ELECTRIC

LOG SPLITTER

Operation Manual

LS5TELL

This product contains lead, a chemical known to the State of California to cause birth

defects or other reproductive harm. Wash your hands after handling this product.

This product contains chemicals known to the State of California to cause cancer and

birth defects or other reproductive harm.

WARNING

Table of Contents

Need help?

Do you have a question about the LS5TELL and is the answer not in the manual?

Questions and answers

Summary of Contents for BE LS5TELL

Page 1: Log Splitter
ELECTRIC LOG SPLITTER Operation Manual LS5TELL WARNING This product contains lead, a chemical known to the State of California to cause birth defects or other reproductive harm. Wash your hands after handling this product. WARNING This product contains chemicals known to the State of California to cause cancer and...
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction Using the Operator’s Manual Product Identification Record Identification Numbers Receipt and Inspection Safety Safety Instructions Hazard Symbols and Meanings Safety Warnings 10 General Safety 10 Work Area 11 Operator Zone 12 Maintenance Safety 13 Fire Prevention Electrical Safety 14 Extension Cords 14 Electrical Connection...
Page 3 TABLE OF CONTENTS Operation 20 Operating Instructions 22 Splitting Logs 22 Transportation 22 Storage Maintenance 24 General Maintenance 24 Sharpening the Wedge 24 Lubrication 24 Replacing Hydraulic Oil Troubleshooting 26 Troubleshooting Chart Specifications 27 Technical Specs Diagram 28 Diagram Parts List 29 Parts List...
Page 4: Introduction
Using the Operator’s manual Thank you for purchasing a BE Log Splitter. Your machine is designed for long life, dependability, and the top performance you demand! Please take time now to read through this manual so you better understand the machine’s operation, maintenance and safety precautions.
Page 5: Product Identification
PRODUCT IDENTIFICATION Record Identification Numbers LOG SPLITTER If you need to contact an Authorized Dealer or Customer Service line (1-866-850-6662) for information on servicing, always provide the product model and identification numbers. You will need to locate the model and serial number for the machine and record the information in the places provided below.
Page 6: Receipt And Inspection
If damage or missing parts are apparent, make the appropriate notation on the delivery receipt, then sign the receipt. Immediately contact the carrier for an inspection. All material must be held in the receiving location for the carrier’s inspection. Delivery receipts that have been signed without a notation of damage or missing parts are considered to be delivered “clear.”...
Page 7: Safety 7 7
SAFETY Save these Instructions SAFETY RULES This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. The safety alert symbol ( ) is used with a signal word (DANGER, CAUTION, WARNING), a pictorial and/or a safety message to alert you to hazards.
Page 8 SAFETY Some of the following symbols may be used on this tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and safer. SYMBOL NAME EXPLANATION Volts Voltage Amperes...
Page 9: Safety Warnings
(without loose cuffs or draw strings). Always wear a protective hearing device when operating this log splitter. • NEVER wear loose clothing or jewelry that can be caught by moving parts of the log splitter. Keep clothing and hair away from all moving parts when operating this log splitter.
Page 10: General Safety
• KEEP all people and pets a minimum of 25 feet away from your work area when operating this log splitter. Only the operator is to be near the log splitter during use. • ALWAYS wear safety glasses.
Page 11: Operator Zone
SAFETY OPERATOR ZONE WARNING • ONLY operate the log splitter from the operator zone as shown in the diagram. The operator has the safest and most efficient access to the control valve and the beam in this location. Failure to operate the log splitter in this position can result in serious injury or death.
Page 12: Maintenance Safety
Serious infection or reaction can develop if proper medical treatment is not administered immediately. • ALWAYS be sure to relieve all pressure by shutting off the motor and moving the control handle back to stop position. • NEVER remove the vent plug from the hydraulic tank or reservoir while the log splitter is running.
Page 13: Fire Prevention
