PLATINUM FIRES
A A D D E E N N
A A L L I I T T A A
A A L L V V A A
F F L L U U E E L L E E S S S S G G A A S S F F I I R R E E
I I N N S S T T A A L L L L A A T T I I O O N N A A N N D D U U S S E E R R I I N N S S T T R R U U C C T T I I O O N N S S
A A l l l l i i n n s s t t r r u u c c t t i i o o n n s s m m u u s s t t b b e e h h a a n n d d e e d d t t o o u u s s e e r r f f o o r r s s a a f f e e k k e e e e p p i i n n g g
Revision A - 10/05
Country(s) of destination - GB/IE
Platinum Fires, Christchurch, Dorset BH23 2BT
Tel: 01202 499330
Fax: 01202 499326
Advertisement
Table of Contents
Summary of Contents for Platinum Fires ALITA
- Page 1 A A l l l l i i n n s s t t r r u u c c t t i i o o n n s s m m u u s s t t b b e e h h a a n n d d e e d d t t o o u u s s e e r r f f o o r r s s a a f f e e k k e e e e p p i i n n g g Revision A - 10/05 Country(s) of destination - GB/IE Platinum Fires, Christchurch, Dorset BH23 2BT Tel: 01202 499330 Fax: 01202 499326...
-
Page 2: Installation Instructions
INSTALLATION INSTRUCTIONS Preliminary Notes Before Installation This appliance is a high efficiency, flueless, flame effect gas fire. It provides radiant and convected warmth both efficiently and safely utilising the latest type catalytic convertor burner technology. The appliance incorporates a combustion monitoring system (Oxygen Depletion System). -
Page 3: Table Of Contents
Section Contents Page No. Section Contents Page No. Important Notes Testing and Commisioning Appliance Data 8.1 Operating the Appliance Installation Requirements 8.2 Spark Failure 3.1 Room Sizing 8.3 Setting pressure Site Requirements 8.4 Fitting the Frame Assembly 4.1 Ventilation Briefing the customer Unpacking the Appliance 10.0 Servicing... -
Page 4: Appliance Data
Advice should be sought from your local building control officer. ROOM SIZING Aden and Alita : The room size should be a minimum of 30m 3 (e.g. 11’6” x 11’6” x 8’) to allow adequate circulation of air and ensure the correct operation of the fire. - Page 5 SITE REQUIREMENTS (continued) installed in areas where it is likely to be exposed to persistent strong draughts, that may be generated by outside doors or windows, air vents etc. It is recommended that the appliance should not be installed within 500mm of any air vent. Clearances to non-combustibles Non combustible surfaces are defined as brick, metal, marble, concrete etc.
-
Page 6: Ventilation
Remove the front frame retaining screws (positions shown) from the side of the firebox and carefully remove the front frame from the appliance. Alita and Alva models : The frame is supplied loose. GAS SUPPLY ROUTES There are four possible entry points for the gas supply pipework to enter the appliance firebox. -
Page 7: Preparing The Appliance
(if applicable). FIXING POINTS ADEN, ALITA MODELS ALVA MODELS If the appliance is to be mounted on the inner leaf of a conventional cavity wall, or a solid wall, drill four holes using a 7mm masonry bit. -
Page 8: Checking The Burner
Aden models : The control knob may be accessed by opening the panel beneath the glass, on the front of the appliance. Alita models : The control knob may be accessed from below the bottom of the front panel. Alva models : The control knob is a spherical design and is marked as shown in the diagram to the right. -
Page 9: Spark Failure
Re-fitting is the reverse of removal as detailed in section 5.2. Alita models : The front frame assembly simply hooks on to the rear frame at two points. After hooking on the frame, secure it with two fixing screws as shown. -
Page 10: Servicing
10.0 SERVICING Isolate the fire from the gas supply. Ensure that the fire is fully cold before attempting service. A sug- gested procedure for servicing is detailed below. 1. Lay out the dustsheet and tools. 2. Remove the facia section. Removal is the reverse of fitting as detailed in section 8.4/5.2. 3. -
Page 11: Catalysts
10.3 CATALYSTS It is recommended that the catalysts are inspected for signs of damage and dirt during routine servic- ing procedures. The expected life of the catalysts is in excess of 11,000 hours (10 years of normal use). After this time the catalyst should be replaced. If there are any deposits of dirt or soot on the catalysts they should be cleaned with a soft brush and a vacuum cleaner. -
Page 12: Troubleshooting Guide
11.0 TROUBLESHOOTING GUIDE Fire sparks but pilot does not light No gas to fire, check isolators are open. Pipe work blockage, clean out. Air not fully purged, re purge supply or wait longer. Spark earthing to metal work, reset gap correctly. Blocked pilot, clean out internally. -
Page 13: User Instructions
USER INSTRUCTIONS Section Content Page No Important Notes Clearances to Combustibles Ventilation & Room Size Operating Instructions Combustion Monitoring System Cleaning Servicing List of Replacement Parts IMPORTANT NOTES The installation and Servicing of this fire MUST only be carried out by a competent person (such as a CORGI registered fitter) in accordance with the Gas Safety (Installation and Use) Regulations 1998, the relevant British Standards, Codes of Practice, the Building Regulations and the manufacturer's instructions. -
Page 14: Clearances To Combustibles
CLEARANCES TO COMBUSTIBLES Clearances to combustible materials Combustible materials are defined as wood, fabrics, or other materials likely to combust if exposed to flame. Generally, any material, which is likely to discolour, melt or misshape when exposed to moder- ate heat, should be considered as a combustible material or surface. Clearance to the sides of the appliance are 100mm(4in) but curtains, drapes and other fabrics are not permitted within a distance of 500mm(20in) of the appliance sides. -
Page 15: Operating Instructions
For Republic of Ireland, see relevant rules in force. Aden and Alita : The room size should be a minimum of 30m 3 (e.g. 11’6” x 11’6” x 8’) to allow adequate circulation of air and ensure the correct operation of the fire. -
Page 16: List Of Spare Parts
PART NO. ITEM PART NO. ITEM Please Enquire Glass door assembly FT/F730023 Pilot assembly FT003155/0 Gas valve - (Aden & Alita) Please Enquire Burner tray FT003155/1 Gas valve - (Alva) FB/F780052 Catalyst IN/F940136 Seal kit for Catalyst D D O O 0 0 0 0 5 5 5 5 5 5 8 8 / / 0 0 As our policy is one of continuous improvement and development , we hope therefore you will understand we must retain the right to amend details and/or specifications without prior notice.
