible with adjustable straps active 50 x 56 Comfort 9008099 Cover extra deep backrest flexible with adjustable straps active 54 x 44 Comfort...

  • Page 47: Sedeo Original / Mounting Bracket For Legrest

    Sedeo Lite/Pro Spare parts | 47 17 Sedeo Original / Mounting bracket for legrest Article number Description 9001156 Legrest holder right 9001155 Legrest holder left 1015338 Torx socket head screw M6x50 iso 14579 (100 pieces) 1010873 Legrest clamp, set 9002923...

  • Page 48: Mounting Bracket For Heavy Duty Legrest

    48 | Spare parts Sedeo Lite/Pro 18 Mounting bracket for heavy duty legrest Article number Description 1a,2-4 1016567 Legrest insert tube heavy duty, right 1b,2-4 1016568 Legrest insert tube heavy duty, left 1016569 Legrest insert tube heavy duty, set 1010873...

  • Page 49: Standard Legrest (For Sedeo Original Standard Legrest See Section 39)

    Sedeo Lite/Pro Spare parts | 49 19 Standard legrest (for Sedeo Original standard legrest see section 39) Article number Description 1,2,3a,3b 1018304 Standard legrest set with calfstrap SW 42-46 3000559 Calf strap, incl. mounting set 6000310 Calf strap extended SW 54, incl. mounting set...

  • Page 50: Manually Elevating Legrest (For Sedeo Original Manually Elevating Legrest See Section 40)

    50 | Spare parts Sedeo Lite/Pro 20 Manually elevating legrest (for Sedeo Original manually elevating legrest see section 40) Article number Description 1018305 Manually elevating legrest set with calfplates SW 42-46 1,2a,3,4a 1018291 Manually elevating legrest RHS SW 42-46 cm...

  • Page 51: Electrically Elevating Legrest (For Sedeo Original Electrically Elevating Legrest See Section 41)

    Sedeo Lite/Pro Spare parts | 51 21 Electrically elevating legrest (for Sedeo Original electrically elevating legrest see section 41) Article number Description 1018306 Electrically elevating legrest set with calfplates SW 42-46 1,2,3a 1018297 Electrically elevating legrest RHS SW 42-46 cm...

  • Page 52: Standard Heavy Duty Legrest

    52 | Spare parts Sedeo Lite/Pro 22 Standard heavy duty legrest Article number Description 14003 Upper tube standard leg rest, left 14004 Upper tube standard leg rest, right 14005 Leg rest release lever, left 14006 Leg rest release lever, right...

  • Page 53: Comfort Heavy Duty Legrest

    Sedeo Lite/Pro Spare parts | 53 23 Comfort heavy duty legrest Article number Description 14007 Lower tube, leg rest 14005 Leg rest release lever, left 14006 Leg rest release lever, right 14036 Operating lever for comfort leg rest 14015 Leg rest head for comfort leg rest, left...

  • Page 54: Sedeo Pro / Central Legrest

    54 | Spare parts Sedeo Lite/Pro 24 Sedeo Pro / Central legrest 12 13 14 20 21 19a,19b Article number Description 1010941 Standard central legrest upper part 1-10,16-18 1011156 Standard central legrest 1-18 1011157 Standard central legrest with calf plate...

  • Page 55: Sedeo Pro / Manually Elevating Central Legrest

    Sedeo Lite/Pro Spare parts | 55 25 Sedeo Pro / Manually elevating central legrest 13 14 15 25 26 24a,24b Article number Description 1-4,18-23 1010944 Manually elevating central legrest upper part 1-11,18-23 1011158 Manually elevating central legrest 1-16,18-23 1011159 Manually elevating central legrest with calf plate...

  • Page 56: Sedeo Pro / Electrically Elevating Central Legrest

    56 | Spare parts Sedeo Lite/Pro 26 Sedeo Pro / Electrically elevating central legrest (only i.c.w. R-net/DX2) 26a,26b Article number Description 1016763 Front cover 1016764 Axle cover 1016778 Torx countersunk socket head screw M6x10 ISO10642 (100 pieces) 4,6,26a,27,28 1016774 Calf plate bracket complete with calf plates...

  • Page 57: Sedeo Pro / Removable Armrest

    Sedeo Lite/Pro Spare parts | 57 27 Sedeo Pro / Removable armrest 3a, 4a, 5a, 22a 3b, 4b, 5b, 22b 1, 2 15a,16a 15b,16b 19a,20a 19b,20b Article number Description 1,13 1010911 Side plate PA 1,9,11,12a,12b,13 1016186 Side plate PA set incl mounting bracket...

