Manual
Light Source
User Guide
MicroLED
Light Source Range
Models covered by this manual:
UFO MIC4000P
Please read this manual fully before installing, operating or performing
maintenance on the light source unit.
Universal Fibre Optics
Home Place | Coldstream | TD12 4DT | United Kingdom
Tel: +44 (0)1890 883416 | Fax: +44 (0)1890 883062
www.fibreopticlighting.com
Issue 2 | Revised: 101013
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for UFO MIC4000P
Summary of Contents for UFO MIC4000P
- Page 1 User Guide MicroLED Light Source Range Models covered by this manual: UFO MIC4000P Please read this manual fully before installing, operating or performing maintenance on the light source unit. Universal Fibre Optics Home Place | Coldstream | TD12 4DT | United Kingdom Tel: +44 (0)1890 883416 | Fax: +44 (0)1890 883062 www.fibreopticlighting.com...
- Page 2 Please read these instructions fully before connecting your unit to the electrical supply, and keep them for future reference. The UFO MicroLED range of light sources utilises an RGBW LED array and is suitable for use with either glass or polymer fibre-optic harness The MicroLED is powered by a 100-240 VAC remote desktop power supply unit.
- Page 3 INSTALLATION INSTRUCTIONS POWER SUPPLY REQUIREMENTS The LED Light Source is powered from a multifunction, multi-voltage, desk top Power Supply Unit. Remove the SW4047B Desk Top PSU from its box. This PSU is a multi-plug device catering for UK, European and USA plugs. Select the correct plug and slide it into the receptacle until it clicks securely into place as shown below: The plug can be removed by squeezing together the plastic retaining lugs and...
- Page 4 CONNECTION There are 2 connections required – the fibre port and the mains supply. The fibre port should be connected first. Connect and secure the fibre optic connector into the front of the unit and secure using the M5 locking screw Plug the mains plug into the electrical supply socket.
-
Page 5: Remote Controller Operation
REMOTE OPERATION 2. OFF 1. ON 4. Indicator Light 3. Colour Ring 5. Speed 6. Brightness 9. Mode 7. Brightness 10. Mode 8. Speed Description Function Button Power ON Button Power OFF Colour Ring Touch control all colours (White not available) Indicator Indicates Controller active when buttons pressed Button... - Page 6 Mode Function Programme List Mode Brightness Speed Comment To revert to 1 (Static White) at any Static White Adjustable Not Adjustable time touch Colour Ring then Mode+ Colour Ring control – brightness White and Colours adjust Colour only, not White. To Adjustable Not Adjustable mixed...
-
Page 7: Stand-Alone Operation
REMOTE RANGE WALK TEST Once the Light Source is fully installed carry out a complete range walk test and record the range in the table below. This information is essential for maintenance purposes to determine if the range/sensitivity is reducing and also to record dead areas within the Remote Controller’s range due to RF obstructions and/or RF interference. -
Page 8: Dmx Operation
The Light Source is controlled using the 2 push buttons on the rear of the unit. The Lower button STOPS and STARTS the colour Cycle The Upper button is used to select the Cycle speed as follows. Push the Lower button repeatedly until the colour White is displayed. -
Page 9: Maintenance
MAINTENANCE Please note that a record of all maintenance MUST be kept in the table below, indicating what maintenance was undertaken and when. This MUST be dated for warranty purposes. Date Maintenance Undertaken Universal Fibre Optics... -
Page 10: Technical Specifications
TECHNICAL SPECIFICATIONS Problem Probable cause(s) Remedy Mains supply off Check supply and reinstate Unit is dead - LED power Loose mains plugs Check plugs indicator is not illuminated PSU failed Replace PSU LED array failure Replace Light Source Unit is dead - no light output but LED power indicator is still May have been switched off... - Page 11 TECHNICAL SPECIFICATIONS Description Details Port connector size 30mm Fibre type Glass/Polymer Supply voltage 110VAC 60Hz / 230 VAC 50 Hz PSU Output 12V DC, 2A, 24W Maximum LED Power 2 - 5W in colour cycle mode Min Ambient Temperature -10ºC +45ºC Max Ambient Temperature Power Connection...
- Page 12 Universal Fibre Optics Home Place | Coldstream | TD12 4DT | United Kingdom Tel: +44 (0)1890 883416 | Fax: +44 (0)1890 883062 www.fibreopticlighting.com...