SAFETY FIRE PREVENTION WARNING • NEVER operate your log splitter near a flame or spark. Hydraulic oil is flammable and can explode. • NEVER smoke while operating or refueling your log splitter. Gas fumes can easily explode. • ALWAYS take a Class B fire extinguisher with you when operating this log splitter in dry areas as a precautionary measure against possible flying sparks.
Page 14: Electrical Safety
ELECTRICAL CONNECTION This tool is powered by a precision built electric motor. It should be con- nected to a power supply that is 115 volts, 60 Hz, AC only (normal household current). Do not operate this tool on direct current (DC).
Page 15: Speed And Wiring
A line intended only for lights cannot properly carry a power tool motor. Wire that is heavy enough for a short distance will be too light for a greater distance. A line that can support one power tool may not be able to support two or three tools.
Page 16: Overview
OVERVIEW Overview 1. End wedge 2. Sliding ram 3. Support legs, log holder 4. Machine body / Oil reservoir 5. Control handle 6. 115v motor 7. Motor control box 8. On/Off switch 9. Electrical cable with plug 10. Oil drain bolt with dipstick 11.
Page 17: Assembly
ASSEMBLY Assembly This product has been shipped pre-assembled. • Carefully remove the log splitter and all accessories from the box. Make sure that all items listed in the packing list are included. • Inspect the tool carefully to make sure no breakage or damage occurred during shipping.
Page 18: Pre-Operation
• Clear the work area. • Check that all nuts, bolts and hydraulic fittings are tight to be sure the equipment is in a safe working condition. • Make sure your outlet type, voltage, and frequency match the data stated on the serial number label (or “Technical Specifications”...
Page 19: Log Prepratation
PRE-OPERATION LOG PREPARATION Logs should be cut with square ends. Never split logs larger than 10 in. diameter or 20-1/2 in. long. Uneven logs (e.g. knotted, curved, etc.) should not be used. Oil the wedge and upper side of the machine body. This will allow the log to move smoothly on the surface.
Page 20: Operating Instructions
Only allow responsible adults who have read and understand the manual to operate this machine. d) Be familiar with all controls and proper operation. Know how to stop the machine quickly in the event of an emergency. e) Do not operate the machine while under the influence of alcohol, drugs or medication.
Page 21 OPERATION k) Don’t force the tool. It is already designed to operate at its maximum speed and tonnage. If you experienced problems splitting especially hard wood, do not continue to push on the control handle for more than 3 seconds. Release the control handle at once to avoid damage.
Page 22: Splitting Logs
Never split more than one log at a time. • Place log lengthwise and lying flat on the work table. • Both ends of the log should be cut as square as possible to help prevent the log from riding out of the splitter during operation.
Page 23: Storage
OPERATION STORAGE NOTICE a) Store this unit switched off and unplugged. b) Allow machine to cool 5 minutes after every use before storing. c) Protect power supply cable from heat, sunshine, aggressive liquids and sharp edges. d) Store unit in a clean, dry area. Do not store in unprotected areas outdoors.
Page 24: Maintenance
• When servicing, use only identical replacement parts. Use of any other parts may create a hazard or cause product damage. • Only the parts shown on the parts list are intended to be repaired or replaced by the customer. All other parts should be replaced at an Authorized Service Center.
Page 25 • Level down the log splitter, start the motor and cycle the ram several times to remove excess air from the reservoir. NOTICE The oil level should be between the two grooves around the bottom of the dipstick. • Use AW32 hydraulic fluid.
Page 26: Troubleshooting
TROUBLESHOOTING Troubleshooting TROUBLESHOOTING CHART PROBLEM POSSIBLE CAUSE SOLUTION Motor fails to start. • Overload Protection • Switch off the motor and Device is disengaged to unplug the power cable. protect the log splitter Let motor cool down for from being damaged. half an hour and restart.
Page 27: Specifications
SPECIFICATIONS Specifications TECHNICAL SPECS Electrical requirements 115V, 60Hz Power output 1300W Rated current Motor speed 3400 RPM Power cable SJTW 14 AWG (2.08mm²) Max splitting force 5 Ton Max splitting length 20.5 in Max splitting diameter 10 in Hydraulic pressure 2700 PSI Cylinder bore 2.2 in...
Page 28: Diagram
DIAGRAM Diagram...
Page 29: Parts List
PARTS LIST Parts List...
Page 30 PARTS LIST Parts List...