  • Page 58: Sedeo Pro / Flip Up Armrest

    58 | Spare parts Sedeo Lite/Pro 28 Sedeo Pro / Flip up armrest 3a, 4a, 5a 3b, 4b, 5b 1, 2 15a,16a 15b,16b 9004465C Article number Description 1,13 1010911 Side plate PA 2,13 1010912 Side support PU 3a,6 1010905 Armrest pad 40 cm, right...

  • Page 59: Sedeo Pro / Headrest

    Sedeo Lite/Pro Spare parts | 59 29 Sedeo Pro / Headrest 1, 2, 3 Article number Description 1010957 Headrest small 1,4,5,6,7,11 1015354 Headrest small with metal parts and receiver for mounting on push bar 1010996 Headrest large 1010997 Headrest flexible...

  • Page 60: Sedeo Pro / Joystick Bracket

    60 | Spare parts Sedeo Lite/Pro 30 Sedeo Pro / Joystick bracket Article number Description 1010949 Remote interface bracket 1010881 Clamp nut (10 pieces) 2-4, 7, 8 1010950 Remote Armrest bracket 1015330 Torx socket head screw M6x8 din7984T Precote 85 (100 pieces)

  • Page 61: Sedeo Pro / Lighting On Flip Up Armrest

    Sedeo Lite/Pro Spare parts | 61 31 Sedeo Pro / Lighting on flip up armrest Article number Description 6002661 Front light module standard 6000038 Front light module StVZO 1010959 Front light module for mounting on flip up armrest, left = right...

  • Page 62: Sedeo Pro / Lighting On Seat Frame

    62 | Spare parts Sedeo Lite/Pro 32 Sedeo Pro / Lighting on seat frame Article number Description 6002661 Front light module standard 6000038 Front light module StVZO 1,2a-9 1015810 Front light module for mounting on seat frame, left = right...

  • Page 63: Sedeo Pro / Abduction Support

    Sedeo Lite/Pro Spare parts | 63 33 Sedeo Pro / Abduction support Article number Description 1011002 Abduction support 1015342 Torx countersunk socket head screw M6x70 iso10642 (100 pieces) Lock nut M6 D985/8/VZ...

  • Page 64: Sedeo Pro / Hemiplegia Armrest - Side Cushions Wegde Shaped - Mirror - Armrest Bag

    64 | Spare parts Sedeo Lite/Pro 34 Sedeo Pro / Hemiplegia armrest - Side cushions wegde shaped - Mirror - Armrest bag 11 12 9004466A Article number Description 1010977 Hemiplegia armrest 1015333 Torx socket head screw M6x16 iso14579 Precote 85 (100 pieces)

  • Page 65: Sedeo Pro / Positioning Belt - Cane Holder - Thigh Support

    Sedeo Lite/Pro Spare parts | 65 35 Sedeo Pro / Positioning belt - Cane holder - Thigh support 11 12 Article number Description 1a,2,3,10-12 1010991 Positioning belt short 1b,2,3,10-12 1010992 Positioning belt long 1015331 Torx socket head screw M6x10 iso 14579 Precote 85 (100 pieces)

  • Page 66: Sedeo Pro / Worktops Manual Wheelchair

    66 | Spare parts Sedeo Lite/Pro 36 Sedeo Pro / Worktops manual wheelchair Article number Description 1,6,8 1015155 Worktop, fixed, acrylic 2,7,8 1015160 Worktop, folding, acrylic 1015170 Half worktop, acrylic 4,6,8 1015159 Worktop, fixed, acrylic, with raised edges, suitable for upholstery...

  • Page 67: Sedeo Pro / Worktops Power Wheelchair

    Sedeo Lite/Pro Spare parts | 67 37 Sedeo Pro / Worktops power wheelchair 1a 1b 2a 2b 5a 5b EV-21B Article number Description 1a,8,9 1015167 Worktop, folding, acrylic + joystick recess right hand side 1b,8,9 1015168 Worktop, folding, acrylic + joystick recess left hand side...

  • Page 68: Sedeo Pro / Third Party Backrest

    9007270 Torx socket head screw M8x10 T30 iso14578 Wing bolt M8x20; L=40 1015397 Service set cable guide ø 22 (10 pieces) 1015398 Service set cable guide ø 25 (10 pieces) 1017907 Sedeo Pro seat frame with seat shell backrest frame...

