HDMI Converter
YH0101
Model No.
Operating Instructions
Dear customer
Thank you for purchasing this product. For optimum performance and safety,
please read these instructions carefully before connecting, operating or adjusting
this product. Please keep this manual for future reference.
FEATURES
Easy to Use: Install in seconds, no need for setting.
Conversion: It could convert YPbPr and SPDIF audio into complete HDMI.
HDCP compliant.
NOTICE
Vision HD reserves the right to make changes in the hardware, packaging
and any accompanying documentation without prior written notice.
１
（P/N of this Instructions is INSYH0101）
Operating Instructions
Advertisement
Table of Contents
Related Manuals for Grandbeing YH0101
Summary of Contents for Grandbeing YH0101
- Page 1 Operating Instructions HDMI Converter YH0101 Model No. Operating Instructions （P/N of this Instructions is INSYH0101） Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference.
- Page 2 INTRODUCTION Vision HD ’s YH0101 is a component video(YPbPr) converter. It converts YPbPr input into HDMI output. YH0101 has the ability of buffering and amplifying. It achieves long-distance transmission of HDMI signal of more than 15 meters. YH0101 offers solutions for digital entertainment center, HDTV retail and show site, HDTV, STB, DVD and Projector factory, noise, space and security concerns, ２...
- Page 3 Operating Instructions data center control, information distribution, conference room presentation, school and corporate training environments. PACKAGE CONTENTS 1) Main unit. P/N_YH0101 2) 5V DC Power Adapter.P/N_VDC0502 Operating Instructions. P/N_INSYH0101 * HDMI cables are optional. PANEL DESCRIPTIONS Input Panel 1) YPbPr video input.. 2) SPDIF audio input.
- Page 4 2) Connect the HDMI device into the HDMI Output slot in the back of YH0101. 3) Insert the DC side of 5v power supply into YH0101 and then connect the AC side of the power supply into the wall outlet.
- Page 5 Operating Instructions DTV and HDTV Mid-Scale Clamping Fully Sync Processing Black and mid-level precision clamp and calibration* Input video mode status detection Digital Video Input Front End Interface ITU-R BT. 656 …… 8 bits/channel ..…………… 1 channel RGB 444 ………….. 8/10/12 bits/channel ..…..… 1/ 3 channel YCbCr 444 .…..…...
- Page 6 Operating Instructions approximate. MAINTENANCE Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzine to clean this unit. PRODUCT SERVICE 1) Damage requiring service: The unit should be serviced by qualified service personnel if: (a) The DC power supply cord or AC adaptor has been damaged; (b) Objects or liquids have gotten into the unit;...
- Page 7 Operating Instructions preferably in the original carton. Include a letter detailing the complaint and provide a day time phone and/or email address where you can be reached. IF REPAIR IS NEEDED DURING THE LIMITED WARRANTY PERIOD THE PURCHASER WILL BE REQUIRED TO FURNISH A SALES RECEIPT/PROOF OF PURCHASE INDICATING DATE OF PURCHASE, AMOUNT PAID AND PLACE OF PURCHASE.
