Technical Manual

WATER SOFTENER

TM-EN-Slimline-Rev2013.08

Table of Contents

Need help?

Do you have a question about the Eco 17L and is the answer not in the manual?

Questions and answers

Summary of Contents for SlimLine Eco 17L

Page 2: Table Of Contents
Default parameter settings ....................Page 17 Exploded view - Slimline 11L, 14L ..................Page 18 Exploded view - Slimline 17L, 24L, 30L ................Page 20 Exploded view - Valve body assembly - Eco ............... Page 22 Exploded view - Valve body assembly - Eco ..............
Page 3: Warning & Safety Instructions
WARNING & SAFETY INSTRUCTIONS Before you begin the installation of the water softener, we advise you  read and carefully follow the instructions contained in this manual. It contains important information about safety, installation, use and maintenance of the product. The actual system that you have received, may differ from the pictures/illustrations/descriptions in this Technical Manual.
Page 4: Operating Conditions & Requirements
OPERATING CONDITIONS & REQUIREMENTS OPERATING PRESSURE: min. 1,4 / max. 8,3 bar   this system is configured to perform optimally at an operating pressure of 3 bar (±½ bar); in case of a lower or higher operating pressure the performance may be affected negatively! ...
Page 5: Installation
INSTALLATION Picture 1&10 DRAIN To facilitate the installation, you may want to remove the  salt lid and main cover from the water softener. We recommend the use of a stand pipe with air trap.  To prevent backflow from the sewerage system into the INLET &...
Page 6: Start-Up
START-UP PRESSURIZING PERFORM REGENERATION 1. Make sure the bypass system is in 'bypass' position. 11. Manually initiate a regeneration, by pressing the scroll 2. Make sure the electronic controller of the water button repeatedly until the display shows: softener is in service mode. 3.
Page 7: Electronic Control Panel
ELECTRONIC CONTROL PANEL Picture 7 REGENERATION MODE In regeneration mode the display shows the actual symbol button function regeneration cycle and, where relevant, the total remaining to advance to the next SCROLL regeneration time and remaining cycle time: parameter to increase the value of the BRINE FILL parameter to decrease the value of the...
Page 8 ELECTRONIC CONTROL PANEL PROGRAMMING INSTRUCTIONS - INSTALLER  Before entering the programming mode, make sure that the control valve is in the service mode. 1. Press the scroll button; the display will show: Language:English  Press the up or down button to set the language.
Page 9 ELECTRONIC CONTROL PANEL 7. Press the scroll button again; the display will show: PROGRAMMING INSTRUCTIONS - PARAMETER SET LEVEL MTR:SNAP SENSOR  All configuration parameters on this water softener  Press the up or down button to set the type of have been pre-programmed in the factory, to offer optimal water meter sensor.
Page 10 ELECTRONIC CONTROL PANEL  EZ3P5e EZ3PB r11: display shows the software version DIAGNOSTICS LEVEL (for factory purpose only).  CapToUse: display shows the remaining capacity. Besides of all programming parameters, a series of operating  Fill: display shows the refill time used for the previous parameters can be consulted in the diagnostics level;...
Page 11: Maintenance
MAINTENANCE ROUTINE CHECKS WATER CONDITIONER SALT Regularly the user should perform a basic check to verify if Picture 10 the water softener is functioning correctly, on the basis of The water softener needs 'brine' for its periodic the following control points: regenerations.
Page 12: Hydraulic Flow Diagrams - Eco
HYDRAULIC FLOW DIAGRAMS - ECO SERVICE REFILL BRINE PREPARATION BRINE DRAW / SLOW RINSE Page 12...
Page 13: Hydraulic Flow Diagrams - Eco
HYDRAULIC FLOW DIAGRAMS - ECO SERVICE REFILL BRINE PREPARATION BACKWASH BRINE DRAW / SLOW RINSE FAST RINSE Page 13...
Page 14: Troubleshooting
TROUBLESHOOTING PROBLEM CAUSE SOLUTION Hard (untreated) water Open or defective bypass Close or replace bypass to service Water softener in regeneration Wait until regeneration finishes or manually advance regeneration to end No salt in brine cabinet Add salt and initiate regeneration manually Salt bridging Break salt bridge(s) and initiate regeneration manually...
