Summary of Contents for e-Lvt e-Lvt
- Page 2 Waterproof Anti - pressure Durable anti-fall...
- Page 3 Thanks for using e-Lvt electronic cigarette. You have already started more healthy life and improve environmental surroundings for your families and friends from now on. Please read this manual carefully before using the product, and then use it correctly. Attention 1.
- Page 4 Products instructions Electronic cigarette e-Lvt adopts the latest intelligent integrated circuits, control circuits, executive circuits and high power output circuit; it can make the circuit and battery work perfect, extend battery life. These dual-mode constant voltage and constant power can be adjusted. Besides, you can choose different kinds...
- Page 5 Three big functions 1.Smoking Fit for 510 thread atomizer. Dual output mode (Variable voltage from 3.0-6.0V. Variable power from 3w-15w.) 2.Power bank Charge for digital products by USB cable connections 3.Linghting Press the button "-" 3 seconds to turn on /off the light...
-
Page 6: Using Instruction
Using instruction 1. Please use the packing accessories in correctly way to avoid the damage which were caused by incorrect operation. 2. If battery tube appears“LOV ”during working, please replace new battery or charge the battery. 3. Please use the 18650 charger to recharge the battery. 4. - Page 7 Description of main function Power supplying The charging way of single 18650 lithium battery is to connect the adapter and USB cable, or you can take out the battery to charge for the battery. Working parameters The quiescent current is minute, the output current is lower than 5A.
- Page 8 Method of Application 1. Put 18650 batteries into the battery box and close the battery cover. Then power on, LED shows the number 888 for three times, red, yellow, green LED will display one by one, and the digital pipe will extinguish and come into sleep mode later.
- Page 9 Method of Application 2. Starting up: Pressing the smoking button 3 times within two seconds continuously. LED will blink once in red,yellow and green light and the digital shows "ON" to enter starting mode. After the above action, the led indicator lights will show the battery capacity after pressing the smoking button.
- Page 10 Method of Application 4. Adjustment on voltage and rate of power: In the state of button unlocked, pressing the power button and "-" for 2 seconds simultaneously, the nixie tube shows "UO", which means the mode of output voltage. The output voltage will increase or decrease 0.1V when pressing "+" or "-", the adjustment situation will show on the nixie tube.
- Page 11 Method of Application 8. The nixie tube will show "OFF" when pressing "smoking key" for 3 times within 2 seconds continuously, which means turn off the battery and enter into power off, then turn into sleep mod. 9. This product can link with USB of computer through the mini USB line, then to be charged.
- Page 12 Method of Application 12. In the case of locked mod, mode conversion can be switched, but not for parameter adjustment. 13. Distinction of LED light colors: when the battery voltage is less than 3.6V; led light turn red; 3.6-3.75V turns yellow;...
- Page 13 Attention: 1.Please keep the product away from high temperature environment when the product is working or stocked. 2.Please keep the product and accessories away from children. 3 Please observe the using rules strictly. Avoid beating the product when using it. 4.Please unplug the power when clearing the charger, and stop using wet fabric.
