Summary of Contents for JPL Ltd X400
- Page 1 X400 WIRELESS HEADSET USER MANUAL...
- Page 2 Contents (What is included) BASE UNIT MICROPHONE HEADBAND EAR HOOK LEATHETTE EAR CUSHION TELEPHONE CONNECTION CORD POWER ADAPTER USB CABLE (OPTIONAL EXTRA)
- Page 3 Headset Mute / Speaker Volume In-Use / On-Off Indicator Call Hook On / Off Down Black & Wine Cover Options Mute - To change the Speaker Volume, roll the switch towards the ‘plus’ sign to increase the volume and roll the switch towards the ‘minus’ sign to reduce the volume and press the switch to activate the microphone mute mode.
- Page 4 Base Unit Top of Base Unit Bottom of Base Unit Side of Base Unit PC/TEL Selection Button Microphone Volume Compatibility Switch Microphone Mute Button Adjustment Switch PC/TEL Selection Button Press to switch between PC and TEL Microphone Mute Button Press to mute call Microphone Volume Switch After installation, adjust the volume level for the best level of microphone volume.
-
Page 5: Setting Up The Base
Setting up the Base Desk Phone with HEADSET Port - Plug the supplied telephone cord into the TEL port of the BASE UNIT - Connect the telephone cord to the HEADSET port of the desk phone - It will take 3 mins for the Unit and Headset to auto connect to the telephone) - Follow the fine tuning instructions to... - Page 6 1. When your desk phone is in-use on an external call (ie. No dial tone), set the volume on the desk phone to Max. 2. Adjust the Microphone TX on the base of the X400 unit. 3. Fine tune the listening speaker of the headset using the ‘plus’ and ‘minus’ toggle.
- Page 7 Operating Instructions - Plug the Power Adapter DC Jack into the back of the Base Unit. (See Note 1) - Press the Hook On/Off switch to make a call - Select compatibility switch ‘1’ or ‘2’ position until you can hear the dial tone - Adjust speaker and microphone volume - Press the Hook On/Off switch to end a call Note 1 : Factory default setup : Paired...
-
Page 8: Led Indicator
LED Indicator Charging Status LEDs status Charging Battery Indicator : ‘Blinking’ 3 sec-ON, 1 sec-OFF Full Charged Battery Indicator : ‘ON’ Low Battery Battery Indicator : ‘Blinking’ 1 sec-ON, 1 sec-OFF Event LEDs status Press Microphone mute Mute indicator : ‘ON’ Press PC/TEL selection PC/TEL Indicator - TEL : ‘OFF’... -
Page 9: Troubleshooting
Trouble Shooting 1. Can not hear a dial tone. • Check the PC/TEL button. TEL Mute: PC/TEL indicator – ‘OFF’ • Please check the cable connection between Base unit and Phone. • Check that the power adapter is plugged in and has power •... -
Page 10: Limited Warranty
JPL and to the extent permitted by law, are excluded. JPL Ltd, Church Close Business Park, Todber, Sturminster Newton, Dorset, DT10 1JH, ENGLAND Tel: +44(0)1258 820100 E-mail: sales@jpl.uk.com...