  • Page 69: Sedeo Original / Standard Legrest (End Of Life Parts)

    Sedeo Original standard legrest top complete right 01503.8100 Sedeo Original standard legrest top complete left Sedeo Original standard legrests with calf strap for SW 42 cm, set (mounting 1015137 brackets included) Sedeo Original standard legrests with calf strap for SW 46 cm, set (mounting...
  • Page 70 Sedeo Lite/Pro Continued from 38 Sedeo Pro / Third party backrest Article number Description Sedeo Original standard legrests with calf strap for SW 50 cm, set (mounting 1015139 brackets included) Sedeo Original standard legrests with calf strap for SW 54 cm, set (mounting...

  • Page 71: Sedeo Original / Manually Elevating Legrest (End Of Life Parts)

    Sedeo Original manually elevating legrest upper part right 1002517 Sedeo Original manually elevating legrest upper part left 1-11 140.00351.000 Sedeo Original manually elevating legrest for SW 42 cm (size 15) right 1-11 01500.9219 Sedeo Original manually elevating legrest for SW 46 cm (size 17) right 1-11 140.00361.000...
  • Page 72 72 | Spare parts Sedeo Lite/Pro Continued from 40 Sedeo Original / Manually elevating legrest (End of Life parts) Article number Description Sedeo Original manually elevating legrests with calf support for SW 42 cm, set 1015145 (mounting brackets included) Sedeo Original manually elevating legrests with calf support for SW 46 cm, set...

  • Page 73: Sedeo Original / Electrically Elevating Legrest (End Of Life Parts)

    Sedeo Original electrically elevating legrest upper part right 1003029 Sedeo Original electrically elevating legrest upper part left 1-11 1003618 Sedeo Original electrically elevating legrest for SW 42 cm (size 15) right 1-11 01502.9013 Sedeo Original electrically elevating legrest for SW 46 cm (size 17) right 1-11...
  • Page 74 74 | Spare parts Sedeo Lite/Pro Continued from 41 Sedeo Original / Electrically elevating legrest (End of Life parts) Article number Description Sedeo Original electrically elevating legrests with calf support for SW 46 cm,set 1015150 (mounting brackets included) Sedeo Original electrically elevating legrests with calf support for SW 50 cm,set...

  • Page 75: Service Instructions

    This document is a reference book to be used to order parts for the Sedeo seating system. Assembly, replacement and adjustment instructions The paragraphs § 5.2 (Sedeo Lite) and § 5.3 (Sedeo Pro) cover illustrated assembly, replacement and adjustment instructions. Every separate visual instruction is prefaced with: •...

  • Page 76: Assembling, Replacement And Adjustment Instructions Sedeo Lite

    76 | Service instructions Sedeo Lite/Pro 5.2 Assembling, replacement and adjustment instructions Sedeo Lite 5.2.1 Replacing the backrest frames Replacing a backrest frame with a different seat width Preparation Tools used Note! Switch off the wheelchair via remote control (power wheelchair only).
  • Page 77 Sedeo Lite/Pro Service instructions | 77...
  • Page 78 78 | Service instructions Sedeo Lite/Pro Replacing a backrest sling frame for a backrest adjustable strapped frame Preparation Relevant article numbers Note! Switch off the wheelchair via remote control (power • 1012927/-28/-29/-30 Backrest frame strapped SW wheelchair only). 42/45/48/51 • 1012954/-55 Backrest with adjustable straps SW 42/48 Instructions •...
  • Page 79 Sedeo Lite/Pro Service instructions | 79...

  • Page 80: Adjusting Or Mounting The Seat Cushion Fixation Set

    • 1010953 Seat cushion fixation set the front and backside always in the same holes! The seat • 1012267 Interface board Sedeo Original board Sedeo Lite SD40 has only two positions. Ex-factory the fixation brackets on the seat board are mounted in the back position.

  • Page 81: Mounting The Standard Or Swing-Away Remote Holder

    Sedeo Lite/Pro Service instructions | 81 5.2.3 Mounting the standard or swing-away remote holder Preparation Relevant article numbers Note! Switch off the wheelchair via remote control (power • 1010951 Swing-away remote holder wheelchair only). • 1010952 Standard remote holder • 1011164 Swing-away remote holder complete Instructions •...

  • Page 82: Mounting The Lights

    82 | Service instructions Sedeo Lite/Pro 5.2.4 Mounting the lights Preparation • 9006302 Lighting harness Shark, no tilt and/or lift Note! Switch off the wheelchair via remote control (power • 9006298 Lighting harness Shark with tilt and/or lift wheelchair only).
  • Page 83 Sedeo Lite/Pro Service instructions | 83...

