ECO Spot™ LED40DE User Manual
The ECO Spot LED40DE is intended for exterior applications but
is also suitable for interior use. Thank you for choosing an ECO
Spot™ Gobo projector. This unit is equipped with a fan cooled heat
pipe to keep the 40W High Power LED running cool. It is also
available as interior version (ES-LED40D).
Please read this manual before installing or operating this fixture,
follow the safety precautions listed below and observe all warnings.
WARNING!
To prevent damage to the LED, always connect the driver
cable to the projector FIRST before plugging it into the
power outlet.

Package Contents


Projector, External LED Driver, Test Gobo, Spare gobo retaining ring and spare drive
belt, Gobo adapter ring for E-Size Gobos

Safety Information

•
Place your fixture at a suitable place with good air flow.
•
Keep flammable materials away from the fixture.
•
Minimum distance to flammable material = 1 ft (0.3m).
•
Minimum distance to illuminated surface = 3.3 ft (1.0m).
•
Provide a minimum clearance of 4 in (10cm) around air vents.
•
Use only genuine spare parts for part replacement.
•
Do not look directly into the lamp; it can cause eye damage.
•
Always unplug the unit from the power mains before any service is done.
•
Light fixtures should be installed and maintained only by qualified personnel with
experience in lighting equipment and general electrical experience.
•
Disconnect the fixture from AC power before handling the fixture.
•
Always ground (earth) the fixture electrically.
•
Use only a power source that complies with local building and electrical codes and
has both, overload and ground-fault protection.
•
Do not use the fixture if the power cable or power plug is in any way damaged,
defective or wet, or if they show signs of overheating.
