- Page 1 User manual High definition digital satellite receiver Model ID: 7101 English 3/2009 jp...
-
Page 2: Table Of Contents
User manual Contents Safety precautions .......................... 4 Environment protection........................6 Features ............................7 Remote Control ..........................8 Front panel ............................ 10 Rear panel ............................. 11 Connecting ............................ 12 Getting started ..........................14 8.1. Easy install ..............................14 8.2. Box Setting ............................... 14 8.3. - Page 3 User manual 10.9. Zoom ..............................29 10.10. Time Shift (optional, only for PVR ready receivers) ................29 10.11. Recording, Edit the reserved delayed Recording (optional, only for PVR Ready receivers) ....30 10.12. Immediate Recording by RECORD button (optional, only for PVR Ready receivers) ...... 30 10.13.
-
Page 4: Safety Precautions
User manual Safety precautions CAUTION: The lightning flash with Warning: The exclamation point within arrowhead symbol, To reduce the risk of electric an equilateral triangle is within equilateral shock, don't open the cabinet. intended to alert the user to triangle, is intended to Refer servicing to qualified important operating... - Page 5 User manual Attachments: Never add any attachments and/or equipment without the manufacturer consent; as such additions may result in the risk of fire, electric shock, or other personal injury. Locating: Slots and openings in the cabinet are provided for ventilation to protect it from overheating.
-
Page 6: Environment Protection
User manual Environment protection Attention! Your product Is marked with this symbol. It means that used electrical and electronic products should not be mixed with general household waste. There is a separate collection system for these products. Information on Disposal for Users (private households) in the European Union Used electrical and electronic equipment must be treated separately and In accordance with legislation that requires proper treatment, recovery and recycling of used electrical and electronic equipment. -
Page 7: Features
User manual Features MPEG-Fully DVB-S / DVB-S2 (H.264) HD compliant 8000 channels (TV and Radio) programmable Multilingual menu text support Channel switching time less than 1 second Channel list editing Favorite channel list editing True-color On-Screen Display (OSD) ... -
Page 8: Remote Control
User manual Remote Control You can power on/off the receiver, operate on screen menu, and use a variety of hot key function. Switch the PVR between Operation and POWER Standby mode. Włączanie lub przełączanie w stan czuwania Standby. Display the sleep time. At the sleep time, SLEEP the power is automatically turn OFF and the PVR goes to the STANDBY mode. - Page 9 User manual (Optional, only for PVR Ready receivers) Display the progress bar of time shift or playback when no progress bar is displayed.Start playback with normal speed. Return to normal speed from trick mode. (Optional, only for PVR Ready receivers) Stop time shift, playback or recording. Stop the MP3 or JPEG player.
-
Page 10: Front Panel
User manual Front panel POWER KEY: To switch the receiver power on/stand by MENU KEY：To enter into the main menu. <,> KEY: To adjust volume level, or to move cursor left or right in the menu. ^, v KEY : To change channels, or to move cursor up or down in the menu OK KEY: To see TV/Radio channel list, or to confirm in the menu. -
Page 11: Rear Panel
User manual Rear panel Please refer to the diagram above for all possible connections of your receiver. Do not connect the unit to the mains socket until all other connections have been made and checked. Your configuration can vary depending on model POWER ON/OFF SWITCH: To switch ON/OFF the receiver power supply. -
Page 12: Connecting
User manual Connecting There are four ways to connect the receiver to your existing TV system. We recommend using one of the following cases for the best result: If you have a high definition television set, you should use a HDMI cable for best result, Plug one end of the cable into the HDMI socket on the receiver, and the other end into the matching socket on your television. - Page 13 User manual Connecting with Motorized System (DiSEqC 1.2) Connect one end of your coaxial cable to the LNB IN connector on the receiver and the other end to the REC or Receiver connector on the DiSEqC 1.2 motor. Connect the coaxial cable from the LNB to the LNB connector on the DiSEqC 1.2 motor.
-
Page 14: Getting Started
User manual install. For more details, please refer to the chapter “Manual Installation” of “Menu Operations”. Getting started Menu operations 8.1. Easy install Now this chapter assumes that the HD Receiver system has been installed correctly, meaning: Press the button to operate the receiver from The satellite antenna for the HD Receiver has ... -
Page 15: Organizing Favourites
User manual You can restrain and Skip (hide) the services. Mark the Group, Options, Service Found and Detail Information display desired services using “ OK ” button, use button to Please refer to the “Organizing Services” part in this choose Skip mode and press “... - Page 16 User manual will be shown as long as the PVR is searching for Power services. All services found will be listed in two columns Select the LNB voltage among 13, 18, 13/18, 13.5, on the screen with TV services in one column and 18.5, 13.5/18.5 and OFF by using “...
