Toshiba 32L221U Quick Setup Manual

Toshiba_ 32L221U_55L421U_16-0802_QSG_V7_ENG_Final.ai 1 10/12/2016 4:25:05 PM Toshiba_ 32L221U_55L421U_16-0802_QSG_V7_ENG_Final.ai 1 10/12/2016 4:25:05 PM
1
INCLUDED ACCESSORIES
32" 55"
+ +
Remote control and
two AAA batteries
32"
32"
Stand legs
M4 screws
(20 mm length)
(4 pcs.)
55"
Stand legs
C
M
M5 screws
Y
FEATURES
(10 mm length)
CM
MY (4 pcs.) Front
CY
CMY
32"
K
55"
Power cord
What you need
(not included)
Phillips screw driver
Back
Mobile device such as a tablet or
phone running an Android™ or
Apple® iOS.
Internet connection
(wired or wireless)
*Subscription or other payment may be required to access 32"
certain content.
55"
FIND YOUR USER GUIDE ONLINE!
Go to www.tv.toshiba.com and follow the
online instructions.
WARNING: To reduce the risk of fire or electric shock, do not
expose this apparatus to rain or moisture.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol within an equilateral
triangle is intended to alert the user to the presence of uninsulated
"hazardous voltage" within the product's enclosure, which may be of
sufficient magnitude to induce a risk of electric shock to persons.
The exclamation mark inside an equilateral triangle is intended to
alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature accompanying
the product.
IMPORTANT: See the online User Guide before installing the
TV on a wall.
URL: www.tv.toshiba.com
START HERE
How do I attach the stands to my TV? (not for wall mounting)
You'll need: Soft surface and a Phillips screwdriver.
A Carefully place your TV face-down on a cushioned, clean surface.
B Secure each TV stand leg to the bottom of your TV with two
of the provided screws.
A
M4 (20 mm) screws
B
32" 55"
(Sample Illustration)
32" - TV
32"/55"- TV
Remote sensor
Power On/Standby LED
55"- TV
32" - TV
INPUT
INPUT
Power button locations
Press to turn on your TV when your TV is off (in standby mode).
Press and hold to turn off your TV when TV is on.
32" 55"
AV IN
VIDEO L - AUDIO - R
LAN ANT /
USB
LAN CABLE IN
ETHERNET
CABLE IN
55"- TV
1
(ARC)
2
3
DIGITAL
OUTPUT
(Optical)
DIGITAL OUTPUT
(OPTICAL)
32" 720p, 60Hz, LED CHROMECAST BUILT-IN TV
55" 1080p, 60Hz, LED CHROMECAST BUILT-IN TV
55"
A
M5 (10 mm) screws
B
2
MAKING CONNECTIONS
How do I watch TV (cable, satellite, or antenna) or connect a device such as a DVD or Blu-ray disc player or game console?
HDMI® (BEST)
Best video quality
(Sample Illustration)
32" - TV
Note: Connect an ARC-enabled home
1
(ARC) theater receiver to HDMI 1.
2
ANT /
CABLE IN
3
DIGITAL
OUTPUT
(Optical)
Quick Setup Guide | 32L221U/55L421U
WALL MOUNT
32"
How do I prepare my TV for wall mounting? (not for use with a TV stand)
You'll need: Soft surface and a Phillips screwdriver
Before you mount your TV, make sure that:
55"
• You remove the stand legs.
• The wall-mount bracket is listed by an independent laboratory (such as UL, CSA, or ETL).
• The bracket supports the weight of your TV.
A Carefully place your TV face-down on a cushioned, clean surface.
OR
B See the instructions that came with your wall mount for more information about
how to correctly mount your TV.
A
32 "
VESA Mounting Pattern
VESA mount (mm): 100 × 100 - M4 type screws
Your TV has four VESA mounting holes on the back. If you attach a wall-mount bracket to the
B
back of your TV, the bracket must be securely attached, using all four holes. If you do not
use all four mounting holes, your TV may fall and cause property damage or personal injury.
See the documentation that came with your wall mount for complete mounting instructions.
(Sample Illustration)
32" - TV
AV (GOOD)
AV IN
VIDEO L - AUDIO - R
LAN
LAN
AUDIO/VIDEO OUT
CONNECTING ETHERNET (OPTIONAL)
(Sample Illustration) - 32" - TV
AV IN
VIDEO L - AUDIO - R
LAN
LAN
Note: For Chromecast built-in setup, you have to connect either LAN or Wi-Fi to access the Internet.
See back for additional info.
