Summary of Contents for Dreamwave 4CH NVR KIT
-
Page 1: Quick Installation Guide
QUICK INSTALLATION GUIDE 4CH, 8CH & 16CH Surveillance System / NVR WiFi PoE Camera Kit... - Page 2 WHAT’S IN THE BOX – 4CH NVR KIT Four (4) 631H2 WiFi PoE IP Cameras 9508S WiFi AP / Router N8/1U 8 Channel IP NVR with 500GB Hard Drive POE31004P 5-port PoE switch Four (4) Antennas for Cameras Four (4) power adapters for cameras Software CDs for managing NVR &...
- Page 3 WHAT’S IN THE BOX – 8CH NVR KIT Eight (8) 631H2 WiFi PoE IP Cameras 9508S WiFi AP / Router N8/1U 8 Channel IP NVR with 1TB Hard Drive POE31008P 9-port PoE switch Eight (8) Antennas for Cameras Eight (8) power adapters for cameras Software CDs for managing NVR &...
- Page 4 WHAT’S IN THE BOX – 16CH NVR KIT Sixteen (16) 631H2 WiFi PoE IP Cameras TWO (2) 9508S WiFi AP / Routers N25/1U 25 Channel IP NVR with 4TB Hard Drive TWO (2) POE31008P 9-port PoE switches Sixteen (16) Antennas for Cameras Sixteen (16) power adapters for cameras Software CDs for managing NVR &...
- Page 5 9508S WIFI AP / ROUTER The 9508s is a 3-in-1 wireless device. It can be configured as a wireless router, Access-Point or Repeater. The 9508s is configured as an Access-Point by default to ensure it works with your home / business Wireless router without any issues. The WiFi cameras are pre-configured with the SSID &...
-
Page 6: Poe Switch
POE SWITCH A PoE switch is same as a regular Ethernet switch except that it also sends power over the same Ethernet cable, which is used to power the cameras. PoE switch can power a variety of devices such as wireless routers, IP phones, cameras, or any device that is PoE enabled. - Page 7 I N S T A L L I N G Y O U R N V R S Y S T E M – W I F I C O N N E C T I V I T Y ( 9 5 0 8 s ) The cameras can be connected either wired or wireless.
- Page 8 I N S T A L L I N G Y O U R N V R S Y S T E M – W I R E D C O N N E C T I V I T Y ( P O E ) The cameras can be connected either wired or wireless.
- Page 9 R E M O T E V I E W A P P ( G O O L I N K ) S E T U P O N Y O U R S M A R T P H O N E Install the GOOLINK FREE app on your iPhone / Android phone Start the app, click on “+”...
- Page 10 NVR System IP Address & Access Information (4CH & 8CH NVR Systems) Device IP Address Username Password Admin GUI 192.168.1.20 admin (no password set) http://192.168.1.20 Camera 1 - 8 192.168.1.21 – admin admin http://192.168.1.x 192.168.1.28 Where x = 21 for cam1, 22 for cam2 and so on.
- Page 11 NVR System IP Address & Access Information (16CH NVR Systems) Device IP Address Username Password Admin GUI 192.168.1.20 admin (no password set) http://192.168.1.20 Camera 1 - 16 192.168.1.21 – admin admin http://192.168.1.x 192.168.1.36 Where x = 21 for cam1, 22 for cam2 and so on. 9508S -1 192.168.1.39 admin...
- Page 12 C A M E R A G U I D E CAMERAS FEATURES 631H2 536H2 653H5 537H5 802.3af (POE) ✓ ✓ ✓ ✓ 802.11n (WiFi) (2.4GHz) ✓ ✓ ✗ ✗ ONVIF 2.1 Compliant ✓ ✓ ✓ ✓ IP66 Weather Proof ✓...