  • Page 84: Mounting The Positioning Belt

    84 | Service instructions Sedeo Lite/Pro 5.2.5 Mounting the positioning belt Preparation Note! Switch off the wheelchair via remote control (power wheelchair only). Instructions Note! Suitable work area required! • Follow the illustrated instructions for mounting the positioning belt short or long.

  • Page 85: Assembly, Replacement And Adjustment Instructions Sedeo Pro

    General instruction: Removing drop out protection parts Introduction Tools used Sedeo Pro has parts that are protected against dropping out, at the moment you take them out to maximum position. Parts like armrests (width/height), legrests (width/height) and sliders have such a protection.

  • Page 86: General Instruction: The Use Of The Clamp Nut

    General instruction: The use of the clamp nut Introduction Relevant article numbers Sedeo Pro is build with extrusion profiles. The clamp nut • N.a. connection is designed for strong and reliable connections and easy adjustable parts. Most part connections, mounted Tools used on extrusion profiles, have such a clamp nut connection.

  • Page 87: Replacing The Angle Adjustable/Reclining Backrests

    Sedeo Lite/Pro Service instructions | 87 5.3.3 Replacing the angle adjustable/reclining backrests Removing the angle adjustable backrest Preparation Tools used Note! Switch off the wheelchair via remote control (power wheelchair only). Instructions Note! Suitable work area required! Note! This task is a preparation for mounting the manually reclining backrest or mounting the electrically reclining backrest.
  • Page 88 88 | Service instructions Sedeo Lite/Pro...
  • Page 89 Sedeo Lite/Pro Service instructions | 89 Mounting the manually reclining backrest Preparation Tools used Note! Switch off the wheelchair via remote control (power wheelchair only). Instructions Note! Suitable work area required! Note! Before mounting the manually reclining backrest you have to remove the angle adjustable backrest.
  • Page 90 90 | Service instructions Sedeo Lite/Pro Mounting the electrically reclining backrest Preparation Tools used Note! Switch off the wheelchair via remote control (power wheelchair only). Instructions Note! Suitable work area required! Note! Before mounting the electrically reclining backrest you have to remove the angle adjustable backrest.
  • Page 91 Sedeo Lite/Pro Service instructions | 91...

  • Page 92: Mounting The Push Bars

    92 | Service instructions Sedeo Lite/Pro 5.3.4 Mounting the push bars Replacing the height adjustable push bars, or mounting the angle adjustable push bar (manual wheelchair only). Preparation Relevant article numbers N.a. • 1010890 Push handle left • 1010891 Push handle right Instructions •...
  • Page 93 Sedeo Lite/Pro Service instructions | 93 Note! Be sure you mount the two push handle locking clips.
  • Page 94 94 | Service instructions Sedeo Lite/Pro Mounting the push bar for attendant control (power wheelchair only). Preparation Tools used Note! Switch off the wheelchair via remote control (power wheelchair only). Instructions Note! Suitable work area required! • Follow the illustrated instructions for mounting the adjustable push bar for attended control.

  • Page 95: Adjusting Or Mounting The Seat Cushion Fixation Set

    • 1012267 Interface board Sedeo Original the front and backside always in the same holes! The seat board Sedeo Lite SD40 has only two positions. Ex-factory the fixation brackets on the seat board are mounted in the back position.

  • Page 96: Mounting The Backrest Cushion Fixation Set

    Relevant article numbers • 1010889 Backrest mounting set Note! Define by feeling the lowest hole at the top of the frame and the highest hole at the bottom of the frame. The unused holes are intended for the Sedeo Original seat frame!

