HTP‐T32G28D

H.264 IP DOME CAMERA

User Manual

Ver. 1.0

Table of Contents

Need help?

Do you have a question about the HTP-T32G28D and is the answer not in the manual?

Questions and answers

Summary of Contents for Hunt CCTV HTP-T32G28D

Page 1 HTP‐T32G28D H.264 IP DOME CAMERA User Manual Ver. 1.0...
Page 2 We appreciate your purchasing HTP-T32G28D. Before installing the product, please read the following with care. Make sure to turn off the power before installing HTP-T32G28D. Do not install under the direct sunlight or in dusty areas. Make sure you use the product within the temperature and humidity specified in the specification.
Page 3: Table Of Contents
Remote Video Monitoring ...................... 9 2. Initialization of IP Address ....................... 11 4. Remote Configuration........................12 1. Using Remote Configuration ....................12 2. HTP-T32G28D Setup ......................13 2.1 System ........................... 13 2.2 Video..........................15 2.3 Audio ..........................18 2.4 Network .......................... 19 2.5 Serial Port Configuration ....................
Page 4: Introduction
1. About User Manual The User Manual is provided to advise how to use this premium network camera, HTP-T32G28D. This manual includes how to trouble shoot in case of problems as well as installation, operation and setting up the HTP- T32G28D.
Page 5: Product And Accessories
HTP-T32G28D User Manual Sensor & Alarm Support direct connections of external sensor and alarm devices. Event alarm User Interface Diagnose and upgrade through dedicated program called True Manager System configuration using Internet Explorer High Reliability Embedded system System recovery by dual Watch-dog functions 3.
Page 6: Rotation Functions
PC client or a decoder system or 1 to many connections where one HTP-T32G28D can be connected several PCs and decoder systems. Topology Generally HTP-T32G28D and a PC or a decoder are connected in a 1 to 1 mode or a 1 to many configuration. 1:1 connection Remote Center...
Page 7 HTP-T32G28D User Manual One HTP-T32G28D is installed at a site where video images are transmitted. A PC or a decoder is installed at a central location to receive and view the video images on an analog monitor. Audio and serial data are transferredin either direction.
Page 8: Installation
PT commands to the external equipment via the serial port. When a decoder system instead of PC client is connected to HTP-T32G28D, the serial port and that of the decoder system works in pass-through mode. That is, data from at one port is delivered to the other port, vice versa .
Page 9: Connecting Power
HTP-T32G28D User Manual 5. Connecting Power After confirming the power source, connect power adaptor and then 12V DC connector to the system. 6. Checking Operating Once the power is supplied to the camera, it will start booting. The system will boot up to an operating mode after approximately 40-60 seconds. The green LED on the Ethernet port will flash indicating the system is ready.
Page 10: System Operation
Default ID : admin Password : 1234 Video Monitoring via Decoder System Once the HTP-T32G28D’s IP address is set in the remote IP address section of the decoder, the decoder system will connect to the HTP-T32G28D and start receiving the video images.
Page 11 HTP-T32G28D User Manual Video Selection HTP-T32G28D is capable of dual streaming. Video Selection allows you to choose Primary Video image or Secondary Video image. Video Image is displayed according to the resolution set on video configuration. When dual streaming is not activated and secondary mode is selected, video cannot be...
Page 12: Initialization Of Ip Address
HTP-T32G28D User Manual 2. Initialization of IP Address If HTP-T32G28D’s IP address is lost, the HTP-T32G28D can be reset. Press a reset button on the back of the HTP-T32G28D, this will reset the camera to factory defaults as follows: While the system is in operation, press the reset button for more than 5 seconds.
Page 13: Remote Configuration
1. Using Remote Configuration Remote setting is available by using web browser. Enter the IP address of HTP-T32G28D and then live view screen appears as below. Press Setup button located in the upper right area of the monitoring screen to go to the server setup.
Page 14: Htp-T32G28D Setup
HTP-T32G28D User Manual 2. HTP-T32G28D Setup 2.1 System -13-...
Page 15 Do not press the Reboot button unless the server needs a reboot . Factory Reset Current IP Address of HTP-T32G28D is changed to default IP Address, 192.168.10.100. System log and user registrations are also cleared. The other setting value will be remained.
Page 16: Video
HTP-T32G28D User Manual 2.2 Video -15-...
Page 17 HTP-T32G28D User Manual ENCODE Input Format Choose video type to be used between composite NTSC or composite Resolution Selectable video compression resolution as below: NTSC: 720X480, 720x240, 352X480, 352X240, 176X120 PAL: 720X576, 720X288, 352X576, 352X288, 176X144 Frame Rate Select video frame rate (the maximum number of frames of video images to compress.) The frame rate actually transmitted can be affected by the network bandwidth limitations.
