- Page 1 BATTERY PACK For PVI-AEC-EVO QUICK INSTALLATION GUIDE Note: This document contains proprietary information of Power-One, Inc. The contents of this document or any part thereof should not be reproduced or disclosed to any third party whitout Power-One’s express written consent.
-
Page 2: Package Contents
BATTERY PACK QUICK INSTALLATION GUIDE Wiring Battery Pack to PVI-AEC-EVO Package contents Package contents BATTERY PACK For PVI-AEC-EVO QUICK INSTALLATION GUIDE No te : Th is do cu me nt co nt ai ns pr op ri et ar y in fo rm at io n of Powe r- On e, In c. - Page 3 PVI-AEC-EVO (powered by 24Vdc source) for a period of at least 24h. The BATTERY PACK is able to supply the PVI-AEC-EVO in case of the 24Vdc failure but is not able to turn on the PVI-AEC-EVO from the shut down condition.
-
Page 4: Technical Data
BATTERY PACK QUICK INSTALLATION GUIDE TECHNICAL DATA Battery Type Panasonic Model HHR60AAAH AAA Ni-Mh Rechargeable battery www.panasonic.com Battery Voltage 4 x 1.2 V Battery Rated Capacity 500 mAh Battery Charge Current 50 mA Max. Ambient Working Temperature +55 °C Min. Ambient Working Temperature -20 °C Operating Humidity 25 to 95 % RH @ +40 °C... -
Page 5: Contenuto Della Confezione
Monitoring System Connessione del Battery Pack al PVI-AEC-EVO Contenuto della confezione Contenuto della confezione BATTERY PACK For PVI-AEC-EVO QUICK INSTALLATION GUIDE No te : Th is do cu me nt co nt ai ns pr op ri et ar y in fo rm at io n of Powe r- On e, In c. - Page 6 GUIDA DI INSTALLAZIONE RAPIDA Descrizione del prodotto e dati tecnici Il Battery Pack è un modulo di espansione specificatamente sviluppato per il sistema PVI-AEC-EVO in grado di fornire un alimentazione di back-up al sistema in caso di assenza della tensione di alimentazione.
-
Page 7: Dati Tecnici
Monitoring System DATI TECNICI Tipologia di batterie Panasonic Model HHR60AAAH AAA Ni-Mh Rechargeable battery www.panasonic.com Voltaggio delle batterie 4 x 1.2 V Capacità delle batterie 500 mAh Corrente di carica delle batterie 50 mA Max. Temperatura operativa +55 °C Min. Temperatura operativa -20 °C Umidità... - Page 8 BATTERY PACK SCHNELLINSTALLATIONSANLEITUNG Anschluss des Battery Pack an den PVI-AEC-EVO Packungsinhalt Packungsinhalt BATTERY PACK For PVI-AEC-EVO QUICK INSTALLATION GUIDE No te : Th is do cu me nt co nt ai ns pr op ri et ar y in fo rm at io n of Powe r- On e, In c.
- Page 9 Mal verwendet, ist sie möglicherweise nicht vollständig geladen. Zur vollständigen Ladung muß die Batterie mindestens 24 Stunden mit demPVI-AEC-EVO verbunden sein (Versorgung über 24V DC). Das Battery Pack kann den PVI-AEC-EVO speisen, ist aber nicht in der Lage den PVI-AEC-EVO nach einem Systemstillstand neu zu starten.
-
Page 10: Technische Daten
BATTERY PACK SCHNELLINSTALLATIONSANLEITUNG TECHNISCHE DATEN Batterie Typ Panasonic Model HHR60AAAH AAA Ni-Mh wiederaufladbare Akkus www.panasonic.com Batteriespannung 4 x 1.2 V Batteriekapazität 500 mAh Batterie Ladestrom 50 mA Max. Arbeitstemperatur +55 °C Min. Arbeitstemperatur -20 °C Relative Luftfeuchtigkeit 25 bis 95 % RH @ +40 °C Schutzklasse IP20 MTBF... -
Page 11: Contenu De L'emballage
Monitoring System Pack Batterie pour PVI-AEC-EVO Contenu de l'emballage Contenu de l'emballage BATTERY PACK For PVI-AEC-EVO QUICK INSTALLATION GUIDE No te : Th is do cu me nt co nt ai ns pr op ri et ar y in fo rm at io n of Powe r- On e, In c. - Page 12 Le PVI-AEC-EVO est équipé d'une batterie et de son chargeur. Lorsque la batterie est utilisée pour la première fois, elle peut être partiellement vide. Elle sera rechargée complètement une fois que le PVI-AEC-EVO sera alimenté en 24V durant 24 heures au minimum.
-
Page 13: Caractéristiques Techniques
Monitoring System CARACTÉRISTIQUES TECHNIQUES Type de batterie Panasonic Modèle HHR60AAAH AAA Ni-MH rechargeable www.panasonic.com Tension de la batterie 4 x 1.2 V Capacité nominale de la batterie 500 mAh Courant de charge de la batterie 50 mA Température Max. Ambiante de fonctionnement +55 °C Température Min. - Page 14 BATTERY PACK QUICK INSTALLATION GUIDE...
