Summary of Contents for Converters.TV 989
- Page 1 Digital S/PDIF and Toslink Audio over single Cat5e/6 Transmitter & Reciever - ID# 989 Operation Manual...
- Page 2 Introduction Digital S/PDIF and Toslink Audio over single Cat5e/6 Transmitter & Reciever is designed to transmit Optical and Coaxial digital audio signals up to 150 meters using one CAT5e/6 cable. Supports stereo and multichannel LPCM, 7.1, DTS, Dolby Digital audio etc via Digital TosLink cable (optical fibre) or Coaxial cable.
- Page 3 Operating Functions Controls Transmitter 1. Coaxial In: This slot is to connect with source audio equipment such as DVD or Blue-Ray player for input audio signal sending. 2. Optical In: This slot is to connect with the audio source equipment such as DVD or Blue-Ray player for input audio signal sending.
- Page 4 Top Panel 1. Power LED: The blue LED will illuminate when the device is connected with power. RJ-45 Pin Assignment Transmitter Receiver Definition Definition Signal A Signal A Signal B Signal B Cat5/5e/6 Signal C Signal C 150M < > Signal D Signal D DC5V...
- Page 5 Connection...
- Page 6 Specifications Transmitter Input 1 x Coaxial & 1 x Optical Output 1 x CAT6 Receiver Input 1 x CAT6 Output 1 x Coaxial & 1 x Optical CAT6 Cable Distance 150 meters Sample Rate 32 / 44.1 / 48 / 88.2 & 96KHz ESD Protection Human Body Model: ±...
