Nikkei NPRC56PK User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
NPRC56PK Portable radio
USER MANUAL
EN
© Elmarc, 16/11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NPRC56PK and is the answer not in the manual?

Questions and answers

Summary of Contents for Nikkei NPRC56PK

  • Page 1 NPRC56PK Portable radio USER MANUAL © Elmarc, 16/11...

  • Page 2: Table Of Contents

    Intended use Labels in this manual 1.3 General safety instructions 3 Preparations for use Unpacking 2.2 Package contents 6 Installation 3.1 Connecting to the mains 3.2 Install batteries 8 Functions NPRC56PK 4.2 General functions 10 Operation 5.1 Setting the clock 5.2 Setting an alarm 12 5.3 Using the timer 13 5.4 Radio functions 14 5.5...

  • Page 3: Safety

    1 Safety 1.1 Intended use The device functions as a portable radio/CD audio player. The device can play music (MP3) via CD, USB and SD card. Music can be played wirelessly via the bluetooth connection. It is also possible to play music via the AUX port. 5 Read the manual carefully before the first use. 1.2 Labels in this manual 6 WARNING A warning means that injury is possible if the instructions are not obeyed. 1 CAUTION A caution means that damage to the equipment is possible. 5 A note gives additional information, e.g. for a procedure. 1.3 General safety instructions 6 To prevent damage or malfunctions: Please take time and read the general safety instructions. This will avoid fire, explosions, electric shocks or other hazards that may result in damage to property and/ or severe or fatal injuries. 6 The manufacturer is not liable for sases of material damage or personal injury caused by incorrect handling or non compliance with the safety instructions. In such cases, the warrenty will be voided. 6 WARNING Do not put force on the appliance. The appliance can fall and can cause serious injury. 6 WARNING Do not insert any objects in the ventilation holes. 6 Always check that the mains voltage corresponds to the voltage on the rating plate.
  • Page 4 6 Never leave children unattended with the packing material. The packaging material represents a danger of suffocation Children frequently underestimate the danger.always keep childern away from the packaging material. 6 To prevent hearing damage, remember to adjust the volume to a comfortable level. 1 CAUTION Do not spill any liquid on the appliance. 1 CAUTION Do not block the ventilation holes. 1 Clean the outside of the appliance with a soft cloth. When the appliance is very dirty, dampen the cloth slightly with water and a neutral solution. 1 Do not expose the appliance to direct sunlight. 1 Do not put the appliance near a heat source. This could damage the appliance. 1 Check the product,cable and (if applicabl) adapter for any damage before use. If there is any visible damage,astrong odour,or excessive overheating of components, unplug the product. 1 If your product runs on batteries: Incorrect installation can cause battery leakage and corrosion which will damage the appliance. Corrosion, oxidation, battery leakage and any other gradually acidic defect of this nature will invalidate the guarantee. 1 This appliance is double insulated; therefore no earth wire is required. Always check that the mains voltage corresponds to the voltage on the rating plate.
  • Page 5 5 If this appliance is equipped with rubber feet to prevent it from moving: The feet are made from non-migrating material specially formulated to avoid leaving any marks or stains on furniture. However, certain types of furniture polishes, wood preservatives or cleaning sprays cause the rubber to soften and leave marks or a residue on the furniture, and potentially risk the surface to become damaged. To prevent damage to wooden surfaces, we recommend that you apply self-adhesive pads to the bottom of the rubber feet before installation. 5 We recommend that you retain the original carton and packing materials in case it ever becomes necessary to return your product for service. This is the only way to safely protect the product against damage in transit. If you do dispose of the carton and the packing materials, please remember to recycle with due care to the environment.

  • Page 6: Preparations For Use

    2 Preparations for use 2.1 Unpacking 6 Never leave children unattended with the packing material. The packaging material represents a danger of suffocation Children frequently underestimate the danger.always keep childern away from the packaging material. • Check the package contents as described below. If any item is missing, please contact your reseller. • Remove the labels from the front panel carefully if present. 5 We recommend that you retain the original carton and packing materials in case it ever becomes necessary to return your product for service. This is the only way to safely protect the product against damage in transit. If you do dispose of the carton and the packing materials, please remember to recycle with due care to the environment. 2.2 Package contents The following items are included in the received package: • 1 x Portable radio (NPRC56PK) • 1 x Quick start guide • 1 x Mains cable 5 If any item is missing, please contact your reseller.

