□ H e a d
O f f i c e 86-66 Nomizo-cho Otsuka Yamashina-ku 607-8135 Kyoto JAPAN
□ C a m e r a
□ I m a g e I n s p e c t i o n D e p t .
□ T o k y o
O f f i c e 2F MK Bldg. 2-2-19 Sotokanda Chiyoda-ku 101-0021 Tokyo JAPAN
TAKENAKA SYSTEM CO.,LTD.
TAKENAKA SENSOR GROUP
Line scan camera
Instruction Manual
Model: TL-1024UCL
TAKENAKA SENSOR GROUP
TAKENAKA SYSTEM CO.,LTD.
TEL:+81-75-593-9300 FAX +81-75-593-9790
D e p t . 4F Matsumasa Bld.1-17-14 Ogaya Otsu Shiga 520-2144 JAPAN
TEL:+81-77-545-4331 FAX +81-77-545-4335
86-66 Nomizo-cho Otsuka Yamashina-ku 607-8135 Kyoto JAPAN
TEL:+81-75-593-9300 FAX +81-75-593-9790
TEL :+81-3-3255-0361
URL http://www.takex-system.co.jp/
URL http://www.takex.co.jp/
FAX:+81-3-3255-0362
(ver.0.4)
1 / 17
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Takex tl-1024ucl
Summary of Contents for Takex tl-1024ucl
- Page 1 (ver.0.4) 1 / 17 Line scan camera Instruction Manual Model: TL-1024UCL TAKENAKA SENSOR GROUP TAKENAKA SYSTEM CO.,LTD. □ H e a d O f f i c e 86-66 Nomizo-cho Otsuka Yamashina-ku 607-8135 Kyoto JAPAN TEL:+81-75-593-9300 FAX +81-75-593-9790 □ C a m e r a D e p t .
-
Page 2: Table Of Contents
2 / 17 Table of Contents ………………………………………………… 3 1. Outline ………………………………………………… 3 2. Features ………………………………….…………… 3 3.Applications ……………………………………. ………… 3 4. CCD image sensor …………………………………… …………… 4 5.Specifications ……………………………… ……………… 4 6. Camera I/O 6-1. Connector pin assignment of the Power connector 6-2. -
Page 3: Outline
3 / 17 1. Outline ● CCD line scan camera with 1024 pixels of image sensor and of 50MHz data rate. ● Video signal is output complying with Camera Link standard (Base Configuration). 2. Features ● It can perform high-speed inspection with 1024 image pixels at 50MHz data rate. ●... -
Page 4: Specifications
4 / 17 5. Specifications Number of pixels 1024 Unit cell size 10μ m×10μ m Photo array length 10.24 mm Data rate 50 MHz Scan rate (scan/sec) 45.45 kHz Max. Line transfer pulse input 22 μ sec Base Configuration Video output (Digital output) 2×8/10 bit Sensitivity 50 Ｖ/lx．sec... - Page 5 5 / 17 6-2 Camera Link connector Camera Link connector pin-out Conforming cable 3M made 14B26-SZLB-＊00-0LC (＊m) ※ 14B26-SZ3B-＊00-04C (＊m) ※ Flex resistance cable Camera Control Configration Base Configuration Connector Signal name Connection Pin No. Signal name Pin No. Signal name Shield Shield EXSYNC...
-
Page 6: Timing Chart
(ver.0.4) 6 / 17 7. Timing chart Ⅰ.TL-1024UCL Timing Chart STR OBE (25 MHz ) EX SYN C In (CC 1 I N) Effective data period 59 clock L INE V ALI D PIX EL DA TA POR T A... -
Page 7: Serial Communication Protocol
SYNC period = Minimum period + n × a Where Internal sync(sync=2) n= expt (exposure time) a= 12.8μsec ….. TL-5150UCL TL-1024UCL 10.24μsec ….. TL-2048UCL TL-4096UCL TL-7400UCL TL-7400RCL TL-7450UCL (3) Exposure control system switching (Refer to the time chart on P.11) - Page 8 8 / 17 [Network transmission setting] Baud rate :9600bps Data Length :8bit Start Bit :1bit Stop Bit :1bit Parity :Non Xon / Xoff Control :Non [Communication overall] 1. Viewing To view the status of the camera. e.g. Id? <CR> To view the camera ID. 2.
- Page 9 9 / 17 [ Description of exceptional case] ＊NG is returned when in command input error or in inputting nonexistent command. e.g. : Command input error (Gain position No. is not designated. ) Input: ch1gain=96 Output: NG e.g. : Input of nonexistent command Input: chake Output: NG...
- Page 10 10 / 17 【Command Protocol】 (PC->Camera) Command Format Argument Return value Explanantion Name Communication 1 Check check<CR> Command for communication test Camera setting 0:Dip Switch View the effective state of Communication setting value/DIP 2 Ctrl (view) ctrl[?]<CR> 1:Com N=0:Dip Sw Set the effective state of Communication setting value/DIP 3 Ctrl (set) ctrl=N<CR>...
-
Page 11: Exposure Control
11 / 17 9. Exposure control Pulse width exposure (expc=2) Exposure during the period of the pulse width(H) of EXT.SYNC(CC1 Minimum exposure time =10.24μsec ★Note that the minimum period of EXT.SYNC is 23μsec at the Pulse width exposure mode Minimum period = 1μsec + DATA output duration(22μsec） ST-1 ST-2 ST-3... -
Page 12: Setup Steps Of Hyper Terminal
12 / 17 Setup steps of Hyper terminal. [Setup of Hyper terminal ] 1) Select “Start”→ “Programs”→”Accessories”→”Communications”→”Hyper Terminal” 2) The windows will appear with the picture below. 3) When the next picture appears, enter any name.(e.g. GMA_RS232C) Then click the “OK” button. 4) When the next picture appears, select “... - Page 13 13 / 17 5) When the next picture appears, select each items as follows.(9600,8,None,1,Non) Then click the “OK” button. [Communication settings] Baud Rate : 9600bps Data Length : 8bit Start Bit : 1bit Stop Bit : 1bit Parity : Non Xon/Xoff Control : Non 6) The next picture will appear.
- Page 14 14 / 17 8) When the next picture appears, select “Settings” tag. 9) When the next picture appears, click the “ASCII Setup” button. 10) When the next picture appears, select each items as follows.(☑, ☑, 0, 0,☑, blank, blank) Then click the “OK” button. 11) The screen display will return to the screen of 9).
- Page 15 15 / 17 12) End of setup. Confirm the connection of the camera , enter “check” on the screen below and then send it out. If “OK” is displayed on the screen, communication processing has been completed. 13) Select “Start”→ “Programs”→”Accessories”→”Communications”→”Hyper Terminal” →”(＊1) ”, when to launch the Hyper terminal again with the same settings after having exited the above screen.
-
Page 16: Notes
16 / 17 11. Notes Precautions for use ■ Do not make an impact on the equipment. ■ Do not lag the equipment with heat insulating agent. If the equipment is covered with heat insulating agent, It produces an increase in teｍperature and it causes the equipment to malfunction.(except for low-temperature environment use) ■... -
Page 17: External Dimensions
17 / 17 12. External dimensions M 2.6 De pth 6 8 0.3 63.5 ( Four f aces) Came ra Li nk F -Mo unt Element Ｐ Ｏ Ｗ Ｅ Ｒ Ｍ Ｏ Ｄ Ｅ Ｌ ＴＬ － 51 50ＵＣ Ｌ Ｓ...
