Modal craftsynth User Manual page 16

MIDI CC Implemention Chart
Function CC
Glide 5
Headphone Volume 7
Distortion 12
Delay Amount 13
Delay Time 14 No Sync: 0 - 250 milliseconds / Sync: 8 steps, division of host clock
Delay Feedback 15
Osc1 Shape 16 0 - 21 Sine / 22-42 Tri / 43-63 Saw / 64-127 PWM duty 50% - 5%
Osc2 Shape 17 0 - 21 Sine / 22-42 Tri / 43-63 Saw / 64-85 Square / 86-127 Noise
Osc Mix 18
FM Amount 19
0-63 Unison Spread / 64-76 major / 77-89 minor / 90-102 7th /
Spread 20
FEG Attack 22
FEG Decay 23
FEG Sustain 24
FEG Release 25
AEG Attack 26
AEG Decay 27
AEG Sustain 28
AEG Release 29
Osc2 Detune 30
Osc2 Fine 31
FEG Invert 32
Filter Morph 33 0 = LP / 64 = BP / 127 = HP Continuous morph
Filter Cutoff 34
30
Values
0 - 2.5 seconds, exponential control
Silence - full volume
Dry - Wet
Dry - Wet
0% - 90%
OSC1 - OSC2
No FM to +/- 2 Octave modulation
103 maj 7th / 116-127 maj Octave
0 - 4 Seconds
0 - 2 Seconds
0 - 1
0 - 4 Seconds
0 - 2 Seconds
0 - 4 Seconds
0 - 1
0 - 4 Seconds
-/+4 Octaves, Snaps to Root, min3, maj3, 5th
-/+ 50 Cents
0-63 Not inverted, 64-127 Inverted
0Hz - 20kHz
MIDI CC Implemention Chart
Function CC
Filter Resonance 35
NO SYNC: 0-63 = 0-32Hz Free / 64-71 Root/8 / 72-79 Root/4 /
80-87 Root/2 / 88-95 Root / 96-103 Root*1.5 /104-111 Root*2 /
LFO Rate 36 SYNC: 0-7 = 1/16 / 8-15 = 1/8 / 16-23 =1/4 / 24-31 =1/2 / 32-39
= 1 / 40-47 = 5/4 / 48-55 =2 / 56-63 = 4 (Cycles per beat), then /
64-71 Root/8 / 72-79 Root/4 / 80-87 Root/2 / 88-95 Root / 96-
103 Root*1.5 /104-111 Root*2 / 112-119 Root*2.5 / 120-127
LFO Depth 37
0-21 AMP / 22-42 FRQ / 43-64 CUT / 65-85 FM / 86-106 MIX / 107-
LFO Destination 38
0-14 Sine / 15-31 iSine / 32-47 Tri / 48-63 iTri / 64-79 Ramp up /
LFO Shape 39
80-95 Ramp down / 96-120 Square / 121-127 iSquare
Octave 40 Octave shift -2 to +3 ( 0-21/22-43/44-65/66-87/88-1109/110-127)
C Major (0-24) C Minor (25-49) C Diminished (50-74) C Major Aug-
Scale 41
Delay MIDI Sync 42
AEG Release 72
AEG Attack 73
Filter Cutoff 74
AEG Decay 75
Glide 84
Values
None - Full
112-119 Root*2.5 / 120-127 Root*3
Root*3
0 - Full
127 PWM
mented (75-99) C Blues Pentatonic (100-127)
0-63 Off, 64-127 On
0 - 4 Seconds
0 - 4 Seconds
0Hz - 20kHz
0 - 2 Seconds
0 - 2.5 seconds, exponential control