  • Page 7: Installation

    3 Installation • Put the appliance on a horizontal flat surface. • Connect the appliance to the mains. 6 Check the product,cable and (if applicabl) adapter for any damage before use. If there is any visible damage,astrong odour,or excessive overheating of components, unplug the product. 1 CAUTION Do not put the appliance near a heat source. 1 CAUTION Do not expose the appliance to direct sunlight. 5 This appliance is equipped with rubber feet to prevent it from moving. The feet are made from non-migrating material specially formulated to avoid leaving any marks or stains on furniture. However, certain types of furniture polishes, wood preservatives or cleaning sprays cause the rubber to soften and leave marks or a residue on the furniture, and potentially risk the surface to become damaged. To prevent damage to wooden surfaces, we recommend that you apply self-adhesive pads to the bottom of the rubber feet before installation. 3.1 Connecting to the mains 6 Always check that the mains voltage corresponds to the voltage on the rating plate. • Connect the 8-shaped connector of the power cable to the device's power connection. • Connect the mains plug to a wall socket.

  • Page 8: Install Batteries

    3.2 Install batteries 4x AA The appliance can also be operated on battery power. For this purpose, the appliance uses 4 batteries (AA). 5 Please note: these batteries are not included. 5 If you do not use the appliance for an extended period, remove the batteries. Install batteries • Remove the battery cover. • Insert the batteries matching the (+) and (-) polarity markings. • Re-install the battery cover. 1 CAUTION Incorrect installation can cause battery leakage and corrosion which will damage the appliance. Corrosion, oxidation, battery leakage and any other gradually acidic defect of this nature will invalidate the guarantee.

  • Page 9: Functions

    4 Functions 4.1 NPRC56PK 13 14 15 16 1. Handle 2. CD compartment 3. LCD Display 4. POWER/STANDBY button 5. FUNCTION button 6. Buttons VOLUME UP/DOWN 7. PLAY MODE/PROG/CLK.SET button 8. Speaker 9. PLAY/PAUSE/PARING/MO.ST button 10. Buttons PRE-/AL1, AL2/PRE+ 11. Buttons PREV TUNE-/NEXT TUNE+ 12. STOP/SLEEP/SNOOZE button 13. AUX jack: 3.5 mm 14. USB slot 15. Memory card slot (SD/MMC) 16. Headphone jack 17. Plug contact...

  • Page 10: General Functions

    4.2 General functions FUNCTION button • To select the source mode, press the FUNCTION button (5). Digital volume control • To adjust the volume, press the VOL - (6) button or the VOL + button (6). Headphone jack (16) • To connect a headphone, insert the cable plug in the headphone jack. To prevent hearing damage, remember to adjust the volume to a comfortable level.

  • Page 11: Operation

    5 Operation 5.1 Setting the clock • Set the appliance in the standby mode. • Keep key PLAY MODE/PROG/CLK.SET (7) pressed for 2 seconds • Press the PREV TUNE- (11) or NEXT/TUNE+ (11) key to choose between 24 or 12 hour time display. • "12H" or "24H" appears on the display. • Press PLAY MODE/PROG/CLK.SET (7) to confirm. • Press the PREV TUNE- (11) or NEXT TUNE+ (11) key to set the desired hour. • Press PLAY MODE/PROG/CLK.SET (7) to confirm. • Press the PREV TUNE- (11) or NEXT TUNE+ (11) key to set the desired minutes. • Press PLAY MODE/PROG/CLK.SET (7) to confirm. 5 The time will flash in the display if it has not been set properly.

  • Page 12: Setting An Alarm

    5.2 Setting an alarm 5 Caution! You can set and activate two alarms. Alarm 1 • Set the appliance in the standby mode. • Keep key PRE-/AL1 (10) pressed for 2 seconds • AL1 appears on the display. • Press the PREV TUNE- (11) or NEXT TUNE+ (11) key to set the desired hour. • Press PRE-/AL1 (10) to confirm. • Press the PREV TUNE- (11) or NEXT TUNE+ (11) key to set the desired minutes. • Press PRE-/AL1 (10) to confirm. • To select the source mode TUNER/CD/CARD/USB/AUX/BLUETOOTH, press the PREV TUNE- (11) button NEXT/TUNE+ (11). • Press PRE-/AL1 (10) to confirm. • Press the button VOL- (6) or the button VOL+ (6) to set the volume. • Press PRE-/AL1 (10) to confirm. 5 When the source mode CD has been selected, a CD must be in the appliance. If there is no CD, the alarm will not go off. 5 When the source mode USB or CARD has been selected and there is no USB or memory card present, the radio mode will be switched on when the alarm goes off. Alarm 2 •...

