SVT-1100 ACCESS CONTROL KEYPAD/CARD READER (SVT19130) User Manual Please read this user manual prior to installing the system, and keep it well for future use. - Page 2 Working conditions: temperature: -20 C~50 Current and voltage requirements: DC input: +12V-------15V standby current: 30mA working current: 70mA Applicable card mode: EM ID card Effective distance: 5cm ID cards capacity: 1010 PCS 1. With internal EM reader. 2. Frequency: 125KHz. 3.
- Page 3 1. Open the cover carefully following the instructions below. 2. Before push out the cover, shift the front cover up for few millimetres (Showed in the picture 2 ), then following as the picture 3 showed do uplift within the angle range of 20 degrees. Then, take the front cover away slightly.
- Page 4 1. 2 zones relays can be programmed for opening the lock, up to 1000 user cards and correlative codes can be stored into ZONE 1, 10 user cards or codes can be stored into ZONE 2 . In addition the ZONE 1 can be programmed for 3 modes to open the lock: only the card access, both the code and card access, combined access.
- Page 5 Enter the setting mode: Press the button (mode indicator will flash yellow), follow the button twice, (a continuous beep will be heard and mode indicator will turn yellow), it indicates all user cards and codes have been cleaned out successfully. Press the button (mode indicator will flash yellow), follow the button twice, (a...
- Page 6 Enter the setting mode: Press the button , the mode indicator will flash green, it indicates there is no master card stored, if the indicator turns red, it indicates there is already data existed, press the button twice to clean out the data, and then indicator will flash green, swipe the master card, a long beep will be heard, it indicates that adding success.
- Page 8 The design and specifications of this user manual can be changed without any notification to the user. All copyright and interpretation rights are reserved to SVT Innovations Inc.
