Maintenance

FUSES

■ Blade type
Normal
■ Cartridge type
Normal
■ Multi fuse
Normal
7 52
A vehicle's electrical system is protected
from electrical overload damage by
fuses.
This vehicle has 2 fuse panels, one locat-
ed in the driver's side panel bolster, the
other in the engine compartment near
Blown
the battery.
If any of your vehicle's lights, acces-
sories, or controls do not work, check the
appropriate circuit fuse. If a fuse has
blown, the element inside the fuse will
melt.
If the electrical system does not work,
first check the driver's side fuse panel.
Blown
Always replace a blown fuse with one of
the same rating.
If the replacement fuse blows, this indi-
cates an electrical problem. Avoid using
the system involved and we recommend
that you consult an authorized HYUNDAI
dealer.
✽ NOTICE
Blown
Three kinds of fuses are used: blade
OJC070046D type for lower amperage rating, car-
tridge type, and fusible link for higher
amperage ratings.
WARNING
- Fuse replace-
ment
• Never replace a fuse with any-
thing but another fuse of the
same rating.
• A higher capacity fuse could
cause damage and possibly a
fire.
• Never install a wire or aluminum
foil instead of the proper fuse -
even as a temporary repair. It may
cause extensive wiring damage
and a possible fire.
CAUTION
Do not use a screwdriver or any
other metal object to remove fuses
because it may cause a short circuit
and damage the system.
