- Page 1 Permanent makeup and hair follicles simulation The ORON 58 is a micro p i g m e n t a t i o n d e v i c e based on roller or needle pigmentation insertion. User Manual...
-
Page 2: Table Of Contents
Table of Contents: Content Page ORON 58-Device..............3 Control unit................4-6 Device Parts (7-9): Handle..................7 Foot Pedal................8 Power supply................9 Getting Started..............10-11 Adjusting the Roller & Troubleshooting (for Hair Follicles Simulation)..........12-13 Integral Needle (for PMU)............14 Warranty..................15 Service..................16... -
Page 3: Oron 58-Device
The ORON 58 Device Power Supply Power Station Hand piece Pedal Head for Needle Device parts: Control unit Power supply Activation foot pedal Handle(Roller/needle holder assembly) -
Page 4: Control Unit
Control unit Speed Display Decrease Speed Increase Speed Model Name Electronic Ciruit Handle On/Off Power On/Off Numerical display – Displays device speed Piece key – Activities/Deactivates power to the Handle Power key – Turns the control unit On or Off Electronic circuit –Displays Device Status On/Activity... - Page 5 Control Unit Weight: 770 grams Speed display The speed display range is 100-200 Height: 3mm Lenght: 17mm Width: 17.5mm 12 Volt 1.5 AMP Speed control keys Press the POWER PIECE key – e n a b l e s h a n d l e A LED light above the activation by pressing key indicated control...
- Page 6 Control unit Connectors Pedal Connector Handle Connector Power Connector 12VDC – Power supply input PIECE – Handle Cable input PEDAL – Foot Pedal Cable input...
-
Page 7: Device Parts
Device Parts: Handle Needle Cord Position Hand piece The roller is mounted on the handle A cable connects the handle to the control unit Cable length 180 cm Handle weight 80 grams The PIECE LED light indicates the unit’s power status 1. -
Page 8: Foot Pedal
Foot pedal Cord Pedal Connector to Power Station Pressing on the foot pedal activates the handle motor The foot pedal is connected to the control unit via a cable (180cm long) Activating the foot pedal Make sure the foot pedal connector is securely connected to the control unit Press the foot pedal to activate the unit Release the foot pedal to deactivate the unit A second option is available for those who don’t want to use a foot pedal, a silver... -
Page 9: Power Supply
Note: Make sure the power supply cable is free of foreign objects Specialized Training: Training is done only by authorized NPM training guide Training includes: System operation Troubleshooting Permanent makeup and hair follicles simulation techniques An NPM course completion certificate is given after successfully completing the course... -
Page 10: Getting Started
Getting Started Before using the ORON 58 Device please follow the next steps: Wear disposable gloves Make sure all cables are securely connected Power the base unit On and activate the Piece (make sure the Electronic Circuit Led is blinking) - Page 11 The unit is now ready for permanent makeup and hair follicles simulation implementation Connect the handle cable to the to the control unit connector labeled PIECE Connect the foot pedal to the control unit connector labeled PEDAL Connect the power supply cable to the control unit connector labeled 12VDC Press the POWER key Press the PIECE key While holding the PIEACE base in your left hand turn the handle head using your...
-
Page 12: Adjusting The Roller & Troubleshooting
Adjusting the Roller & Troubleshooting (for Hair Follicles Simulation) Make sure both Power and PIECE lights are on Adjust the units speed by using the (+) (-) keys and observing the speed display (recommended speed is 170) A d j u s t i n g t h e roller: Press the foot pedal and rotate the handle... -
Page 13: Troubleshooting
Troubleshooting: Condition Possible Causes Roller not vibrating (foot pedal Low roller speed – Adjust roller speed activated) Roller not adjusted: Hold the handle base with your left hand and with your right hand rotate the tip part of the hand piece and rotate it counter clockwise until the roller stop to vibrate. -
Page 14: Integral Needle (For Pmu)
Turn the roller/needle a quarter turn counter clockwise and pull it out of the roller base Dispose of the roller/needle properly Place the handle back into the control unit Warning: The ORON 58 device can only be used by NPM authorized and trained staff... -
Page 15: Warranty
Warranty Warning: Do not use or operate the unit without proper training Repairs: Only NPM technicians are authorized to repair the unit Do not attempt repairing the unit yourself Packaging: The unit and accessories are supplied in a specially designed case... -
Page 16: Service
Service For Repair services call +972-4-8702206 or e-mail us at: sales@npm.co.il Classification: The unit is classified as Class 1 Continues use, portable Do not use near flammable material Storage and operational environmental conditions: 10-40 degrees centigrade 30-75% relative humidity 700-1060 hPa atmospheric pressure...
