Wynncom W617
User Manual
Note: The content of the manual is correct when it is released, but "Wynncom Digital Devices Pvt. Ltd" reserves the right to modify the technical
specification without additional notification. Some content in the manual may be different from the mobile phone as the accessory, software, SIM card or
service varies by providers.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W617 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wynncom W617

Summary of Contents for Wynncom W617

  • Page 1 User Manual Note: The content of the manual is correct when it is released, but “Wynncom Digital Devices Pvt. Ltd” reserves the right to modify the technical specification without additional notification. Some content in the manual may be different from the mobile phone as the accessory, software, SIM card or...

  • Page 2: Table Of Contents

    Table of Contents SAFETY PRECAUTIONS………………………………………….03 Message................. 14 1.1. Write message.............. 14 1.1.1. SMS ..............14 1.1.2. MMS ..............15 1.2. Inbox ................15 1.3. Outbox................15 1.4. Draft box ..............15 1.5. Sent box ............... 15 1.6. Templates ..............16 1.7.
  • Page 3 5.4.2 Snake..............22 5.5 Facebook/MSN/Yahoo/Hungama ......22 Multimedia................22 6.1 Video Recorder ..............22 Video player..............22 Image Viewer............... 23 FM radio................ 23 Sound Recorder ............24 7. Profiles… .................. 24 8. My files ..................24 9.Organizer................... 24 9.1 Backup..................24 9.2Calendar ..................

  • Page 4: Safety Precautions

    Important safety precautions This section contains important information on the safe and efficient operation of your mobile device. For your safety, please refer to the guidelines prior to using the phone. Note: Failure to comply with the following precautions may be dangerous or illegal. Drive safely at all times Do not use a hand-held phone while driving.
  • Page 5 Accessories and batteries Use only approved batteries and accessories, such as headsets and PC data cables. Use of any unauthorized accessories could cause damages to you and your phone and may be dangerous. If jewelry, keys, beaded chains, or other conductive materials touch exposed battery terminals, this could complete an electrical circuit (short circuit), become very hot, and could cause damage or injury.
  • Page 6 As with other mobile radio transmitting equipment, users are advised that for the satisfactory operation of the equipment and for the safety of personnel, it is recommended that the equipment should only be used in the normal operating position (held to your ear with the antenna pointing over your shoulder). Ensure to avoid extreme heat or cold;...
  • Page 7 ＊Failure to observe these instructions may lead to the suspension or denial of telephone services to the offender, or legal action, or both. Wynncom Authorized Care Centre Only Wynncom qualified service personnel may repair your phone. It is highly recommended to have a repair or service by qualified service personnel. Use only the approved accessories and batteries.
  • Page 8 Introduction Phone Display Function Dial and receive calls via SIM1 or SIM2 card. Call Dial & Receive Key View call history of SIM1 or SIM2 in idle mode. Press and hold to turn the phone on/off. Call Reject Key/Power on/off End a call or reject an incoming call.

  • Page 9: Getting Started

    Press to enter symbol when editing text. Press to switch input modes when entering text. Press and hold to activate or deactivate the silent mode in idle mode. Press to access four functions in idle mode Navigation Key (Up: access SIM in idle screen; Down: access Widgets in idle screen; Within a menu, press Up, Down, Left or Right to scroll through menu options.
  • Page 10 Remove the battery Put your finger on the black holder located at the bottom of the battery slot and lift the battery up to remove it.for further clarrification please refer the pic below : Insert the SIM card Make sure that the clipped corner of the SIM card is facing the correct direction and the metallic contacts are facing downwards. Slide the SIM card into the card slot until it stops.

  • Page 11: Important Password

    Turning the phone on To turn the phone on, press and hold the Call End key. If you have already enabled the Sim Lock fucntion then enter the PIN code (the 4 to 8 digit code of your SIM card). It is preconfigured and provided to you by your network operator or retailer. If you enter an incorrect PIN code 3 times in succession, your SIM card will be locked.
  • Page 12 Go to Settings > Security Settings > Auto keypad lock to select the time for keypad lock. In idle mode, if the time expires, the keypad will be locked automatically. Long Press * key to Lock Keypad Press LSK+ * Key in quick succession to unlock the keypad manually. Text Entry 1.

  • Page 13: Menu Functions

    1. Press the # Key to switch to Smart ABC. 2. Press 4 6 6 3, the first word “GOOD” appears. 3. Use navigation keys to browse and select “HOME”. 4. Press the Left Soft Key [Select] to confirm “HOME”. 3.

  • Page 14: Message

    Main Menu Message contact Call logs Settings Y -Zone Multimedia Profiles My File Organizer Audio Services Camera For further clarification refer the main GUI picture below: 1. Message This chapter introduces the message services provided by the GSM network. Some services may not be supported by the local network. 1.1 Write message 1.1.1.