  • Page 97: Mounting The Thoracic Supports

    Sedeo Lite/Pro Service instructions | 97 5.3.7 Mounting the thoracic supports Preparation Tools used Note! Switch off the wheelchair via remote control (power wheelchair only). Instructions Note! Suitable work area required! • Follow the illustrated instructions for mounting the Notice thoracic supports.
  • Page 98 98 | Service instructions Sedeo Lite/Pro 5.3.8 Mounting the standard legrest Preparation Relevant article numbers Note! Switch off the wheelchair via remote control. 1018285 Standard legrest RHS SW 42-46 Instructions 1018288 Standard legrest LHS SW 42-46 Note! Suitable work area required! 1018286 Standard legrest RHS SW 50 •...
  • Page 99 Sedeo Lite/Pro Service instructions | 99 140348-02-052 140348-02-053 140348-02-054 140348-02-055...
  • Page 100 100 | Service instructions Sedeo Lite/Pro 5.3.9 Mounting the manually elevating legrest Preparation Relevant article numbers Note! Switch off the wheelchair via remote control. 1018305 Manually elevating legrest set with calfplates SW 42-46 Instructions 1018291 Manually elevating legrest RHS SW 42-46 cm...
  • Page 101 Sedeo Lite/Pro Service instructions | 101 140348-02-056 4 + 5 140348-02-058 140348-02-059 4 + 5 140348-02-060b 140348-02-060a...
  • Page 102 102 | Service instructions Sedeo Lite/Pro 140348-02-061...
  • Page 103 Sedeo Lite/Pro Service instructions | 103 5.3.10 Mounting the electrically elevating legrest Preparation Relevant article numbers Note! Switch off the wheelchair via remote control. 1018306 Electrically elevating legrest set with calfplates SW 42-46 Instructions 1018297 Electrically elevating legrest RHS SW 42-46 cm...
  • Page 104 104 | Service instructions Sedeo Lite/Pro Blue Brown 140348-02-063 4 + 5 140348-02-065 140348-02-064 4 + 5 140348-02-067a 140348-02-059...
  • Page 105 Sedeo Lite/Pro Service instructions | 105 140348-02-067b 140348-02-061...

  • Page 106: Mounting The (Manually Elevating) Central Legrest

    106 | Service instructions Sedeo Lite/Pro 5.3.11 Mounting the (manually elevating) central legrest Preparation Tools used Note! Switch off the wheelchair via remote control (power wheelchair only). Instructions Note! Suitable work area required! • Follow the illustrated instructions for mounting the manually elevating central legrest •...
  • Page 107 Sedeo Lite/Pro Service instructions | 107...

  • Page 108: Mounting The Electrically Elevating Central Legrest

    108 | Service instructions Sedeo Lite/Pro 5.3.12 Mounting the electrically elevating central legrest Preparation Note! See backside of control box cover for wiring Note! Switch off the wheelchair via remote control. diagram. • Hook the seat in place and push it downwards into Instructions position.
  • Page 109 Sedeo Lite/Pro Service instructions | 109 140348-02-042 140348-02-043 140348-02-044 140348-02-045...

  • Page 110: Replacing The Actuators Of The Electrically Elevating Central Legrest

    110 | Service instructions Sedeo Lite/Pro 5.3.13 Replacing the actuators of the electrically elevating central legrest Preparation Note! See backside of control box cover for wiring Note! Switch off the wheelchair via remote control. diagram. • Hook the seat in place and push it downwards into Instructions position.
  • Page 111 Sedeo Lite/Pro Service instructions | 111 140348-02-042 140348-02-043 140348-02-044 140348-02-045...

  • Page 112: Replacing The Flip Up Armrest Hinge

    112 | Service instructions Sedeo Lite/Pro 5.3.14 Replacing the flip up armrest hinge Preparation Relevant article numbers Note! Switch off the wheelchair via remote control (power • 9007777 Flip up armrest lever wheelchair only). Tools used Instructions Note! Suitable work area required! Note! This task is a preparation for replacing the flip up armrest hinge.
  • Page 113 Sedeo Lite/Pro Service instructions | 113...

  • Page 114: Mounting The Standard Or Swing-Away Remote Holder

    114 | Service instructions Sedeo Lite/Pro 5.3.15 Mounting the standard or swing-away remote holder Preparation Relevant article numbers Note! Switch off the wheelchair via remote control (power • 1010951 Swing-away remote holder wheelchair only). • 1010952 Standard remote holder • 1011164 Swing-away remote holder complete Instructions •...
  • Page 115 Sedeo Lite/Pro Service instructions | 115 140348-02-016 Note! Notice the position of the hexagon at any bracket. The hexagon should point with an edge forward!

  • Page 116: Mounting The Lighting On Flip-Up Armrest

    116 | Service instructions Sedeo Lite/Pro 5.3.16 Mounting the lighting on flip-up armrest Preparation • 9006302 Lighting harness Shark, no tilt and/or lift Note! Switch off the wheelchair via remote control (power • 9006298 Lighting harness Shark with tilt and/or lift wheelchair only).

