- Page 1 English Français Deutsch Español Italiano 中文 日本語 한국어 NATIVE UNION ﺍﻝﻉﺭﺏﻱﺓ “Play” Instruction Manual Manuel d’utilisation Bediengungsanleitung Manual de instrucciones Manuale di istruzioni 使用手册 取扱説明書 사용 설명서 ﺩﻝﻱﻝ ﺍﻝﺕﻉﻝﻱﻡﺍﺕ...
- Page 2 WELCOME “Play” Multi-Message Video Memo Pad Designed by Fabien Nauroy · Standby time : up to 45 days with messages, up to 6 months without messages · Play time : Up to 4 hours · Multi-message · Video recording up to 180 seconds · Magnetic back · Time and date of messages · 2.4” diagonal screen · No computer needed · User friendly · LED message indicator...
- Page 3 WHAT YOU GET IN THIS PACKAGE English Français Deutsch Español Italiano 中文 日本語 한국어 NATIVE UNION ﺍﻝﻉﺭﺏﻱﺓ “Play” Instruction Manual Manuel d’utilisation Bediengungsanleitung Manual de instrucciones Manuale di istruzioni 使用手册 取扱説明書 사용 설명서 ﺩﻝﻱﻝ ﺍﻝﺕﻉﻝﻱﻡﺍﺕ “Play” Multi-Message Video Memo Pad Strap to keep your “Play” safe at hand Instruction manual Magnetic sticker plate...
-
Page 4: Main Screen Functions
MAIN SCREEN FUNCTIONS Press any button for 1 second to wake up device to Main Screen Sun 21.08.2011 13.28 Enter “RECORD” mode Enter “PLAY” mode Press and hold for 3 seconds Device will go to standby when idle for 15 seconds Device will go to sleep when idle for 2 minutes... -
Page 5: How To Use
HOW TO USE - RECORD mode Enter “RECORD” mode from Main Screen Start recording after countdown Any key press during countdown will cancel the operation Exit “RECORD” mode and back to main screen While recording Delete message without saving to save message Stop recording and save message White LED will start blinking until all new messages are viewed seconds Device will go back to main screen if idle for 6 seconds... - Page 6 HOW TO USE - PLAY mode Enter “PLAY” mode from Main Screen Play current message shown on screen Skip to next message double press Delete current message shown on screen to cancel delete Delete ALL messages on device press and hold 3 seconds to cancel delete While playing Pause the current message again to resume Delete current message to cancel delete White LED will stop blinking when all new messages are viewed Device will go back to main screen if idle for 6 seconds...
-
Page 7: Date/Time Setup
HOW TO USE - DATE/TIME setup While in SLEEP mode Enter “DATE/TIME setup simultaneously hold 9 seconds While in DATE/TIME setup To cycle through each setting parameter parameter Press 2 seconds Exit without saving settings... -
Page 8: User Interface
HOW TO USE - USER INTERFACE Battery level indicator 180 seconds Timeline bar Unread message (green) Read message Time remaining for recording BATTERY LEVEL INDICATOR 100% -> 60% 60% -> 20% 20% -> 5% 5% -> 0% MESSAGE RECORDED Duration of recorded message Date and time of recorded message CURRENT MESSAGE Duration of current message Date and time of message DELETE CURRENT MESSAGE Duration of the message to be deleted Date and time of the message to be deleted DELETE ALL MESSAGES Total number of messages to be deleted Total duration of all messages to be deleted... -
Page 9: Specifications
Requires 3 X AAA batteries (not included) · Visual angle 68 degree · Standby mode: up to 45 days with messages, up to 6 months without messages. (based on 3 X AAA alkaline battery 1250mAH) · Record mode: up to 6.5 hours, based on 3 X AAA alkaline type battery (1250mAH) · Play mode up to 4 hours, based on 3 X AAA alkaline type battery (1250mAH) · Memory Size 256Mb SDRAM · · Built-in microphone and speaker · Magnet in the back panel · LED Message indicator... - Page 10 FCC COMPLIANCE STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, maybe cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different form that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Disposal of old electrical and electronic equipment: After the implementation of the European Directive 2002/96/EU in the national legal system, the following applies: Electrical and electronic devices may not be disposed of with domestic waste. Consumers are obliged by law to return electrical and electronic devices at the end of their services lives to the public collecting points set up for this purpose or This symbol on the product, the instruction manual or the package indicates that ...
- Page 11 Regulations According to R&TTE Declaration of Conformity If you are having any problem getting your PLAY to work, please go to www.nativeunion.com for further information or consult your retailer. If neither of those solve the problem, please feel free to e-mail us at support@nativeunion.com, and we will do our best to help you. LIMITED WARRANTY If the product appears to be damaged or does not function properly, please follow the advice in this booklet. instructions about how to obtain warranty service. Spec. is subject to change without prior notice. Assembled in China © Native Union and Native Union Logo are registered trademarks of Design Pool Ltd All other trademarks and registered trademarks are the property of their respected owners. Other product and company names mentioned herein may be trademarks of their respective companies. Web www.nativeunion.com Email contact@nativeunion.com...
- Page 12 You are just few seconds away from enjoying your new video-memo! I’m the instruction manual . .. Web www.nativeunion.com Email contact@nativeunion.com...
