Summary of Contents for Corby SYSTEM 2
-
Page 1: Access Control
QUICKGUIDE TO SYSTEM 2 ACCESS CONTROL INSTALLATION access control systems... - Page 2 Two Door Relays: Form C and Form A contact rated 5A @ 30 VDC Two Auxiliary Relays: Form C contact rated 5A @ 30 VDC Two Voltage Outputs: Switches low (-) 50 ma Two Shunt Contacts and Two Zone Inputs 26/30-bit Wiegand card formats For further assistance, call (800) OK CORBY...
- Page 3 IN Keypad and/or IN Card Reader The one door System 2 (2003) can be upgraded to a two door system Corby Card (2016) by purchasing the Model #2020 upgrade kit. This upgrade kit adds a second door, anti-passback, temporary users, one zone input, auxiliary relay #2, one voltage output, large RAM, RS485 and eight additional time schedules.
- Page 4 2 conductor, 22 gauge, shielded - 1000 feet maximum. (95211) 4255 A second contact can be used for zone monitoring. Transformer: Supplied with the System 2. 16.5VAC 40VA 2 conductor, 18 gauge, non-shileded. (93302) SUPPLIED Data Chip readers require a different conductor wire.
- Page 5 2 conductor, 22 gauge, shielded - 1000 feet maximum. (95211) 4255 A second contact can be used for zone monitoring. Transformer: Supplied with the System 2. 16.5VAC 40VA 2 conductor, 18 gauge, non-shileded. (93302) SUPPLIED Data Chip readers require a different conductor wire.
-
Page 6: Communication With A Pc
5 conductor, 22 gauge, shielded - 100 feet maximum. (67005) 4100 Video Display Terminal 2 conductor, 22 gauge, shielded, twisted pair. RS485: Communications loop for multiple System 2’s. Eight total (16 doors). 4126 4000 feet maximum from first unit to last unit. (93302) Printer: Parallel (connects to PC). - Page 7 40946-12 Volt with 6A lead acid battery and transformer Data Chips MISCELLANEOUS 4320Chip assembled on a key-ring with Corby logo 2018Data Chip Programming Wand for faster and easier 4321Chip Only - For use with badges, photo ID cards etc. programming of Data Chips 4323Roll of double stick tape (dots) for adhering Data Chip - 4056Line Extender Module.
-
Page 8: Architectural Specifications
48 character LCD display. System will provide an RS-232 interface for optional programming through a video display terminal, PC or the connection of a printer. System will provide an RS-485, two wire interface for connection to other System 2's in a network. A maximum of eight systems will be networkable to provide control for 16 doors.
