- Page 1 WOOD STOVE Jolie Jolie Forno BASIC - CERAMICA - PIETRA OLLARE Instructions for Use and Maintenance GOOD HEAT...
-
Page 2: Table Of Contents
1.1 WARNINGS - The user must strictly follow the instructions in this instruction Manual. The responsibility of SIDEROS is limited to the supply of the appliance and the manufacturer shall not accept liability in case of failure to observe the instructions given in this Manual. -
Page 3: Accessories
Top made of cast-iron with a series of cooking hobs; Fumes outlet at the top (rear -optional); Multiple oven with precision thermometer (Jolie Forno model only). 1.3 ACCESSORIES Before positioning the stove, check to make sure it is complete with all the accessories. -
Page 4: Overall Dimensions
HEATABLE VOLUME with Rated power Favourable conditions 145 m³ Normal conditions 90 m³ Unfavourable conditions 60 m³ 1.5 OVERALL DIMENSIONS... - Page 5 JOLIE FORNO...
-
Page 6: Technical Description
1.6 TECHNICAL DESCRIPTION Jolie is designed to heat homes or improve insufficient heating, and suits any kind of interior. The supporting frame is made of steel with aluminium sections which make the appliance sturdy; the top, moulding, fireplace, oven (if present) and grate doors, and the front are made of RAF enamelled cast iron. -
Page 7: Installation
GRID-SHAKER CONTROL ASH PIT DOOR ASH PIT fig. 2 (mod. Jolie Forno) 2.0 INSTALLATION 2.1 GENERAL RULES For installation of the stove, take into account the various practical considerations. The walls adjacent to the stove must be made of bricks or concrete, or using non- combustible materials or must be suitably protected with insulating materials. -
Page 8: The Flue
The wood burning stoves manufactured by SIDEROS are based on the principle of convection; therefore it is necessary to ensure free air circulation around the stove without obstructing it with walls or furniture. Correct convection will allow maximum heat exchange through the fireplace walls while at the same time ensuring uniform temperatures, avoiding overheating of the rooms. - Page 9 The installation must be done by qualified personnel in accordance with the standards concerning the sector (UNI EN 1443 and UNI EN 10683). However, if an existing brickwork flue is to be used, have it checked by a technician to make sure it has suitable features and satisfies the following requisites.
- Page 10 The Table below shows the sizing of the flue according to the actual thermal capacity. Tab. 1 Thermal Flue height less than Flue height between 4 Flue height greater capacity 4 metres and 6 metres than 6 metres Ø internal cm Ø...
-
Page 11: Connection To The Flue
2.3 CONNECTIONS TO THE FLUE The stove is set up for a top flue gases outlet connection. The collar is present in the ash pan inside the fireplace and must be mounted and fixed using the screws provided on the head. -
Page 12: Specifications For The Chimney Pots
For stoves which use Ø15 cm tubes, install the cup-shaped tube connections and proceed in reverse of the description given above for the Ø12 cm tubes. For the horizontal sections, the welding must face upwards, there must be at least 50 cm between the duct and the ceiling and these must be fixed to the ceiling. -
Page 13: The Depression
The chimney pot must satisfy the following requisites; - the internal cross-section must be equivalent to that of the flue; - the free outlet cross-section must be at least double the internal cross-section of the flue; - it must be constructed in such a way as to prevent rain, snow and foreign bodies from penetrating the flue and to ensure flue gas exhaust in all wind conditions;... -
Page 14: Operation
3.2 FUELS The only fuel that must be used with a SIDEROS stove is wood, which must be seasoned properly. The logs must first be cut to the right length and then split into halves. -
Page 15: Warnings
Also see Table 5 which shows the features of the most common types of wood. UNSEASONED WOOD DOES NOT HEAT, DIRTIES THE FLUE AND POLLUTES THE ENVIRONMENT. WARNINGS For operation at the night, place big hard logs of wood in the stove. The combustion will thus be slow and the embers will last until the next morning. -
Page 16: Switching On
The air flow is adjusted by means of the “knob” provided in the upper part of the fireplace door. turn the knob clockwise to open the valve and anticlockwise to close it. For proper combustion, to avoid overheating of the stove and higher fuel consumption, it is advisable to make the adjustments as specified in Table 4. -
Page 17: Working In Transition Period
ATTENTION When switching the stove on the first time, follow the indications given below: - open the windows or ventilate the room properly; - check to make sure there are no foreign bodies inside the grate and/or the ash pan; - shut the secondary air and open the primary air to the maximum;... -
Page 18: Working In Winter
Use smaller quantities of wood, and clean the grid frequently using the poker and “revive” the embers by shaking the grid using the command provided, to ensure better working of the stove. 3.6 WORKING IN WINTER Before lighting the stove, always clean the grid to remove ash. If there are embers in the fireplace, spread these out uniformly on the grid so that they come into contact with the primary air evenly: this will ensure better performance. -
Page 19: Seasoning Of The Wood
The Table below shows some of the features of the most common types of wood. Tab. 5 TYPE OF QUANTITY OF EASE OF FLUE GAS EASE OF WOOD HEAT COMBUSTION DENSITY CUTTING HARD WOODS Maple high good good Birch high good good Cherry... -
Page 20: Cleaning And Maintenance
WARNINGS - A clean flue in good condition will ensure safety for the home and satisfactory working of your SIDEROS stove. - The flue must, therefore be checked and cleaned by qualified personnel, at least once a year, before starting to use the stove. -
Page 21: Cleaning And Maintenance Of The Stove
For cleaning the oven (mod. Jolie Forno) use only water or products that are not acidic/alkaline. Do not use metal scourers or sponges with metal parts for cleaning as these will damage the enamel coating, thereby affecting the working. -
Page 22: Ce Marking Information
7.0 CE MARKING INFORMATION EN 13240:2001 + A2:2004 JOLIE - JOLIE FORNO SOLID FUEL APPLIANCE minimum 20 cm (rear) Minimum distance from minimum 30 cm inflammable materials (side) CO emission in combustion products 0.1696 % Exhaust gas temperature 341.15 °C Rated heat output 6.84 kW heat output... - Page 23 PERSONS, ANIMALS OR OBJECTS CAUSED BY FAILURE TO FOLLOW THE GENERAL SAFETY REGULATIONS AND THE INSTRUCTIONS FOR USE, CLEANING AND MAINTENANCE GIVEN IN THIS MANUAL. SIDEROS S.p.A. Via dell'Industria, 87 41038 San Felice sul Panaro - Modena - ITALY Tel. +39.0535.86611 Fax +39.0535.86645 e-mail info@sideros.com...