Page 18 HTP-T32G28D User Manual DUAL ENCODE Use Dual Encode The Selection between H.264 and MJPEG is supported. Secondary Video can be used on Live View window Dual Encode Algorithm H.264 and MJPEG can be selected for secondary streaming. Maximum resolution is 720 x 480 and there are 8 steps of resolution.
Page 19: Audio
HTP-T32G28D User Manual Sensitivity A condition to trigger an event of motion detection. The value determines the sensitivity of the motion detection within a block: the smaller, the more sensitive. It is selectable from from 0 to 10. Information Display System ID and/or server time can be display over the video window in Web View.
Page 20: Network
HTP-T32G28D User Manual 2.4 Network -19-...
Page 21 RTSP port used for RTSP-based connection SNMP HTP-T32G28D can be used as an SNMP agent. It is compatible to both SNMPv1 and SNMPv2c. Vender specific MIBs for IP camera/server are defined. SNMP listen port can be set and disabled when it is 0.
Page 22 HTP-T32G28D User Manual Select the DDNS(Dynamic DNS) server to use. One of the two servers can be selected. - TrueDNS : use TrueDNS service. Systems can be registered on the website for TrueDNS service: http://ns1.truecam.net. System will get a domain name of xxx.truecam.net style. Refer to the user guide document for True DNS service.
Page 23: Serial Port Configuration
HTP-T32G28D User Manual 2.5 Serial Port Configuration Serial Port Configuration There is one serial port, RS-485 in HTP-T32G28D. The serial port can be configured as follows Mode Selection Bitrate 2400, 4800, 9600, 19200, 38400, 57600, 115200 bps Data Bits 5, 6, 7, 8 bits...
Page 24 Select the serial port used for PTZ camera control. Direct Keyboard Control Keyboard controller can be connected to HTP-T32G28D directly to control zoom and focus. Sensor Type There is one sensor input port on HTP-T32G28D. The sensor port can be configured to the following. Function Operation Not used...
Page 25: Event Configuration
HTP-T32G28D User Manual 2.6 Event Configuration -24-...
Page 26 HTP-T32G28D User Manual The HTP-T32G28D has one sensor port and one alarm port. When a decoder system instead of a PC client is connected to a HTP-T32G28D, one system becomes a Local system and the other a Remote system (Generally a system which is being used by the user is called as Local system).
Page 27 HTP-T32G28D User Manual needs to be specified on Server Address field, and Port specifies the port for SMTP operation (Port 25 is the default port in SMTP operation. If a different port is configured in the SMTP server, this port needs to be changed accordingly).
Page 28: Preset
Press Set Button Save This function is only available when a PTZ receiver is used with HTP-T32G28D. Configure up to 15 preset positions. Preset function is not available on some PTZ receivers. Make sure to check if a PTZ receiver supports preset.
Page 29: User
HTP-T32G28D User Manual 2.8 User User can be registered and privilege level of a user can be specified. User configuration is allowed only to admin user. Max 16 users can be registered and each user can have one of four privileges.
Page 30: Camera
HTP-T32G28D User Manual Change Password Pressing Modify Password button after selecting a user shows a page for changing password. In case changing admin password, old password is checked. Modify Privilege Level Pressing Modify Privilege button after selecting a user shows a page for changing the privilege. It is not allowed to change the privilege level of admin user.
Page 31 HTP-T32G28D User Manual Settings for analog part of the camera can be configured. Camera-specific menu is displayed using OSD on video display, and this menu can be operated with 5 buttons on the page. OSD (On Screen Display) How to use Press the Set button to access the SETUP mode.
Page 32 HTP-T32G28D User Manual Press the Set button to display the setup menu and move the arrow indicator to ‘SHUTTER’ using ① the Up or Down button. ② Set ‘SUTTER’ to the desired mode using the Left or Right button. ③...
Page 33 HTP-T32G28D User Manual Press the Set button to display the SETUP menu and move the arrow indicator to ‘BACKLIGHT’ ① using the Up or Down button. ② Set ‘BACKLIGHT’ to the desired mode using the Left or Right button Auto Gain Control (AGC) AGC is to get bright picture.
Page 34: Appendix : Poe Specification
HTP-T32G28D User Manual whitish. This is not out of order SPECIAL ① CAMERA ID : If the camera ID feature is set to ‘OFF’, the name will not displayed in the monitor. However, Camera ID can be set on the System tap of web viewer.
Page 35 HTP-T32G28D User Manual Output Voltage : 12.0V Input voltage range : 36V to 57V 1500V isolation (input to output) PoE must be protected from over-voltages exceeding the 80V maximum rated surge input voltage Recommended Operating Conditions Parameter Units DC Supply Voltage DC Voltage Lockout Ta/°C...