  • Page 13: Using The Timer

    Snooze alarm • To snooze the alarm, press STOP/SLEEP/SNOOZE (12). The alarm sounds again after the snooze time has elapsed. The default snooze time is: 6 minutes. Turn off alarm • Press the STANDBY key once (4). 5.3 Using the timer • Select the desired source. • To do this, press the FUNCTION key (5). • Keep key STOP/SLEEP/SNOOZE (12) pressed for 2 seconds SLEEP appears on the display. • Press the button STOP/SLEEP/SNOOZE (12) repeatedly until the desired setting is found. The appliance stops playing after the chosen time has elapsed. • To cancel the SLEEP function, press the STOP/SLEEP/SNOOZE button (12).

  • Page 14: Radio Functions

    5.4 Radio functions • Slide out the antenna • To select the source mode TUNER, press the FUNCTION button (5). "FM" appears on the display. To switch between Mono and Stereo reception, press the MO/ST button (9). Automatically adjust the frequency • Keep key PLAY/PAUSE/PAIRING/MO-ST (9) pressed for 2 seconds • To skip to the next preset station, press the PRE-/AL1 button (10) or the AL2/PRE+ button (10). Adjust the frequency manually • To tune to the station of your choice, press the PREV TUNE- (11) button or the NEXT TUNE+ (11) button repeatedly until the frequency is found. Save a radiostation into the memory • Press the PLAY MODE/PROG/CLK.SET button (7). "P01". appears on the display. • Press the PRE-/AL1 or AL2/PRE+ (10) key to select a memory location. • Press PLAY MODE/PROG/CLK.SET (7) to confirm. 5 20 memory locations are available.

  • Page 15: Cd Functions

    5.5 CD functions To insert a CD: • Press the CD compartment (2) to open the appliance • Insert the CD with the label upwards • Close the CD compartment Playing a CD: 1 Make sure that no external device is connected to the AUX IN port. • To select the source mode CD, press the FUNCTION button (5). CD appears on the display. • To pause playback, press the PLAY/PAUSE button (9) once. During playback, the following functions are available: • To select a track, press the PREV TUNE- (11) button or the NEXT/TUNE+ (11) button until the desired track is set. • To forward or rewind the track, press and hold the PREV button (11) or the NEXT button (11). • To select a track, press the PREV button (11) button or the NEXT/ TUNE+ (11)button until the desired track is set. • To pause playback, press the PLAY/PAUSE button ((9)) once; to resume playback, press the button again.
  • Page 16 Program track sequence • To stop playback, press the STOP button (12). • To play a list of tracks (max. (7)) in a program, press the PLAY MODE/ PROG/CLK.SET button 20. "P01". appears on the display. MEMORY appears on the display. • Press the PREV TUNE- (11) button or the NEXT/TUNE+ (11) button to select a desired track. • Press the PLAY MODE/PROG/CLK.SET button (7) to confirm the selection. Repeat the previous step to select more tracks and confirm every selection with the PLAY MODE/PROG/CLK.SET button (7). • Press the PLAY/PAUSE/PAIRING/MO-ST button (9) to start the program. • To play the program again, press the PROG./+10 button (9) after the program has finished. Press the PLAY/PAUSE button (12) to start the program again. • To play the program again, press the PLAY MODE/PROG/CLK.SET button (7) after the program has finished. Press the PLAY/PAUSE/PAIRING/MO- ST button (9) to start the program again. • To stop the program during playback, press the STOP/SLEEP/SNOOZE button (12). • To delete the program during the playback, press the STOP/SLEEP/ SNOOZE button (12) twice.

  • Page 17: Usb And Memory Card

    5.6 USB and memory card 5 Due to the great variety of products with USB ports and their sometimes quite manufacturer-specific functions we can neither guarantee that all devices will be recognised, nor that all operating options that are possible in theory will actually work. USB functions • Insert the USB device in the slot (14). The device can only be connected one way. • To select the source mode USB, press the FUNCTION button (5). • USB appears on the display. • After connecting the appliance, the contents are loaded. • Next, the total number of tracks appears on the display (3). • Playback starts automatically. • To pause playback, press the PLAY/PAUSE button (12) once. Memory card functions • Insert the SD/MMC device in the slot. The device can only be connected one way. • To select the source mode CARD, press the FUNCTION button (5). • CARD appears on the display. • After connecting the appliance, the contents are loaded. • Next, the total number of tracks appears on the display (3). •...

