VIEW-i Lite/Pro/Silver/Gold/Ruby
User Manual v.2.6.24
Please read carefully before using this product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VIEW-i Lite and is the answer not in the manual?

Questions and answers

Summary of Contents for Avic VIEW-i Lite

  • Page 1 VIEW-i Lite/Pro/Silver/Gold/Ruby User Manual v.2.6.24 Please read carefully before using this product.

  • Page 2: Table Of Contents

    Table of Contents Liability Precautions Components Functions Features Installation View-i Product Manual View-i PC Player Manual View-i Product Trouble-Shooting Specifications and Certifications ※ Warranty...

  • Page 3: Liability

    1. Liability 1. This product was designed to assist you in driving safely by recording driving information and data for driver reference. 2. This product does not guaranteed to record information on every accident. - A minor force will not trigger the G-Force sensor to activate Event Recording.

  • Page 4: Precautions

    2. Precautions (Device) Do not open/fix/alter this device Do not operate product while driving Any customer alterations will void the Only operate in safe environments warranty Only install this product within the Do not use any accessories other then recommended installation area those included with the recorder It could result in poor GPS reception The use of any additional accessories will...
  • Page 5 2. Precautions (SD Card) Only use SD memory card from the manufacturer Product may not function correctly if un-tested SD memory cards is used Do not open/fix/modify SD memory card Product could be damaged and warranty does not cover such damage. SD memory card need to be replaced with a new product once it reaches end of product life Product might malfunction if SD card’s writing speed decreases.
  • Page 6 3. Product Package Please confirm below package list in the box Cradle & SD Card Device Double Side Tape x User Manual (Included View-i PC Player) IR Lighting Wire Clip x 6 ea TV-out Cable Cigarjack Module Power Cable (Ruby Model Only) TV-out cable : Display which doesn’t have composite port must be adjusted to the correct display format Product package may change for product enhancement without any notification...

  • Page 7: Functions

    4. Functions Function Description Records everything during device power on status [NOTE] If memory exceeds its capacity, device deletes oldest file to make Constant Recording room for new recordings. Therefore, if user wants to keep the old recordings, user must backup the recordings before they are automatically deleted When device detects exceeded force in the device, device automatically saves 15 seconds before and after of the triggered event.
  • Page 8 4. Functions Function Description View-i PC View-i PC Player can be used to check recorded videos on SD card Player View driver’s route in Google Map embedded in View-i PC Player Google Map [NOTE] GPS needs to be connected to the satellites in order to sync Sync Sync data with Google Maps...

  • Page 9: Features

    5. Features Name Description ① Power Port DC 12V/DC 24V ② Internal GPS ③ Front Camera 130M Pixel CMOS Image Sensor ④ Power Switch Device Power on/off switch Preview/Replay recorded files to ⑤ TV-Out Port nearest display (NTSC/PAL) ⑥ Mic Switch Mic on/off switch ⑦...

  • Page 10: Installation

    6. Installation 6.1 Recommendation For Sedans and SUVs, install the device near rear view mirror to the driver side where GPS and Camera does not have physical interrupts 6.2 Placing the Cradle Remove tape cover and place according to the diagram in 6.1 with open side up [NOTE] If device was installed any place other then what is recommended in diagram 6.1, it will...
  • Page 11 6. Installation 6.3 Installing the product into the Cradle 1. Insert SD memory card to the product 2. Hold product so camera part is at the bottom and then slide it into the cradle from top to bottom until it makes a clicking sound 3.

  • Page 12: View-I Product Manual

    7. View-i Product Manual Name Recording Mode Replay Mode(TV-OUT) Manually start event recording Manual Recording ① If button is pressed, device will make Same as Recording Mode Button “tic-tic” sound and blue and orange LED will blink quickly Short No function Previous File Press Memory...
  • Page 13 7. View-i Product Manual 7.1 Buzzer/LED Scenario Name Buzzer Red LED : On 1 beep for 1CH products Blue LED : Blink Booting Status 2 beeps for 2CH products Orange LED : Blink If SD card is not inserted, Red LED : On SD Card Device will make a beep Blue LED : Blink...