Page 15 TROUBLESHOOTING PROBLEM CAUSE SOLUTION Control valve fails to Low operating pressure Check operating pressure; must be higher than 1,4 draw brine Drain flow adjuster closed too much Open drain flow adjuster slowly until unit draws brine Plugged injector and/or brine restrictor Clean injector and/or brine restrictor Plugged injector filter Clean injector filter...
Page 16: Electrical Wiring Diagrams
ELECTRICAL WIRING DIAGRAMS     = flow meter    = power lead  = 24VAC auxilliary contact, closed during regeneration (max. 500mA)  = refill solenoid (white)  = drain solenoid  = key pad  ...
Page 17: Default Parameter Settings
DEFAULT PARAMETER SETTINGS Model Resin Hardness unit °f °f °f °f °f (1) (2) Exchange capacity per liter resin (°f M Resin (liters) Override (days) Cycle 1: REFILL (sec) Cycle 2: BRINE PREPARATION (min) Cycle 3: BRINE DRAW/SLOW RINSE (min) SNAP SNAP SNAP...
Page 18: Exploded View - Slimline 11L, 14L
EXPLODED VIEW - SLIMLINE 11L, 14L Page 18...
Page 19 EXPLODED VIEW - SLIMLINE 11L, 14L Item Description Remark  PT/1016/CP Pressure tank 10x16  E8000 Softening resin  38528 Riser tube assembly with deflector to be cut to length  287/166 Top distributor  568/303/6 Connection kit ¾” male ...
Page 20: Exploded View - Slimline 17L, 24L, 30L
EXPLODED VIEW - SLIMLINE 17L, 24L, 30L Page 20...
Page 21 EXPLODED VIEW - SLIMLINE 17L, 24L, 30L Item Description Remark  PT/0932/CP Pressure tank 9x32 Eco 17L, Eco 24L, Eco  PT/1032/CP Pressure tank 10x32 Eco 30L, Eco  E8000 Softening resin  38528 Riser tube assembly with deflector to be cut to length ...
Page 22: Exploded View - Valve Body Assembly - Eco
EXPLODED VIEW - VALVE BODY ASSEMBLY - ECO Page 22...
Page 23 EXPLODED VIEW - VALVE BODY ASSEMBLY - ECO Item Description Remark 15/90 Screw, solenoid retainer (4x)  413/134/24 Solenoid 541/229 Retainer, solenoid 413/58 Guide, solenoid  413/62 Spring, solenoid plunger  74099 Plunger, solenoid  74098 Diaphragm, solenoid 15/222 Screw, back cap (4x) 541/286/2/E Back cap DM/A6ME4...
Page 24: Exploded View - Valve Body Assembly - Eco
EXPLODED VIEW - VALVE BODY ASSEMBLY - ECO Page 24...
Page 25 EXPLODED VIEW - VALVE BODY ASSEMBLY - ECO Item Description Remark 15/90 Screw, solenoid (6x)  413/134/24 Solenoid (2x) 541/229 Retainer, solenoid 413/58 Guide, solenoid (2x)  413/62 Spring, solenoid plunger (2x)  74099 Plunger, solenoid (2x)  74098 Diaphragm, solenoid (2x) 15/222 Screw, back cap (4x) 541/274/2/E...
Page 26: Exploded View - Valve Body Assembly
EXPLODED VIEW - VALVE BODY ASSEMBLY Item Description Remark 15/87 Screw, valve head 72216 Valve head 541/300/G Drain flow control 2,0 gpm 11L, Eco 15L, Eco 541/300/J Drain flow control 2,6 gpm 185/115/1 O-ring, drain line adaptor 74018 Nut, drain solenoid 74016 Drain line adaptor 74019...
Page 27 Page 27...
Page 28: Technical Data - Eco
TECHNICAL DATA - ECO Technical specifications: Model Resin Operating pressure min/max (bar) 1,4/8,3 Operating temperature min/max (°C) 2/48 Electrical connection (V/Hz) 230/50 Maximum power consumption (VA) Hydraulic connection inlet/outlet ¾” BSP Male Supplied with 24V transformer Performances @ 3 bar operating pressure and brining of 125gr/Ltr of resin Model Resin Nominal exchange capacity (m³x°f)
Page 29 TECHNICAL DATA - ECO Technical specifications: Model Resin Operating pressure min/max (bar) 1,4/8,3 Operating temperature min/max (°C) 2/48 Electrical connection (V/Hz) 230/50 Maximum power consumption (VA) Hydraulic connection inlet/outlet ¾” BSP Male Supplied with 24V transformer Performances @ 3 bar operating pressure and brining of 125 gr/Ltr of resin Model Resin Nominal exchange capacity (m³x°f)
Page 30 Page 30...
Page 31 Page 31...
Page 32 AQUION, INC. Lammerdries-Oost 30c B-2250 Olen Belgium  +32 (0) 14-28.51.71  +32 (0) 14-28.51.70 RPR/RPM Turnhout BWT/TVA/VAT BE 0882.738.206  infobelgium@eriewatertreatment.com  www.eriewatertreatment.com...
