MusicMan BT–X10 User Manual

Maxi bluetooth soundstation
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MAXI Bluetooth Soundstation BT–X10
The Declaration of Conformity is under the Internet link: www.technaxx.de/ (in bottom bar
"Konformitätserklärung"); Before using the device, read the user manual carefully.
Music cube with super bass and crystal clear sound!

Features

FM radio and extendable antenna for better radio reception
Built-in microphone and AUX-IN
Supports MicroSD cards and USB up to 32GB
Recording function and voice amplifier function
Supports background music when speaking with microphone
(compare with a Karaoke-function)
Connection with Bluetooth compatible devices (= Pairing)
Steaming music in MP3 / WMA / WAV format from any bluetooth enabled devices
Operating distance Bluetooth max. 10m (open range)
1.8" LCD display (2 x 4cm) displays the song name and ID3 (= music information)
Remote control (included) for more convenient operation
Rechargeable and changeable Lithium 2600mAh battery 7.4V
FM radio (autoscan of FM signal and its automatically storing) & antenna for a better
radio reception
Control buttons: 1 key to swtich the folders which are stored on MicroSD card or USB,
another key to switch the music playing / FM / Bluetooth function
Memory play (auto memory the last song played)
Ideal for traveling and parties, easy installation and handling

Charging of the battery

Only (!) use the provided adapter (7.4V) to charge the device, otherwise it may cause
damage or disfunction of the device. Charging time is approx. 5–6 hours; In order to
prolong the battery life, please do not charge more than 8 hours. While charing the RED
LED is blinking. When the battery is fully charged, the RED LED will switch off.

Power ON / OFF

Connect the speaker with the power adapter to a socket. To turn on the speaker, rotate the
„Power ON/OFF & Volume Knob" (16) to the right until you hear a CLIC tone. The RED LED
will change to BLUE. The volume of the speaker is at the same time higher. To turn off the
speaker, rotate the „Power ON/OFF & Volume Knob" (16) to the left until you hear a CLIC
tone. The BLUE LED will change to RED. Insert a MicroSD memory card to the slot (15)
or a USB flash drive to the slot (9) respectively. Both memory media have to be
formatted under Windows FAT32 with MP3 / WMA / WAV files.
MusicMan

User Manual

®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BT–X10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MusicMan BT–X10

  • Page 1: User Manual

    ® MusicMan MAXI Bluetooth Soundstation BT–X10 User Manual The Declaration of Conformity is under the Internet link: www.technaxx.de/ (in bottom bar “Konformitätserklärung”); Before using the device, read the user manual carefully. Music cube with super bass and crystal clear sound!
  • Page 2 View of the topwith display (1) Back View with keys and ports 1.8” display screen USB slot...

  • Page 3: Main Menu

    Previous / Fast Reverse – ECHO + (wheel) Play / Pause – Volume + (wheel) Next / Fast Forward Charging jack Folder Switches Handle Menu Antenna (for better radio reception) Mode MicroSD card slot AUX-IN jack ON / OFF and volume knob Microphone input jack Echo (10) function, only working when using the microphone: Rotate the Echo-wheel to the right when you want to produce higher ECHO or to reduce ECHO, rotate the...

  • Page 4: System Settings

    Repeat Choose the repeat mode: ALL, FOLDER, ONE, RANDOM Equalizer Choose from 7 EQs File Browser Browse the file which is stored on USB or MircoSD Exit Exit the MENU (7) Under Pause Mode, press shortly the MENU button enter into sub-menu: File Browser Browse the file which is stored on USB or MircoSD Delete File...
  • Page 5 Bluetooth mode. (b) The BT logo on the screen keeps twinkling. (d) Activate Bluetooth and search for device name “Musicman”, connect using the pass code “0000” if needed. Once connected, the BT logo stop twinkling. (e) Play the music from you mobile phone and enjoy.

  • Page 6: Remote Control

    cable provided. Plug one jack into the speaker, the other end into normal MP3/4 or notebook. Play the music from MP3/4 or notebook, etc. The LCD screen will display the AUX-IN cable under this state. REMARK: Under any state, LINE–IN function is prior to USB / MicroSD / FM / Bluetooth. Quick Switch: Press the MODE button (7) on the speaker to switch between Music playing/FM/Bluetooth quickly.
  • Page 7 Supports MicroSD cards and USB up to 32GB Shell material Weight / Dimensions 1 kg / (L) 15 x (W) 15 x (H) 19 cm (with handle) ® MusicMan MAXI Bluetooth Soundstation BT–X10, Power Package Contents adapter, Remote control, Microphone, User Manual Warnings Only charge the speaker with the provided original power adapter (7.4V)