-
Page 17: Auto Installation
User manual To add a new TP to the TP list of the selected satellite. USALS (Yellow) Edit To edit the parameters (Frequency, Polarization, Symbol rate and FEC) of selected TP. (Blue) Delete To delete the TPs selected using (add ok key icon) button. -
Page 18: Guidance Of Installing A Dish
User manual 9.3.1. File List Installation” menu then it starts scanning and shows you the result at the end of scanning. Press “ OK ” button on this item to enter the File List menu. (Red)Stop Stop the automatically checking. (Green) Continue ... -
Page 19: Mp3 Player
User manual It is very convenient function to Mark the Select “Delete” item after selecting the desired services with different options. files (or folders) you want to delete. You have to confirm it at Confirm box. iii. (Yellow) Edit Play A new folder can be made by select To play the selected file, press button. -
Page 20: Record List
User manual files recorded in HDD permanently. If a new HDD is You can also enter this menu by press installed, it should be formatted because the file (White) button when watching the program. structure of PVR is different from others. You cannot use the Time shift, Recording and playback functions with an unformatted HDD. -
Page 21: Parental Control
User manual Teletext Language Go to the Change Password item to configure new PIN Code. Enter the PIN code by using the numeric buttons It is an item for changing the language of the Teletext. on your RCU. As long as the services support it, the Teletext language is changeable by press button on your 9.4.3. -
Page 22: A/V Control
User manual 9.4.4. A/V Control UHF Offset Change the value of the UHF Offset by using “ OK ” button. The default value is 0. 9.4.6. Miscellaneous Setting TV-SCART Select the mode of Video output between RGB and CVBS on TV SCART by using “... -
Page 23: Upgrade Rs232
User manual 9.5.2. Upgrade RS232 Start upgrade After you select the "Upgrade File", press “ OK ” button on "Start upgrade" item, the receiver can upgrade automaticlly. You can also Press Archive Button to direct enter the” upgrade from HDD” meun list This item is very convenient to transfer HD Receiver content such as software, data or default data to other HD Receiver for upgrading the HD Receiver via the... -
Page 24: Contact
User manual 9.5.5. Contact All information showed in this menu and submenu are coming from inserted card. In case if anything is wrong, it could be card problem. After inserting the card correctly at any time, a message-box will show on the screen with message about detecting the card, in "card info"... -
Page 25: Net Config
User manual Press (Green) to Recover the parameters. 9.7.3. Net Manual Upgrade In this menu press (Red) button to connecting to the server. When connected to the server, the available file list will displayed like the following picture, you can see the information about the software files, like state, version, type, date. -
Page 26: Tetris
User manual 9.8.2. Tetris 9.8.3. Landmine 9.8.4. Speed... -
Page 27: Function Guide
User manual , “ P+ , P- ” buttons: Browse the list, then 10. Function guide press “ OK ” button to switch the viewing service to the highlight one. button: change list from TV services to Radio 10.1. Ok list services or verse. -
Page 28: Information Box
User manual 1 hours if there is no event information of current In the timer list menu you can Using service (Red) or (Green) buttons to Delete or Modify the entries of Timer selected by pressing “ OK ” button. •... -
Page 29: Changing Services
User manual Teletext. In the software emulation mode, you can Press (Green) button to check EPG detail watch the Teletext using the RCU of PVR, event though information page by page. your TV does not support Teletext. Press (Yellow) button to enable the “Property” menu to set current service’s FAV, Lock or Skip state, Press button to setup and watch Teletext. -
Page 30: Recording, Edit The Reserved Delayed Recording (Optional, Only For Pvr Ready Receivers)
User manual Press button to display Time Shift progress bar. You have to press button once more to display Time Shift progress bar during Trick mode. (such as Fast Forward, Reverse Playback, Slow motion) 10.12. Immediate Recording by RECORD button (optional, only for PVR Ready receivers) To go to the desired playback position, press... -
Page 31: Recording By Epg (Optional, Only For Pvr Ready Receivers)
User manual service list. You can use several useful editing function at Recorded Services as followings. A. New folder: press (Yellow) button select New folder to make new folder. B. Copy： Press (Yellow) button select Copy to copy the document to other logic disk. C. -
Page 32: Slow Motion Playback
User manual the position by percent with numeric button of RCU, the playback position will be moved to the point. Press “OK” button to select the services among the recorded services list and press button to playback the multi-services in sequence automatically. You can press (Blue) button add the ... -
Page 33: Jpeg Player
User manual 10.18. JPEG Player Press button to pause the JPEG play. Press button to exit the JPEG player. 10.19. Picture In Picture (PIP) Press (Red) button to display PIP. Press (Red) button repeatedly to change the size of sub- picture or to remove the sub-picture. -
Page 34: Software Upgrade
User manual 11. Software Upgrade The HD Receiver has stable and convenience software to use. But, to improve the HD Receiver the new software of the HD Receiver may be released. Whenever a problem is found or functions are added or modified, the software in the HD Receiver has to be upgraded to enjoy better function. -
Page 35: Trouble Shooting
User manual 12. Trouble Shooting Problem Solution About HD Receiver Check the main power cable and check that it is No display VFD on plugged into a suitable power outlet. the front panel. Check whether HD Receiver is in Standby mode. ... -
Page 36: Specifications
User manual 13. Specifications SYSTEM RESOURCES 400 MIPS based CPU Main Processor Flash Memory 8Mbytes DDR SDRAM 1024+512Mbits TUNER/CHANNEL Input Connector F-type, Connector, Female Loop Through F-type, Connector, Female Signal Level -65 to -25 dBm Vertical: +13V/+14V Horizontal: +18V/+19V LNB Power & Polarization Current: Max. - Page 37 User manual RF-Modulator (Optional) PLL type CH21~69 for the Demodulation PAL BG/I/DK selectable TV Standard 75 Ohms, Male/Female RF Connector Frequency Range UHF : 470~860MHz A/V & DATA INPUT/OUTPUT Video CVBS/RGB output TV-SCART Audio L/R output Video CVBS output Audio L/R output VCR-SCART Video CVBS, RGB input Audio L/R input...
-
Page 38: Declaration Of Conformity
User manual 14. Declaration of conformity The manufacturer herewith declares the conformity of that product with the following directives and standards: Low Voltage Directive 2006/95/EG EN 60065:2002+A1:2006 EMC Directive 2004/108/EG EN 55 013:2001+A1:2003+A2:2006 EN 55 020:2007 EN 61 000-3-2:2006 EN 61 000-3-3:1995+A1:2001+A2:2005 Model: Digital Satellite Receiver DVB-S...
