Page 1: User Manual
LCD-TFT Monitors LM5000 User Manual LM5000D11-02 Edition 03 March 2004 KROMA T E L E C O M Pol. Ind. Alcobendas - C/ La Granja, 80 28108 Madrid - SPAIN Tel. (34-91) 661 45 14 Fax. (34-91) 484 03 49 e-mail: sales@kromatelecom.com... -
Page 2: Table Of Contents
Manual de Usuario Serie LM5000 INDEX 1. FRONT PANEL ........................2 1.1 DESCRIPTION AND FUNCTIONS OF EACH PART............3 2. REAR PANEL ......................... 4 2..1 DESCRIPTIONS AND FUNCTIONS: ................. 5 3. KEYBOARD..........................6 3.1 COMMON KEYS FOR ALL THE EQUIPMENTS ..............6 3.2 SPECIFIC KEYS FOR LM5015 &... -
Page 3: Front Panel
Manual de Usuario Serie LM5000 LM5009 LM5015 LM5018 LM5018 LM5018 A) The equipment Switch on / Switch off. B) Calibration Diode C) Optical Encoder D) Keyboard E) Tally Led Indicator - 2 -... -
Page 4: Description And Functions Of Each Part
Manual de Usuario Serie LM5000 1.1 DESCRIPTION AND FUNCTIONS OF EACH PART. The equipment Switch on / Switch off. A green led switch on will let us know that the equipment is activated. Calibration Diode Led. The calibration diode led will be on in case that the equipment present values and such calibration values do not agree with. - Page 5 Manual de Usuario Serie LM5000 LM5009 LM5015 LM5018 A) Power B) Serial Number & Power Supply C) AES-EBU Audio Output (optional). D) Analog Audio Output (optional). E) Tally Input Indicator F) Connection with the Remote Equipment. G) Composite Video Inputs (A & B) (optional).
-
Page 6: Descriptions And Functions
Manual de Usuario Serie LM5000 2.1 DESCRIPTIONS AND FUNCTIONS: Power. The power supply characteristics will have to agree with the ones indicated in label B. Serial Number This identification card allows to distinguish three basic parts: - The equipment Serial number. - Necessary Power supply for the equipment at issue (voltage and power). -
Page 7: Common Keys For All The Equipments
Manual de Usuario Serie LM5000 LM5009 LM5015 LM5018 3.1 COMMON KEYS FOR ALL THE EQUIPMENTS CCVS: Composite video input selection. The first time that the key is pressed appears the current, and the second and the successive ones will cause a change of video input. - Page 8 Manual de Usuario Serie LM5000 CDV: SDI input selection. The first time that the key is pressed appears the current, and the second and the successive ones will cause a change of video input. If the CDV option is installed will appear an indicative text on the screen, it will show the input selected in each time, and the presence or absence of signal in the same one.
-
Page 9: Specific Keys For Lm5015 & Lm5018 Equipments
Manual de Usuario Serie LM5000 After few seconds or pressing the ESC key such message will disappear automatically. AES-EBU Audio output channels selection: It will allow to select the AES-EBU audio output channels.The first key pressing will indicate the last AES-EBU Audio output channels selected and the second and successive ones will do an output channels change. -
Page 10: Keyboard
Manual de Usuario Serie LM5000 HUE: Hue control on the screen. This is only for NTSC video signals. When this key is pressed, it will appear the current screen Hue value, and if it agrees with the calibrated value (CAL) , if not (UNCAL). By means of the optical encoder (C in the front part), this value will be able to be changed. - Page 11 Manual de Usuario Serie LM5000 For example, if we want to accede to SETUP menu, we must vary the optical encoder in clock wise direction (positive sense) to increase the position of the selection window: Next, press CAL key, then it will accede to this menu If the user wants to leave from the menus application, the ESC key will be pressed, and then, it will disappear.