  • Page 18: Aux In

    During playback, the following functions are available: • To select a track, press the PREV TUNE- (11) button or the NEXT/TUNE+ (11) button until the desired track is set. • Press and hold the PREV TUNE- (11) button or the NEXT/TUNE+ (11) button to rewind or forward the track. • To pause playback, press the PLAY/PAUSE button ((9)) once; to resume playback, press the button again. • Press the button PLAY MODE/PROG/CLK.SET (7) to select the next folder on an MP3 disc or a USB flash drive • To stop playback, press the STOP/SLEEP/SNOOZE button (12). • To remove the device, gently pull it out of the slot. 5.7 AUX IN • To connect an external audio device, insert the cable plug in the AUX IN jack ((13)). • To select the source mode AUX, press the FUNCTION button (5). • "AUX" appears on the display.

  • Page 19: Operation With Bluetooth

    A2DP. Preparation • To select the source mode BLUETOOTH, press the FUNCTION button (5). "BT" appears on the display. Your NPRC56PK is now ready to establish a wireless connection with your Bluetooth device. Establishing a Bluetooth connection (PAIREN) • Turn on the Bluetooth function of your device • Go to the Bluetooth Menu of your Bluetooth device. • Search Bluetooth devices and select NPRC56PK to establish connection • Enter "0000" when the player asks for the PIN code The blue LED remains lit as soon as the connection has been established. Making a manual Bluetooth connection. • Turn on the Bluetooth function of your device • Go to the Bluetooth Menu of your Bluetooth device. • Keep key PLAY MODE/PROG/CLK.SET (7) pressed for 3 seconds • Search Bluetooth devices and select NPRC56PK to establish connection • Enter "0000" when the player asks for the PIN code 5 NOTE: your Bluetooth connection has a range of approximately 10 metres...

  • Page 20: Auto Power System (Aps)

    Reconnect via Bluetooth If you move outside the Bluetooth range, the connection will be automatically terminated. The Bluetooth connection will be recovered again as soon as you come within the Bluetooth range. 5.9 Auto Power System (APS) The Auto Power System (APS) is intended to save energy. In the following situations, the device will go into Standby mode after 15 minutes: • After playing, the following source mode ends: CARD • To switch on the appliance, press the STANDBY button POWER/ STANDBY (4).

  • Page 21: Cleaning And Maintenance

    6 Cleaning and maintenance 6 WARNING Before performing any cleaning or maintenance, switch off and unplug the appliance. • Clean the outside of the appliance with a soft cloth. When the appliance is very dirty, dampen the cloth slightly with water and a neutral solution. 6.1 Handle and care of a disc • Hold the disc with fingers. Hold the disc outer edge and/or the centre spindle hole. Do not touch the disc surface. • Do not bend or press the disc. Do not expose the disc to direct sunlight or heating sources. • Clean the disc surface with a soft, dry cleaning cloth. Wipe the disc surface gently, radially, from centre towards the outer edge. • Do not apply thinner, alcohol, chemical solvent, or sprays when cleaning. Such cleaning fluids will permanently damage the disc surface.

  • Page 22: Specifications

    7 Specifications Voltage: 110-230VAC ~ 50/60 Hz • Power consumption: 14 Watt • Standby power consumption: < 1 Watt • Speaker output: 2 x 1,5 W RMS • Max power: 2 x 1,8 Watt RMS • Battery size: AA (4x) • Disc types: CD/ CD-R/ CD-RW • Maximum USB memory: 16 GB • Audio formats: MP3 • Frequency range: 87,5 - 108 Mhz • 20 memory locations are available. • Dimensions: 25 x 11 x 20,3 cm • Weight: 1100 g. • LCD Display • USB slot • Memory card slot (SD/MMC) • Headphone jack •...

  • Page 23: Disposal Of Used Electric And Electronic Equipment

    8 Disposal of used electric and electronic equipment The meaning of the symbol on the material, its accessory or packaging indicates that this product shall not be treated as household waste. Please, dispose of this equipment at your applicable collection point for the recycling of electrical and electronic equipments waste. In the European Union and Other European countries which there are separate collection systems for used electrical and electronic product. By ensuring the correct disposal of this product, you will help prevent potentially hazardous to the environment and to human health, which could otherwise be caused by unsuitable waste handling of this product. The recycling of materials will help conserve natural resources. Please do not therefore dispose of your old electrical and electronic equipment with your household waste. Do not dispose of batteries as household waste but take them to a battery recycling facility. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product. For more information and warranty conditions, please visit: www.nikkei.eu...