  • Page 14: View-I Pc Player Manual

    This part of the manual explains the use of View-i PC Player, video and utility player. With View-i PC Player, user may view the contents of View-i Lite/Pro/Silver/Gold products. * Windows Media Player and other player may show videos but G-Sensor, GPS, MAP, Report functions can only be used in View-i PC Player.
  • Page 15 8. View-i PC Player Manual 8.3 View-i PC Player - 1 Channel Double click on ”View-i” icon to view the below screen. (View-i Lite/Pro) Name Description ① Video Screen Video play screen of designated video file ② G-Sensor Graph G-sensor data of video screen for user analysis...
  • Page 16 8. View-i PC Player Manual 8.4 View-i PC Player - 2 Channel Double click on ”View-i2” icon to view the below screen. (View-i Silver/Gold/Ruby) Name Description ① Front Video Screen Front video play screen of designated video file ② ② Rear Video Screen Rear Video Screen Rear video play screen of selected front video file...
  • Page 17 8. View-i PC Player Manual 8.5 Buttons Button Description Button Description Previous File Open 1 file Rewind Print Screen Play ECO-Drive Report Pause Event Report Stop Setting Fast-forward Play Speed Control Next File 8.6 Control Bar Volume Control : Video volume control with mute function...
  • Page 18 8. View-i PC Player Manual 8.7 Open File / Play • Recorded contents can be found inside device’s SD card. Constant files can be found under “NORMAL” folder / folder name under date/hour. • Event videos can be found under “EVENT” folder. •...
  • Page 19 8. View-i PC Player Manual 8.8 File List Screen Name Description Folder Open a folder with recorded ① Open videos Chain Play button for continual playing ② Play of checked listed files File name consist of date/hour of recordings of recordings. EVT_090919_201518.mp4 File ③...
  • Page 20 8. View-i PC Player Manual 8.9 Search - DB 1. Import play list to the Search screen (Reference : 8.6 Open File / Play) 2. Click on “Create DB” to make database *Database must be created before searching 3. Select search option and click “Search” bu tton 4.
  • Page 21 8. View-i PC Player Manual 8.10 Play Screen View-i Silver/Gold/Ruby View-i Lite/Pro Name Name Description Description ① Video Screen Video play screen of designated video file ② G-Sensor Screen G-sensor data of video screen for user analysis Speed-o-Meter / Display driving speed (View-i Pro) ③...
  • Page 22 8. View-i PC Player Manual 8.11 Google Map Interface 1. View-i PC Player supports Google Map interface Internet must be connected for Google map interface 2. Navigate through Goggle Map with mouse cursor Number Number Description Description Adjust Map size ①...
  • Page 23 8. View-i PC Player Manual 8.12 Road Track™ 1. Road Track™ shows driving path of selected files. In order to use this function, user must first call in the video files and create database 2. After creating the database, click on button button 3.
  • Page 24 8. View-i PC Player Manual 8.13 Speed/G-Sensor 1. View-i PC Player supports detailed view of speed and G-Sensor data 2. Click on “Big Chart” button in the G-sensor screen to display below pop-up screens Speed (Km/H) G sensor Play Time Play Time G-Sensor Speed...
  • Page 25 8. View-i PC Player Manual 8.14 Screen Capture Print/Save 1. View-i PC Player supports screen capture function which can print / save specific screen of user choice 2. Click on button to view the screen below Description Description ① G Sensor Data GPS Data ②...
  • Page 26 8. View-i PC Player Manual 8.15 ECO-Driver Report 1. Create database from user selected video files 2. Click “Eco-Drive Report” button 3. Input basic user information and click “Make Report” button to create a report 4. Use “Excel” and “Preview” button to save the report to a file or print...
  • Page 27 8. View-i PC Player Manual 8.16 Event Report 1. Click on “Event Report” button to retrieve the image capture screen 2. Click on the “Add” button to save 4 different video screen and click on “Next” button 3. Use “Clear” button to remove selected screens 4 Input basic information and click on “Preview”...
  • Page 28 8. View-i PC Player Manual 8.17 GPS/G-Sensor Data Export 1. Create database from user selected video files 2. Click “Save Data” button 3. Save CSV file to user preference location in PC 4. User may utilize *.csv file in their preference...
  • Page 29 Video Quality Video quality setting G-Sensor G-Sensor sensitivity select iti it ② Setting (Low = sensitive / High = Dull) VIEW-i Lite/Silver user must ③ Device Time manually set the time ④ Time Zone Select user time zone ⑤ Sound Setting Buzzer on/off 2.
  • Page 30 8. View-i PC Player Manual 8.18.2 Setting - Expert Name Description Best : 1.3M@VGA 17fps Good : 1.3M@VGA 20fps ① Video Quality Normal : 0.3M@VGA 30fps Compact : 0.3M@QVGA 17fps Compact 0.3M@QVGA 17fps ② Brightness (Dark)-4 ~ +4(Bright) G-Sensor 0.1~2.0 ③...

  • Page 31: View-I Product Trouble-Shooting G

    9. View-i Product Trouble-Shooting Symptom Solution Please check power cable connection to the device Please check power cable connection to vehicle power source Please check power switch on the device No Power If all power connections are correct then remove SD Card and re-insert and try again If you have attempted the above remedies, and the device is still not working properly, please contact your dealer Please check to see if SD card is correctly inserted...

  • Page 32: Specifications And Certifications

    Voltage 12V~24V Size 52(W) x 94(H) x 18(D)mm Weight View-i Clik/Lite : 70g / View- Pro/Silver : 85g / View-Gold/Ruby : 90g Manufacturer AVIC Imaging Inc. / Manufactured in South Korea Certification KCC / FCC / CE / / RoHS...

  • Page 33: Warranty

    Warranty Thank you for purchasing AVIC Imaging Inc.’s product. Product View-i Lite / View-i Pro / View-i Silver / View-i Gold / View-I Ruby Model VSDR-1000 / VSDR-1100 / VSDR-2000 / VSDR-2100 / VSDR-2200 Name Serial Number Phone Phone Email...
  • Page 34 Screens and pictures may be different in product use View-i® Lite/Pro/Silver/Gold/Ruby...