-
Page 12: Memory Recall Menu
Manual de Usuario Serie LM5000 This menu shows the equipmetn current configuration. It can be distinguished the following parts: - BOARDS: it indicates the options installed into the equipment. CCVS: It has available two composite video inputs (CCVS A & B). CDV: : It has available two SDI video inputs with passive loop-through (S1 &... -
Page 13: Setup Menu
Manual de Usuario Serie LM5000 The MEMORY RECALL menu allows to recall the values of the equipment, all the values stored by an user or by the technicians, existing values in different memories (user 1-user 4 and technical). The values that will recall are: Control Values (Brightness, Contrast, Saturation, etc.) and the calibration ones. -
Page 14: Setup Menu Manual
Manual de Usuario Serie LM5000 The SETUP menu allows to change the equipment values , as they are: - Calibration Values (CALIBRATION VALUES MENU). - Geometry Values (GEOMETRY SETUP MENU). - Colorimetry Values (COLOUR SETTINGS). - To calibrate the equipment with the current values (CAL WITH ACTIVE DATA). - To configure the options installed in the equipment(CONFIG. -
Page 15: Calibration Values Menu
Manual de Usuario Serie LM5000 4.3.1.1.CALIBRATION VALUES MENU Access Sequence The CALIBRATION VALUES menu, allows to modify the contrast , brightness, saturation values (only for CCVS signal), Hue (only for NTSC signal) and Dimmer. In this menu we can observe that in each moment it is showed the current value (A) and the calibration value (C) of the control that is desired to modify. -
Page 16: Geometry Setup Menu (Only For Rgb Video Signal)
Manual de Usuario Serie LM5000 4.3.1.2.GEOMETRY SETUP MENU (ONLY FOR RGB VIDEO SIGNAL) Access Sequence The GEOMETRY SETUP menu allows to change: CLOCK ADJ.: Sample clock frecuency of the analog signal. PHASE ADJ.: Sample clock phase of the analog signal. HORZ. -
Page 17: Colour Setting Menu
Manual de Usuario Serie LM5000 pressing CAL key (Negative or Positive). By pressing ESC key, it will recall the initial value without storing any change. 4.3.1.3. COLOUR SETTING MENU Access Sequence The COLOUR SETTING Menu allows to shift each RGB colour component. In order to adjust one of these values, it must be selected by means of the optical encoder (C in the frontal panel) and then press CAL key. -
Page 18: Cal With Active Data
Manual de Usuario Serie LM5000 By pressing ESC key, it will recall the initial value without storing any change. The RESET SETTINGS option will recall the values to its normal value. In order to leave the menu, press the ESC key. 4.3.1.4. - Page 19 Manual de Usuario Serie LM5000 Access Sequence The SYSTEM OPTIONS CONFIGURATIONS menu allows to activate options in the equipment that it have not been in its origin. For it, a code of 4 numbers is requested for, that will activate the option. This code, is facilitated by your distributor and is unique for each equipment.
-
Page 20: Password Menu
Manual de Usuario Serie LM5000 4.4. PASSWORD MENU Access Sequence The PASSWORD menu allows to modify the passwords from (user 1 to user 4) and the one from the system. In order to modify a password, you must be located on it and press CAL key: Password Change First of all, the old password is requested for, to assure that it cannot be changed by any other person:... -
Page 21: Explanation On The Passwords
Initially, all the codes passwords are initialized with values 1234 (from factory). 4.5 TECHNICAL MENU Access Sequence The TECHNICAL menu is of restricted access. The KROMA TELECOM technicians will be only able to accede to this menu by introducing its password. - 20 -... -
Page 22: Memory Store Menu
Manual de Usuario Serie LM5000 4.6 MEMORY STORE MENU Access Sequence The MEMORY STORE Menu, allows to store the current values of the equipment in the different memories from user (user 1 to user 4 and technical). These values will be those that will recover in MEMORY RECALL menu in case of being necessary. -
Page 23: Program Function Menu
Then, it will appear a text showing the recally progress and if this has been made successfully or not. (DONE or ERROR). Storing Sequence In order to leave the MEMORY STORE menu, the ESC key will be pressed. 4.7 PROGRAM FUNCTION MENU Access Sequence LM5009 LM5015 y LM5018 - 22 -... - Page 24 In order to change the colour press the CAL key. APERTURE: Aperture Control. This function only appears in LM5009 equipments, since they do not have associated key to such function as equipment LM5015 and LM5018 (APT key).
- Page 25 In order to know more information about the AUD or CHN key operation , you could see the explanation about the keyboard (point 3). SIZE: Screen aspect ratio (4:3 or 16:9). This function only appears in LM5009 equipments, since they do not have associated key to such function as equipment LM5015 and LM5018 (SIZE key).
-
Page 26: Embedded Audio Menu (Only For Sdi Video Signal)
Manual de Usuario Serie LM5000 4.8. EMBEDDED AUDIO MENU (ONLY FOR SDI VIDEO SIGNAL) Acces Sequence The EMBEDDED AUDIO menu shows information on the audio of the signal and allows to make the audio selection output in Analog and AES-EBU. The menu shows the groups and their corresponding audio channels. -
Page 27: Menu Remote
Manual de Usuario Serie LM5000 we press CAL key. Moving the optical encoder we will select the desired output and we must press the CAL key to validate it. Application Example In this case, we have selected channels 1 and 2 (1-2) belong to group 1 ( ) for the AES-EBU output. -
Page 28: Explanations About The Network Identifier
Manual de Usuario Serie LM5000 The REMOTE menu, allows to define a of network identifier in case such equipment needs to be controlled remotely (through RK5000 equipment). The network identifier must be located in the range from 0 to 254, allowing to have up to 255 equipment simultaneously controlled by only one remote equipment.