  • Page 117: Mounting The Abduction Support

    Sedeo Lite/Pro Service instructions | 117 5.3.17 Mounting the abduction support Preparation Tools used Note! Switch off the wheelchair via remote control (power wheelchair only). Instructions Note! Suitable work area required! • Follow the illustrated instructions for mounting the abduction support.
  • Page 118 118 | Service instructions Sedeo Lite/Pro Note! Adjust the abduction support to the desired position, see the Sedeo Pro user manual.

  • Page 119: Mounting The Hemiplegia Armrest

    Sedeo Lite/Pro Service instructions | 119 5.3.18 Mounting the hemiplegia armrest Preparation Note! Switch off the wheelchair via remote control (power wheelchair only). Instructions Note! Suitable work area required! • Follow the illustrated instructions for mounting the hemiplegia armrest. Relevant article numbers •...

  • Page 120: Mounting The Mirror

    120 | Service instructions Sedeo Lite/Pro 5.3.19 Mounting the mirror Preparation Tools used Note! Switch off the wheelchair via remote control (power wheelchair only). Instructions Note! Suitable work area required! • Follow the illustrated instructions for mounting the mirrors at both sides (joystick side, 1-4/ not joystick side,...
  • Page 121 Sedeo Lite/Pro Service instructions | 121...

  • Page 122: Mounting The Positioning Belt

    122 | Service instructions Sedeo Lite/Pro 5.3.20 Mounting the positioning belt Preparation Tools used Note! Switch off the wheelchair via remote control (power wheelchair only). Instructions Note! Suitable work area required! • Follow the illustrated instructions for mounting the positioning belt short or long.

  • Page 123: Mounting The Cane Holder

    Sedeo Lite/Pro Service instructions | 123 5.3.21 Mounting the cane holder Preparation Tools used Note! Switch off the wheelchair via remote control (power wheelchair only). Instructions Note! Suitable work area required! • Follow the illustrated instructions for mounting the cane holder.
  • Page 124 124 | Service instructions Sedeo Lite/Pro Note! Be sure you mount the two push handle locking clips.

  • Page 125: Trouble Shooting

    Sedeo Lite/Pro Trouble shooting | 125 Trouble shooting | 125 Trouble shooting If the Sedeo seating system is not working or not working as it should, contact your supplier.

  • Page 126: Specifications

    5. ISO 7176-19 Crash test. 6. EN-ISO 10993-5 (1999-11) Biological evaluation of medical devices. 7. EN 1021 1,2 Assessment of the ignitability of upholstered furniture. Ignition source: smouldering cigarete/match flame equivalent. 7.2 Technical information Sedeo Lite Description Unit Values Seating system...

  • Page 127: Technical Information Sedeo Pro

    Sedeo Lite/Pro Specifications | 127 7.3 Technical information Sedeo Pro Description Unit Values Seating system User Weight Seat width 400 - 540 Seat width (option) 520 - 680 Seat depth 440 - 600 Point of gravity Seat Seat cushion depth position...
  • Page 128 128 | Specifications Sedeo Lite/Pro Description Unit Values Headrest width, width adjustable headrest (option) -110 - 110 Controller bracket Controller bracket height Controller bracket depth Controller bracket swing away Controller bracket height Controller bracket depth Controller position angle ° 0 - 45...

  • Page 129: Warranty

    Sedeo Lite/Pro Warranty | 129 Warranty 8.1 Definitions of terms Definitions of terms used in this warranty: • After sales service part: Part purchased after the intial product that is durable and may be subjected to natural wear and tear or natural contamination during normal operation within the lifetime of the product.;...
  • Page 130 Updated drawing angle adjustable backrest mounting set • Moved section 19 to section 39 • Added new section 19 'Standard legrest (for Sedeo Original standard legrest see section 39)' • Moved section 20 to section 40 • Added new section 20 'Manually elevating legrest (for Sedeo Original manually elevating legrest see section 40)' •...
  • Page 131 Sedeo Lite/Pro | 131 | 131...
  • Page 132 Sunrise Medical Pty. Ltd. Sunrise Medical HCM B.V. 6 Healey Circuit, Huntingwood Vossenbeemd 104 NSW 2148 5705 CL Helmond Australia The Netherlands T: +61 (2) 9678 6600 T: +31 (0)492 593 888 E: enquiries@sunrisemedical.com.au E: customerservice@sunrisemedical.nl www.SunriseMedical.com.au www.SunriseMedical.nl www.SunriseMedical.eu (International) Sunrise Medical HCM B.V.

This manual is also suitable for:

Pro

Table of Contents