  • Page 15: Mms

    Save as draft: Save to Draft box. Exit: Exit the message box. 1.1.2. MMS The MMS function allows you to send text and multimedia such as pictures, audio and video to the other phone. After creating the message, you have the follow options: Send: Send the message.

  • Page 16: Templates

    1.6 Templates You can preset frequently used sentences here to avoid repeated input when writing a message. 1.7 Schedule SMS You can schedule the SMS for particular date and time and send. 1.8 Cell Broadcast Look up the broadcast messages. 1.9 Setting There are eight options: SIM 1/SIM2 Message Service center number, validity period, Message Type, Delivery report, Direct Reply, Inbox Location, Save sent message.

  • Page 17: Call Logs

    Add new contact: This option is at top in the phonebook or select from options. You can add a new phone number to SIM1, SIM2 or phone. Delete Multiple: You can delete multiple contacts. Copy: You can copy contacts in phone memory, SIM1 memory and SIM2 memory. Import / Export: Import and Export contacts to memory card.

  • Page 18: Settings

    Note : Default password is “0000”. 4 Settings 4.1Phone Settings 4.1.1 Time and date Set time Set the time Set date Set the date. Time format Set the time format Date display Set the date display format Auto Update with time settings Update date and time automatically from network 4.1.2 Language Select the language for your handset.

  • Page 19: Security

    Contrast Set the backlight brightness Keypad backlight Set the Keypad backlight time. Have "20 seconds", "10 seconds", "5 seconds," "night mode" and "off" five ways to time choose 4.3 Security The phone provides several security options to protect your phone from misuse. 4.3.1 PIN You can enable / disable the SIM lock.
  • Page 20 You can specify the conditions under which calls should be diverted to your voicemail box or another number. Call forwarding unconditional All calls are diverted. Call forwarding on busy A call is diverted if the phone is switched off or is out of range. Call forwarding on no reply A call is diverted if not answered.

  • Page 21: Connections

    5.3 Mobile Tracker Now do not panic, even if your handset is misplaced. The Mobile Tracker feature in W617 allows you to keep a track of your handset if it is lost. Just activate Mobile Tracker application and assign the numbers, so that if you lose your handset, you can receive a warning SMS on those pre-defined numbers.

  • Page 22: Games

    The default Mobile Tracker password is “0000”. 5.4 Games 5.4.1 Tetris Tetris game is a popular and classical game all over the world; it is very simple to play. Play process, navigation keys and left soft key control game. 5.4.2 Snake Snake game is a popular and classical game all over the world;...

  • Page 23: Image Viewer

    etc. Set as screen saver Set the video as screen saver. Set as power on animation Set the video as power on anime. Set as power off animation Set the video as power off anime. See the details. File attributes Exit from video player.

  • Page 24: Sound Recorder

    Open speaker Open speaker. Manual search Search the channel manually. Record file list Watch the recorded file list. Storage Set the recorded file storage to phone or memory card. File format Save the file format. 6.5 Sound Recorder Your phone supports recording .You can record your voice with the help of this function. 7.

  • Page 25: Calendar

    9.2Calendar Options: Add new schedule You can add a new schedule. View schedule You can view the already saved schedule. All schedule You can view all schedules. Clear today’s task Delete today’s schedule. Clear all Clear all saved schedules. Go to date Go to date.

  • Page 26: Bluetooth

    Length This option for“kilometers <-> miles”, “m <->yard”，“m<->foot”,“cm <-> inches”conversion. 9.7 Bluetooth  Bluetooth: Allow you to switch on/off Bluetooth.  Bluetooth visibility: Allow you to switch on/off Bluetooth visibility.  Paired Device: Paired devices will be listed.  Shared folder settings：Set the folders to share. Device name: Set your device name.

  • Page 27: Services

    11Services This function allows you to acquire or visit diversified services on the internet through message or network, please contact your network operator for more information. Note: Your Internet service provider may not support some functions. In order to guarantee the normal operation of the browser line, pleas confirm your SIM card which can support the Internet and open up the function.

  • Page 28: Technical Specification

    Shutter sound : You can on / off this function. Auto save : You can on / off this function. Storage : You can set the storage memory to phone or memory card. Technical Specification W617 GSM Network 900/1800MHz Display Size 7.6Cm...
  • Page 29 Warranty Terms and Conditions Wynncom Digital Devices Pvt. Ltd., (hereinafter referred to as the ‘Company’) provides this Limited Warranty to the purchaser of the Wynncom mobile handset and original accessories (Battery, Charger, Hands free etc.) supplied in the sales package (hereinafter collectively referred to as the ‘Product’).
