Epson ACULASER C9100 Paper Jam Manual

Color Laser Printer
Paper Jam Guide
1
2
Caution:
c
Do not touch the transfer roller
(black rubber roller) of the transfer
unit or the transfer roller of the
intermediate transfer unit.
Touching them may deteriorate
print quality, or damage the transfer
roller and require replacement.
Transfer roller (black rubber roller) of the transfer unit
Transfer roller of the intermediate transfer unit
Jam B (cover B)
3
Paper discharge slot
If the end of the jammed paper
sticks out of the paper discharge
slot, gently remove the paper from
the slot and proceed to step 5.
cover B
If the jammed paper does not stick
out of the paper discharge slot,
remove the jammed paper from
inside cover B.
When the LCD panel displays the Jam XXX error message, choose the appropriate
description to clear the jammed paper.
For more information, see the Online Reference Guide.
4
5
Cautions
c must be observed to
avoid damage to your equipment.
For Long-size Paper
1
2
3
Continue to the next page
