- Page 1 INSTALLATION, OPERATION AND MAINTENANCE • Ariterm Vedo...
-
Page 2: Table Of Contents
CONTENTS General ..................3 Installation ................4-5 Laddomat 21 Connection diagram ........6 Temperature control valve ............7 About burning wood ...............8 Operation ................9-11 Service and maintenance ..........12-15 Measurements and connections .......... 16 Technical data................ 17 Guarantee ................17 Declaration of conformation ..........18 Notes ................ -
Page 3: General
The firewood used in Vedo should be at most 0.5 m long. Vedo is a reverse combustion boiler in which wood is combusted in a firebox lined inside a water jacket upon a ceramic grate. The fuel gasifies on the ceramic grate. -
Page 4: Installation
Flue gas fan The Vedo has versatile assembly options that allow it to be fitted with different chimney so- lutions. The standard delivery always includes a flue gas fan. The standard connection to the chimney is straight up (image 1). Make sure to leave enough space for cleaning when installing the pipe. - Page 5 INSTALLATION Plumbing connections Before installation of the boiler, the heating system must be flushed and a water pressure test carried out. The tightness of connections must be ensured after installation. The factory is not responsible for damage caused by leaking connections. Relief valve installation The pressure relief valve must be CE-approved with a maximum opening pressure of 1.5 bar and a minimum size of DN 15.
-
Page 6: Laddomat 21 Connection Diagram
CONNECTION DIAGRAM Room temperature sensor Exp. Radiator temperature sensor Hot water A T-pipe with a min. vessel diameter of 1 ¼” Cold water Radiator improves ventilation Automatic shunt Mixer valve Radiator pump Flue thermostat Relief valve Shunt valve Electric resistor Warm water accumulator Tank... -
Page 7: Temperature Control Valve
TEMPERATURE CONTROL VALVE The Ariterm Vedo boiler must be installed in connection with a warm water accumulator. This improves its functionality and extends its life span substantially. By installing the boiler as presented here, it is possible to make the boiler temperature rise quickly and to maintain a steady, high temperature when the boiler is being used. -
Page 8: About Burning Wood
ABOUT BURNING WOOD Before starting the boiler, check the following: • Heating network and boiler are filled with water, pressure at least 0.5 bar • If there is a smoke pipe damper, make sure that it is open • The heat supply pump is switched on •... -
Page 9: Operation
OPERATION The use of wood in the Ariterm Vedo Ariterm Vedo is designed for the combustion of solid fuels in densely populated neighbour- hoods. It has been tested and approved in accordance with the latest wood-fired boiler requi- rements. The approval requires both ceramic grates and transfer of heat into an accumulator. -
Page 10: Starting The Fire
OPERATION Starting the fire: • Open the smoke pipe damper. Adjust primary air vent to 4 and secondary air vent to 5 (on 1 to 7 scale). Adjust primary air vent to 4. Adjust sekundary air vent to 5. • Start up the exhaust fan. -
Page 11: Operation
Oil use Ariterm Vedo is also compatible with using oil as fuel. The oil burner is installed on the pellet burner hatch using an oil burner flange, which is available as an accessory. -
Page 12: Service And Maintenance
SERVICE AND MAINTENANCE The boiler will function properly and have a long service life when the following matters are ta- ken care of: • The boiler should be located in a dry space. • The boiler should always be operated within the recommended limits. •... - Page 13 SERVICE AND MAINTENANCE Remove all turbulators. Clean the boiler convector by brushing the convector pipes clean. Make sure that the fire door damper Make sure that the fire door damper closes when you close the feeding opens and closes as you use the hatch.
- Page 14 SERVICE AND MAINTENANCE Other maintenance procedures Adjustment of the hatches Check that the hatch sits tightly. A leaky fee- ding hatch will cause wood to combust in the wrong place. Tighten the hatches by adjusting the lock handle and hinge pieces. From time to time, you should check that the gap between the deflectors and the storage The tightness of the hatches is important for...
-
Page 15: Service And Maintenance
SERVICE AND MAINTENANCE Adjusting the hinge: • Unscrew both mounting screws of the hinge piece enough to move the hinge. • Move the hinge piece slightly in the direc- tion of the boiler. • Tighten the mounting screws slightly and test whether the hatch now sits more tightly on the hinge side. -
Page 16: Measurements And Connections
MEASUREMENTS AND CONNECTIONS Part Name Unit Feeding hatch Stoking hatch Primary air vent Secondary air vent Convector door Top door Bottom door Outlet to accumulator DN 32 Expansion vessel outlet DN 25 Cooling spiral Cu 15 Return from accumulator DN 32 Draining outlet DN 15 Water thermometer / pressure gauge... -
Page 17: Technical Data
TECHNICAL DATA TECHNICAL DATA With wood 30 kW Capacity With pellets 30 kW With oil 30 kW Width 570 mm Depth 1016 mm Height 1345 mm Dimensions Weight (empty) 415 kg Water capacity 125 L Flue connection diameter 140 mm (external) Boiler pressure 0,5-1,5 bar Permitted boiler temperature... -
Page 18: Declaration Of Conformation
MANUFACTURES DECLARATION... -
Page 19: Notes
NOTES... - Page 20 NOTES...
- Page 21 NOTES...
- Page 22 NOTES...
- Page 23 NOTES...
- Page 24 ARITERM SWEDEN AB Flottiljvägen 15 39241 Kalmar www.ariterm.se 0771-442850...
